Temperature
The temperature control can be configured as a supply air control or an extract
air control. By default, this function is configured as a supply air temperature
control. Changes to this configuration are done in the advanced setup; see
Section 6.1.4
Setting
T° heating
T° Cooling
T° Freecooling
Fire Alarm
An external fire detection system is used to control the air handling unit in case
of emergency. The fire alarm function is activated by means of digital input
IN3.
Setting
Input
Supply airflow
Extract airflow
Periodic maintenance
Built-in timer for maintenance warning; if the maintenance interval is
exceeded, a maintenance reminder will be displayed.
Setting
3 monthly warning
12 monthly warning
Commissioning completed
When the commissioning has been successfull and this is confirmed in this
menu, the commissionig menu will not be activated automatically anymore.
Setting
Confirmation of
successfull commis-
sioning
22
Settings Factory
range setting
0...45°C 20,0°C
0...99°C 24,0°C
0...99°C 15°C
Settings Factory
range setting
Normally open Normally
Normally closed closed
0...max
0...max
Settings Factory
range setting
Yes No
No
Yes No
No
Settings Factory
range setting
Yes No
No
BASIC SETUP
LANGUAGE
UNITS
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
BASIC SETUP
LANGUAGE
UNITS
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
BASIC SETUP
UNITS
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
PERIODIC MAINTENANCE
BASIC SETUP
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
PERIODIC MAINTENANCE
COMMISSIONING COMPLETED
