Page 1: Parts List
Parts List S I N G E R Model 7350 (Model 950D2) 029190036 (1) - Page 3 Page A Part Description EJD6033210 Back cover V610155000 Thread guide complete Set screw (M3x12) 0 0 4 2 3 0 3 2 6 * E1A2065000 Bobbin winder thread guide complete Bobbin winder thread guide adjusting E1A2053001* H 1 3 15 3 00 1 Bobbin winder thread guide spring H 1 3 13 3 00 1 Bobbin winder spring disc...
- Page 5 Page B Part Description E1A2683001 Thread take up lever E1A2653000 Thread take up lever supporter E-Ring (ETW-3) 0 0 3 0 1 0 0 3 6 * V60223003 Thread take up lever supporter shaft E1A2313003 Thread take up lever supporter shaft plate Set screw (M4x8A) 0 0 4 2 4 0 1 0 6 * E1A2663000...
- Page 7 Page C Part Description E1A0013000 E1A1373003 BH selector plate E1A1393003 BH slide plate Washer (4.2x9x0.5) 0 0 4 3 0 0 0 7 6 * E-Ring (ETW-3) 0 0 3 0 1 0 0 3 6 * Washer (4.2x12x1.2) 0 0 4 3 0 0 6 9 3 * BH selector plate E1A1413003 Set screw (M2x0.4)
- Page 9 Page D Part Description E5D0014000 Pattern cam contact complete E1A0673003 Pattern cam contact plate (back) E1A0653003 Pattern cam contact plate (front) H 11 9 3 5 0 0 0 Pattern cam shaft collar complete E1A0683003 Pattern cam shaft E-Ring (ETW-6) 0 0 3 0 1 0 0 6 3 * E5D0033000 Pattern cam...
- Page 11 Page E Part escription E1A1453006 BH lever plate E1A1533003 BH positioned plate E1A1513000 BH movement crank 0 0 4 2 3 0 4 3 3 Set screw (M3x3) E1A1523003 BH positioned plate 0 0 4 2 4 0 0 5 6 Set screw (M4x6B) E1A1473003 BH lever crank...
- Page 13 Page F Part Description NB0693000 Bobbin shaft oil cloth E1A2033000 Bobbin shaft NB0673000 Bobbin shaft washer (2) E-Ring (ETW-4) 0 0 3 0 1 0 0 4 6 * NB1275000 Shuttle hook complete NB0643000 Magnet NB1265000 Shuttle hook holder NB0683000 Bobbin shaft washer (3) E1A0563000 Needle plate cover...
- Page 14 NOTE: When you order any spare parts from us, please cooperate with us by writing. (1) Section,Sequence No,and Parts NO. (2) Name of parts (3) Voltage,if necessary (4) "*"means: These spare parts are not supplied individually,but can be obtained by minimum quantity at 300 pcs.
- Page 15 Page G Part Description 0 0 6 9 0 0 0 0 8 Hemmer foot (K) 0 0 6 9 1 8 0 0 8 Zig zag foot © 0 0 6 9 1 4 0 0 8 Button sew on foot 0 0 6 9 0 7 0 0 8 Overcastting foot (E) 0 0 6 9 0 4 0 0 8...
