5.1.3 BASIC SETUP
When the air handling unit is started up for the first time, the
commissioning menu is automatically displayed. At the very end
of the commissioning (menu) the commissioning of the unit has
to be confirmed by the service technician. Once the commis-
sioning has been confirmed, the commissioning menu will not
be displayed as first menu any more. The commissioning menu,
however, will remain accessible through the advanced
Section 6.1.4.
Language
The language desired can be set here. The language setting can
be changed at any time in the basic setup menu.
Setting Settings
range
Language Languages as
displayed
Units
The desired unit can be set here. The unit setting can be changed
at any time in the basic setup menu.
Setting Settings
range
Unit m³/h
l/s
Airflow regulation
The desired control mode can be set here. The setting can be
changed at any time in the basic setup menu. Depending on
the selected function, flows can be set as (l/s, m³/h), pressure
(Pa), input signal strenght (%) or torque (%). For both "Airflow
control" and "Torque control", three setpoints are available: Low,
medium and high.
Setting
Operating mode
20
Factory
setting
English
Factory
setting
m³/h
Settings Factory
range setting
OFF Airflow
Airflow
Demand control
Pressure
Torque
setup. See
BASIC SETUP
BASIC SETUP
BASIC SETUP
Operation and maintenance
BASIC SETUP
LANGUAGE
UNITS
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
LANGUAGE
UNITS
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
LANGUAGE
UNITS
AIRFLOW REGULATION
TEMPERATURE
FIRE ALARM
