CARD CREDENTIAL:

If the electronic lock is equipped with a card reader (HID Proximity or HID iCLASS, iClass SE or iClass Seos):
1. Present a valid card within range of the proximity card reader.

DUAL CREDENTIAL:

If the User or Supervisor requires a dual credential:
1. Enter a valid PIN and press "ENTER" (for Keypad credentials) or present a valid card (for HID Proximity or HID iCLASS, iClass SE or
iClass Seos credentials).
2. Enter the second credential (4-14 digit PIN) and press "ENTER."
NOTE: The second credential must always be a 4 - 14 digit pin.

To Relock the Cart using the Keypad:

1. The carts are equipped with AUTO RE-LOCK, the cart will lock automatically when the specified time elapses.
2. To re-lock before time limit expires, press LOCK/CLEAR button.
NOTE: The default AUTO RE-LOCK time is 5 seconds. AUTO RE-LOCK settings are adjustable via the LOCKVIEW software and this
feature can be disabled. Consult with your supervisor if there any questions about AUTO RE-LOCK settings.

Unlocking the Cart using the Override Key Lock:

1. Insert the key into the mechanical key lock and turn clockwise for RH hinged door and counter-clockwise for LH hinged door.
2. To open, pull out door to access.

To Relock the Cart using the Override Key Lock:

1. To close, push in door.
2. Turn the key in a counter-clockwise direction for RH hinged door and clockwise for LH hinged door.

Replacement of Batteries:

The Keypad is powered by a battery pack of 6 Non-Rechargeable Alkaline AA batteries. A yellow LED (callout 10) will illuminate when
batteries need to be replaced. The battery pack is located behind pull plate cover within battery pack compartment. Remove pull plate
cover then battery pack cover (3 screws) to access batteries fro replacement.
