Summary of Contents for Dorel mother's choice flux
- Page 1 flux 3 wheel stroller IMPORTANT! KEEP FOR FUTURE REFERENCE Illustrations and designs may vary. follow us on motherschoice.com.au...
- Page 2 PREPARING SEAT AND VEHICLE contents assembling the stroller Components list Opening stroller Wheel assembly Bumper bar assembly using Canopy Swivel wheel Operating brakes Adjusting handle Adjusting backrest Drink bottle storage Folding the stroller Unfolding the stroller Tether strap Securing your child Adjusting harness height care and maintenance Care instructions...
- Page 3 These instructions detail the safe use, assembly and maintenance of your product. Please read these instructions carefully and ensure that they are followed at all times. Failure to do so could result in serious injury or death. WARNING TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES WHENEVER THE •...
- Page 4 • Use only those accessories which are supplied by Dorel Australia and approved for use with this stroller. • To prevent the risk of the stroller catching fire, do not park it near an open fire, heater or barbecue.
- Page 5 WARNINGS • This stroller has been designed for use on flat or gently slopped surfaces. Using this stroller on uneven or higher sloped surface may cause the stroller to become unstable and tip over. • Regularly inspect all parts and locking devices, promptly replace worn out or broken parts.
- Page 6 COMPONENTS 1. Handle Front wheel assembly 2. Handle adjustment (both sides) 10. Front wheel swivel lock 3. Folding lock (both sides) 11. Footrest 4. Tether strap 12. Safety harness 5. Storage lock 13. Bumper bar 6. Brake lever 14. Canopy 7.
-
Page 7: Opening Stroller
ASSEMBLING OPENING STROLLER 1. Release the storage latch (Figure 1a). unclip 2. To unfold the stroller, simultaneously lift handle and pull up with a swift motion until and audible ‘click’ is heard. This will lift ensure the locking mechanism has engaged. click Mother’s Choice | Flux 3 Wheel Stroller... -
Page 8: Rear Wheel Assembly
ASSEMBLING REAR WHEEL ASSEMBLY 1. Align the round opening on the side of the stroller with the wheel axle. 2. Push down on the metal pin located on the bar of the frame (figure 2a). Simultaneously push slide the wheel onto the frame until it locks into position. -
Page 9: Attaching Bumper Bar
ASSEMBLING ATTACHING BUMPER BAR align and push 1. Align the bumper bar with the frame. Push down onto the bumper bar until an audible ‘click’ confirms it is secure and in the correct click! position. click! REMOVING BUMPER BAR 1. To remove bumper bar, push in both buttons located on the inner of the bumper bar (figure 4a) and remove from frame. -
Page 10: Using Canopy
USING USING CANOPY 1. Pull the front edge of the canopy to open (figure 5a). mother’s choice tip... The canopy is permanently attached to the stroller. USING VIEWING WINDOW 1. To reveal viewing window, ensure canopy is first fully extended. 2. -
Page 11: Canopy Positions
USING CANOPY POSITIONS Mother’s Choice | Flux 3 Wheel Stroller... - Page 12 USING OPERATING FRONT SWIVEL WHEEL TO LOCK: Push the lever up to lock. TO UNLOCK: Push the lever down to engage swivel wheel. swivel locked Mother’s Choice | Flux 3 Wheel Stroller...
-
Page 13: Operating Brakes
USING OPERATING BRAKES 1. To apply the brake, press down firmly on the red brake pedal. press down to apply lift up to release Mother’s Choice | Flux 3 Wheel Stroller... -
Page 14: Adjusting Handle
USING ADJUSTING HANDLE 1. There are two buttons either side of the handle bar. 2. Press both adjustment buttons simultaneously and rotate to the desired position. 3. Listen for ‘click’. 3 positions press swivel press Mother’s Choice | Flux 3 Wheel Stroller... -
Page 15: To Adjust Backrest
USING TO ADJUST BACKREST 1. To lower the backrest, squeeze the clasp to release and pull in a downward motion. Release the clasp once desired position has been reached. 2. To raise the backrest, squeeze the clasp and push whilst sliding upwards to desired position. - Page 16 USING STORAGE POCKETS 1. Total weight must not exceed 1 kg in both pockets. Mother’s Choice | Flux 3 Wheel Stroller Mother’s Choice | Flux 3 Wheel Stroller...
-
Page 17: Folding The Stroller
USING FOLDING THE STROLLER 1. Apply rear wheel brakes. 2. Remove all items in the shopping basket. 3. Fold the canopy. 4. Unlock the front swivel wheel. 5. Adjust the backrest to full layback position (see page 15). 6. Pull the folding locks up (figure 7a) and simultaneously push down on the stroller (figure 7b) to fold. -
Page 18: Unfolding The Stroller
USING UNFOLDING THE STROLLER release latch 1. Prior to unfolding, ensure the storage latch is released (figure 8a). 2. Simultaneously lift handle up in a short sharp motion until you hear the locking mechanism engage (figure 8b). lift click Mother’s Choice | Flux 3 Wheel Stroller... -
Page 19: Tether Strap
USING TETHER STRAP Whenever a child is in the stroller and brakes are NOT engaged, the large loop should be around your wrist (figure 9). WARNING Correct use of the tether strap will prevent stroller runaway and possible injury to your child. Mother’s Choice | Flux 3 Wheel Stroller... -
Page 20: Securing Your Child
USING SECURING YOUR CHILD 5 points of the harness can be adjusted by moving each straps’ slider (figure A1). To tighten or loosen the waist and/or shoulder straps, hold and lift the plastic adjuster. Adjust straps to desired position. The waist strap needs to fit firmly around the child. -
Page 21: Adjusting Harness Height
USING LOWER UPPER ADJUSTING HARNESS HEIGHT SLOT SLOT 1. The harness can be set at two heights, as displayed in figure 11a and 11b. LOWER SLOT USE 2. To use the lower slot, undo the buckle and feed the shoulder straps in through the loop (figure 11c) before securing harness. -
Page 22: Care And Maintenance
CARE AND MAINTENANCE • Always store in a clean and dry place. • Clean the frame by wiping with a damp cloth. • Do not use abrasives, bleach or strong detergents. • Spot clean fabrics with warm water and mild soap. •... - Page 23 notes Mother’s Choice | Flux 3 Wheel Stroller...
- Page 24 notes Mother’s Choice | Flux 3 Wheel Stroller...
- Page 25 notes Mother’s Choice | Flux 3 Wheel Stroller...
- Page 26 notes Mother’s Choice | Flux 3 Wheel Stroller...
- Page 27 mother’s choice tip... Visit us online to register your new Mother’s Choice product. follow us on motherschoice.com.au www.motherschoice.com.au/product-registration benefits of registration • Your safety - allows us to contact you with important product notifications. • Confirmation of ownership - to prevent loss or fading, provides a record in case of please attach your receipt here: product loss or theft.
- Page 28 Phone: 1300 809 526 Phone: 0800 628 000 (toll free) Specifications are subject to change without notice. Copy or reproduction without permission is prohibited. © 2017 Dorel Australia Pty Ltd. All Rights Reserved. 017501 Flux 3 Wheel Stroller 05/2018 Australia www.dorel.com.au...
