- Page 1 All manuals and user guides at all-guides.com TENORE Eldridge Wardrobe Model # 34150, 34163, 34184 MÓVEIS PROVÍNCIA IND. COM. LTDA ROD. ASSIS CHATEAUBRIAND, KM 174 | CEP: 15110-000 GUAPIAÇU - SP - BRASIL | FONE: 05517 32679200 WWW.MOVEISPROVINCIA.COM.BR...
- Page 2 All manuals and user guides at all-guides.com...
- Page 3 All manuals and user guides at all-guides.com For Best Results • Do not throw away packaging materials until assembly is complete. • Assemble item on a soft surface, such as cardboard or carpet, to protect finish. • Proper assembly requires two people. Tools Required View our assembly video online www.manhattancomfort.com...
-
Page 4: Included In This Package
All manuals and user guides at all-guides.com Included in this Package 01. Baseboard 02. Front of Baseboard 03. Back of Baseboard 04. Baseboard Support Beams x2 05. Left Outer Side 06. Left Inner Side 07. Left and Right Shelves 08. Right Inner Side 09. - Page 5 All manuals and user guides at all-guides.com Included in this Package 0136 x 12 0138 x 16 0342 x 24 0394 x 6 3518 x 6 0429 x 4 4157 x 16 4462 x 18 2510 x 18 4219 x 6 4158 x 3 0440 x 4 3527 x 46...
- Page 6 All manuals and user guides at all-guides.com Baseboard STEP 1 0599 Take and lay ‚ them with the unfinished side up. Screw 2x0599 into the ‚ smaller predrilled holes. 0329 STEP 2 Take 2x04 and hammer ‚ 2x0329 into each of them. STEP 3 Take and hammer...
- Page 7 All manuals and user guides at all-guides.com Baseboard STEP 4 Take 2x04 and place them ‚ between push them all together. Place 2x0494 in each ‚ and screw it in. 0494 0494 Note: When placing ‚ be sure that the arrow is pointing to the hole in the edge of the wood.
- Page 8 All manuals and user guides at all-guides.com Prepare Vertical Pieces STEP 7 0394 Take and place ‚ and screw 2x0160 as shown. 0160 Take 3x4462 and screw ‚ 0394 2x0160 into each of them. 0136 Place 2x0136 on bottom ‚ edge and screw 2x0160 0160...
- Page 9 All manuals and user guides at all-guides.com Prepare Vertical Pieces STEP 9 Repeat Step 7 and Step 8 ‚ on 12. 0160 4462 STEP 10 0394 Take and place 0160 ‚ and screw 2x0160 0394 as shown. Place 2x4462 and screw ‚...
- Page 10 All manuals and user guides at all-guides.com Prepare Vertical Pieces 0160 STEP 12 0394 Flip over and place ‚ 0394 and screw 2x0160 as shown. Place 2x4462 and screw ‚ 0329 0160 2x0160 through each. 4462 Hammer in 2x0329 on top ‚...
- Page 11 All manuals and user guides at all-guides.com Prepare Vertical Pieces STEP 14 Take 2x10 and hammer ‚ 4x0329 into each as shown. 0329 0160 STEP 15 Take 2x14 and place on ‚ 4462 each 4462 and screw 2x0160 through each. Hammer 2x0329 into each...
- Page 12 All manuals and user guides at all-guides.com Prepare Horizontal Pieces STEP 17 Take 2x07 and hammer ‚ 4x0329 into each as shown. 0329 0599 STEP 18 Take and hammer ‚ 4x0329 as shown. 0599 Screw into middle ‚ of 09. 0329 STEP 19 Take...
- Page 13 All manuals and user guides at all-guides.com Prepare Horizontal Pieces STEP 20 Hammer in 2x0329 on side ‚ edge of 2x0329 0329 opposite side edge. Screw in 2x0599 as shown. ‚ 0599 0599 STEP 21 Flip over and screw in ‚...
- Page 14 All manuals and user guides at all-guides.com Build STEP 23 Place at edge ‚ of baseboard. Screw 2x3527 into 05, ‚ going through and into side edge of 01. Note: When putting ‚ together two pieces, be sure to fit the 0599(s) and/or 0329(s) and/or 3529(s) sticking out of one piece into the predrilled...
- Page 15 All manuals and user guides at all-guides.com Build 3527 STEP 25 Place on baseboard ‚ 0599 with (sticking up out of 01) fitting into the hole in its bottom edge. 0494 Place with the arrow ‚ pointing down and screw it in.
- Page 16 All manuals and user guides at all-guides.com Build STEP 27 Place other ‚ as shown. Place 0494 with the arrow ‚ pointing down on the bottom of and screw it in. Place with the three 3527 ‚ 0599 facing down. 0494 Screw 2x3527...
- Page 17 All manuals and user guides at all-guides.com Build 3527 STEP 29 Place 2x14 as shown. ‚ Place on the two 14. ‚ 0494 Place with the arrow 0494 ‚ pointing toward the holes on the top and bottom of both and screw each in.
- Page 18 All manuals and user guides at all-guides.com Back STEP 30 0357 Note: Make sure ‚ hammered into the wood when assembling the back. Place and hammer 0357 ‚ on top and side edges. 0357 Place a on left of ‚ 0342 wardrobe and hammer 0357...
- Page 19 All manuals and user guides at all-guides.com Drawers STEP 31 Hammer 2x0329 into 19, ‚ 3527 20, and each side of 21. Push them all together. ‚ 0329 3527 Screw through ‚ 3527 into and screw through into 21. STEP 32 Slide into slot.
- Page 20 All manuals and user guides at all-guides.com Drawers STEP 34 Push drawer front ‚ onto drawer. 0494 0494 Place in each hole ‚ with the arrow pointing to drawer front, and screw it in. 0160 STEP 35 Squeeze 4x0138 ‚ 0138 bottom of drawer as shown.
- Page 21 All manuals and user guides at all-guides.com Drawers 4158 0394 STEP 36 Repeat drawer procees 3 ‚ more times and slide them into wardrobe as shown. Take 3x4158 and place ‚ them onto 0394. Eldridge Wardrobe...
- Page 22 All manuals and user guides at all-guides.com Doors STEP 37 or 24. Take door pieces ‚ 4219 Place on outside of ‚ door and screw 5x0162 4219 through holes. Note: Make three right ‚ doors by screwing one end 4219 to the middle hole, and the other end to the far right hole.
- Page 23 All manuals and user guides at all-guides.com Doors 4462 2510 Screw A Screw B STEP 39 2510 Align in doors with ‚ 4462 in wardrobe sections and slide them in. Turn Screw A ‚ clockwise and Screw B counterclockwise to adjust hinges. Eldridge Wardrobe...
