Overview of the A/CServiceCenter

6.1

Front

16
15
14
13
12
11
1 Low pressure gauge
2 Red "Fill" lamp
3 Blue "Evacuate" lamp
4 Green "Suction" lamp
5 High pressure gauge
6 Display
7 Keypad
8 Gas analysis unit
9 Front cover
10 Front wheels with wheel stops
