System B HeatSource
Instruction Guidelines
Warnings and Precautions
DANGER: Not for use in the presence of flammable anesthetics.
WARNING: Use of other accessories which are not authorized for
use in connection with the System B 1005 may cause malfunction
and may compromise patient safety.
CAUTION: This device has been investigated with regard to safety
from electrical shock and fire hazard as well as electromagnetic
compatibility (EMC). The device has not been investigated for
other physiological effects.
CAUTION: For use by qualified and trained personnel only.
Package Contents
P/N ........... Description
100-500 System B HeatSource Unit
100-535 Endodontic Training Block
500-173 Pinvise Nut
500-320 Bent Contact Clip
500-010 110 V Charge Adapter (for 110V unit only)
500-011 220 V Charge Adapter (for 220V unit only)
Available System B Tips
952-0003 Kit of four Buchanan Pluggers
952-0004 Fine, Buchanan Plugger
952-0005 Fine Medium, Buchanan Plugger
952-0006 Medium, Buchanan Plugger
952-0007 Medium Large, Buchanan Plugger
Available Accessories
952-0008 Handpiece Assembly
952-0017 Autoclave Tip Stand
951-0020 110V Charge Adapter
951-0021 220V Charge Adapter
951-0009 Pinvise Nut with Contact Spring
951-0010 Standard Anterior Heat Carrier
951-0011 Standard Posterior Heat Carrier
951-0012 Narrow Anterior Heat Carrier
951-0013 Narrow Posterior Heat Carrier
951-0014 Spoon Tip
951-0016 Hot Pulp Test Tip
951-0017 Thick Plugger (1mm)
951-0018 Thin Plugger (.5mm)
951-0019 Searing Tip
Symbols
Front Panel Symbols
Attention! Consult the manual before use.
Temperature Adjustment
Back Panel Symbol
Direct Current.
Bottom Panel Symbols
Attention! Consult the manual before use.
CSA mark with "NRTL/C" indicator for certified
products.
LP 113060
CSA file number.
Type BF Patient Applied Part
300-510_REVJ_SYS_B_HEATSOURCE_IFU_P1.indd 1 300-510_REVJ_SYS_B_HEATSOURCE_IFU_P1.indd 1
Model 1005
™
Packaging/ Handling Symbols
This way up.
Fragile, handle with care.
Keep away from rain.
Temperature limits for storage and transportation.
Product Features
1. The unit operates from a rechargeable battery.
A sturdy, sealed lead-acid battery provides quick reliable power.
At the maximum temperature the battery will provide one hour of
heating power before being depleted.
2. Recharge the battery with the charge adapter.
The unit is delivered fully charged. To recharge the battery use only
the plug-in adapter which comes with the System B HeatSource. Put
the unit in the Store mode by using the panel switch. Remove the tip
from the probe handle. Plug the charge adapter into a grounded wall
outlet and insert the jack at the end of the cord into the receptacle at
the back of the unit. The yellow Charge light will come on.
Note: The System B HeatSource will not operate while charge
adapter is plugged into unit.
For longest battery life, keep the unit on charge at all times when
not in use. The battery cannot be overcharged.
The battery is fully charged when the yellow Charge light turns off.
If the charge adapter is re-inserted when the unit is fully charged, the
Charge light will flash once.
The amber Low light will light up when you need to fully recharge
your battery.
3. The System B HeatSource probe
handle has special features.
The pinvise nut (1) provides a convenient holder for the different
tips. The contact spring (Ring Switch) (2) on the pinvise nut allows
you to touch activate the System B from any direction while wearing
gloves. When you want to heat a tip, depress the spring so that it
contacts the shaft (3).
1
page
Index:
English .......................1
Français .....................3
Español ......................5
Português ..................7
Technique Guide
Downpacking . . . . . . 9
Backfilling . . . . . . . . 11
2
1
3
