Salamander Designs X-LARGE SINGLE DISPLAY MOUNT Quick Start Manual

For 4 bay cabinets

Download this manual

X-LARGE SINGLE DISPLAY MOUNT

FOR 4 BAY CABINETS

Vesa Patterns

Horizontal: 400, 500, 600, 700, 800, 900, 1000, 1100, 1200

Vertical: 100, 200, 300, 400, 500, 600

X-LARGE SINGLE DISPLAY MOUNT HEIGHT/WEIGHT CAPACITY

Wall

56" - Low

63" - H1

69" - H2

74" - H3

79" - H4

Secured

Center of Vesa Range (A)

45" - 51"

52" - 58"

57" - 63"

63" - 69"

68" - 74"

All

4-Bay

M1XL

400lbs

250lbs

400lbs

Salamander Designs, Single X-Large Display for 4 Bay Cabinets

501-726 [2.22]

Page 1 Secured Center of Vesa Range (A) 45” - 51” 52” - 58” 57” - 63” 63” - 69” 68” - 74” 4-Bay M1XL 400lbs 400lbs 250lbs 250lbs 250lbs 400lbs Salamander Designs, Single X-Large Display for 4 Bay Cabinets 501-726 [2.22]...
Page 2 1. Install Display Interface Brackets Fasten the display interface brackets using fasteners (length and size recommended by the display manufacturer). Interface Bracket Display Fasteners Mounting Discs Salamander Designs, Single X-Large Display for 4 Bay Cabinets 501-726 [2.22]...
Page 3 To adjust tilt angle, if necessary, leave the 1/4-20 x 5/8” Button Head Screws loose and adjust the Set Screws. Snug the 1/4-20 x 5/8” Button Head Screws, but do not over tighten. Header Tilt Adjustment Salamander Designs, Single X-Large Display for 4 Bay Cabinets 501-726 [2.22]...
Page 4 Salamander is proud to stand behind our products with industry-leading warranties. Should you ever encounter any problem with your Salamander product, let us know. We are here to make it right. 1.800.535.5659 - 860.761.9500 Full warranty including limitations and warranty claim information may be found at www.salamanderdesigns.com/commercial/warranty Salamander Designs, Single X-Large Display for 4 Bay Cabinets 501-726 [2.22]...
