System Components

Operating Buttons

These are the buttons you use to program your therapy settings, such as selecting the
treatment program and intensity.
On/Off
•
Quick Select programs
•
programs for a particular body area (Knee, Shoulder, Low Back/Hip,
Hand/Wrist, and Back).
Mode
•
SMP and Modulation).
Set
•
– used to change the therapy session parameters (Rate, Cycle Time,
and/or Span Percentage) based on which program option is selected. Also
used to access the Timer function.
Ch 1
• Increase – used to increase the intensity of the electrical current
sent through the channel 1 output jack.
Ch 1
• Decrease – used to decrease the intensity of the electrical current
sent through the channel 1 output jack.
Ch 2
• Increase – used to increase the intensity of the electrical current
sent through the channel 2 output jack.
Ch 2
• Decrease – used to decrease the intensity of the electrical current
sent through the channel 2 output jack.
NOTE:
decreases the intensity in 0.5 increments. Intensity range is 0.0 to 60.0.
The Up or Down intensity controls can be held down to increase or
decrease the intensity faster.

Intensity Lockout Feature

Once the intensity is raised above zero, with no activity for greater than 15 seconds, the
unit will initiate lockout of the increase intensity buttons. A lock symbol will appear on the
display to signify that this has occurred. This feature prevents any unintended key presses
to increase intensity or change the program option.

Output Jacks

The output jacks are where you connect the lead wires to the device. The output jacks are
labeled on the LCD display. Channels 1 and 2 operate independently. There are two (2)
LED indicator lights, one for each channel.
NOTE:
At a high rate, the LED indicator light will flash, looking like it is constantly on. At a
low rate, the LED indicator light will flash slowly.
18
– used to turn the stimulator on and off.
– used to select one of four program options (Continuous, Burst,
Pressing the Up or Down intensity controls increases or
* To unlock, press the Ch 1 or Ch 2 decrease button.
– used to select the most commonly used
