- Page 1 CE376-GPN LiDAR User’s Operation Manual May 2021...
- Page 2 Innovation and performance: we designed it so that it is always easy to use. In the line of Cimel products, you will also find a wide range of remote sensing and automatic Sun Sky Photometer CE318 that can be coordinated with your new Cimel CE376.
-
Page 3: Table Of Contents
North or South Hemisphere ..................10 3.3. Using your CE376 in all simplicity ................ 11 CE376 Acquisition Software ................12 Preserving and Maintaining your CE376 ............13 5.1. Visualization card ....................13 5.2. Windows ......................13 5.3. Maintenance routine .................... 13 2/14 05/2021 Cimel Electronique... -
Page 4: Packaging List
CE376 LiDAR User Operation Manual Packaging List One power supply cables and one network cable (10 m) are delivered with CE376 control unit. 3/14 05/2021 Cimel Electronique... -
Page 5: Ce376 Summary
> 6 µJ Laser Pulse Energy @808 nm > 3 µJ Receiving channel Diameter 100 mm Full Field Of View @532 nm 130 µrad Full Field Of View @808 nm 230 µrad Detectors Fiber coupled Computer interface 4/14 05/2021 Cimel Electronique... -
Page 6: Options
Green channel with dePolarization channel + NIR non-polarized channel 2.3.3. Thermal enclosure CIMEL LiDAR Instrument requires a thermo-regulated room or enclosure with a non-tempered glass (polarization artifacts may occur inside tempered glass) with high transmission in Vis-NIR range, for optimized condition. Please take care to not constraining the window in order to not induce polarization defects inside the glass (silicon joints advised). -
Page 7: Ethernet Extension Cable
The electrical wires are in good condition. • The diameter of the wires complies with the installation requirements. • Your electrical installation is equipped with 16-amps thermal-sensitive protection. In case of doubt, consult your electrician installer. 6/14 05/2021 Cimel Electronique... -
Page 8: Power Supply Specifications
2.3.8. Power Supply Specifications Power Voltage Frequency Consumption On start 100-240 V 47-63 Hz 150 W Running 100-240 V 47-63 Hz 75 W With the thermal enclosure, the total power supply is: 1200 W. 7/14 05/2021 Cimel Electronique... -
Page 9: Eye Safety
The laser output may vary with time as well as the repetition rate. In all case, the standard LiDAR emission will be eyesafe. 2.4.1. CE376 Bottom View Network 24 V DC Connect Connect 110/220 V Connector Power Supply Fuses Switch On/Off Cimel Electronique 8/14 05/2021... -
Page 10: Installation Guide
Each CE376 is delivered into one box (42 kg) with International Plant Protection Convention (IPPC): Check the impacts and tilts indicators inside and outside the box. Each indicators are signed. If indicators are red, note on the bill of lading and inspect product. 9/14 05/2021 Cimel Electronique... -
Page 11: Installation's Site Recommendation
North or South Direction Depending on the position of your CE376 on Earth, the direction of the window will have to be optimized following the table below: Region Position Window North Hemisphere North Direction South Hemisphere South Direction 10/14 05/2021 Cimel Electronique... -
Page 12: Using Your Ce376 In All Simplicity
USB cable. Switch on 1 the general power supply on the front of the CE376 control unit. Your LiDAR is now ready to acquire. Launch the app LidarII.exe and the acquisition should start right away. 11/14 05/2021 Cimel Electronique... -
Page 13: Ce376 Acquisition Software
The CE376 new software and USB driver can be download on our website at http://support.cimel.fr/ If you want update your old software for the new one, use Cimel Update (also available on our website). Acquisition software gives the users a complete control of all types of operation as scaling, time of automatic acquisition. -
Page 14: Preserving And Maintaining Your Ce376
Check if the hood of the CE376 is on place and securely attached (LiDAR not opened). 5.2. Windows Clean with soft cloth when dirty. 5.3. Maintenance routine A maintenance check-up is recommended every year. 13/14 05/2021 Cimel Electronique... - Page 15 Fax: (+33) 143 486 261 Email: cimel@cimel.fr Or use the contact form from our website: www.cimel.fr Cimel Electronique can use Skype and Team Viewer for any technical support. Before contacting us, please indicate: • The reference and the serial number of your product.
