Figure 1
Figure 3

Connecting the Lead Wires to the Electrodes

To connect the lead wire(s) to the electrodes:
1. Decide if you are using one lead wire (two electrodes) or two lead wires
(four electrodes). Follow clinician's instructions.
2. Locate the pins at the ends of the lead wire(s). If necessary, refer to the
image in the
3. Locate the pin insertion points on two or four electrodes as necessary.
NOTE:
4. With the electrodes still attached to the protective backing, insert one
lead wire pin into each electrode's insertion point. Insert the pins
entirely so that no metal shows.
NOTE:
5. Connect the lead wires to the electrodes before applying the electrodes
to the skin. This will reduce the possibility of dislodging the electrodes.
Select User's Manual
System Components
Refer to the electrode package for complete instructions.
Connect only one lead wire to each electrode.
Operation
Figure 2
Figure 4
section.
