SCHNERZINGER MULTI GUARD Quick Start Manual

MULTI GUARD

MULTI GUARD 2022-03 V1
Dear customer,
Thank you for your purchase of a
SCHNERZINGER product.
Please take the time to precisely read the
information in this guide. You will find
important instructions to use your product
and hints for the optimal integration into
your HiFi system.
This guide facilitates your use of the
product, promotes understanding
functional characteristics and helps you to
obtain the full efficiency of the product.
We hope you enjoy your
SCHNERZINGER product.
Abbildung ähnlich

Package Contents

MULTI GUARD master
min. 1x MULTI GUARD unit
12V power supply
(cable length 1,5m)
Antenna (per unit + master)
Dimensions and weight
MULTI GUARD MASTER:
its
l 7 x w 7 x h 3.5 cm / 0.3 kg
MULTI GUARD UNIT:
l 14 x w 5 x h 5 cm / 0.25 kg
new
Antennas are 11 cm long.
MULTI GUARD
The GIGA CANCELING technology of the MULTI GUARDs clears up electrical interfering
fields, resulting from the domestic power grid, radiating into the direct environment.
Application of multiple MULTI GUARDs offers a flexible modular assignment at critical
points, distributed in the room they form a comprehensive protected area thanks to
their coupling function.
A MULTI GUARD set always consists of a MASTER and at least one unit (either PHASE,
EARTH or ROOM).

MULTI GUARD PHASE:

Clear up the individual domestic power phases.

MULTI GUARD EARTH:

Clear up the protective/earth conductor.

MULTI GUARD ROOM:

Clear up the electrical interfering fields that radiate into the room through the power
cables installed in the walls and floors of the HiFi room.
When installing, always start with PHASE, followed by EARTH and finally ROOM.
The antenna should be in a vertical position (bent upwards).
It is essential to note the correct phase (marked by a silver dot on the plug). Measure
the phase of the socket accordingly.

Setting up step by step

1. MULTI GUARD MASTER – basic setting
The MASTER should have a central position in the HiFi room, a slightly elevated place
has also proven its worth.
In the basic setting it is operated without the 12V power supply.
Connect antenna
(upright position).
Switch in position 0.
