Page 1: Parts List
Parts List S I N G E R Model 7322.7312 (Model 995D2.996D2) 版 029190039(1... - Page 3 Page A Part No. Description EJD6033210 Back cover V610155000 Thread guide complete Set screw (M3x12) 0 0 4 2 3 0 3 2 6 * E1A2065000 Bobbin winder thread guide complete Bobbin winder thread guide adjusting E1A2053001* H 1 3 15 30 01 Bobbin winder thread guide spring H 1 3 13 30 01 Bobbin winder spring disc...
- Page 5 Page B Part No. Description E1A2683001 Thread take up lever E1A2653000 Thread take up lever supporter E-Ring (ETW-3) 0 0 3 0 1 0 0 3 6 * V60223003 Thread take up lever supporter shaft E1A2313003 Thread take up lever supporter shaft plate Set screw (M4x8A) 0 0 4 2 4 0 1 0 6 * E1A2663000...
- Page 7 Page C Part No. Description E1A0013000 E1A1373003 BH selector plate E1A1393003 BH slide plate 0 0 41 03 08 1 Set screw (SM3/32×56 L=5) E-Ring (ETW-3) 0 0 3 0 1 0 0 3 6 * E1A2713000 Needle plate cover plate Rotary hook plate (2) E1A0603002 E1A2613002...
- Page 9 Page D Part No. Description EAD0014000 Pattern cam contact complete E1A0673003 Pattern cam contact plate (back) E1A0653003 Pattern cam contact plate (front) H 1 1 93 50 00 Pattern cam shaft collar complete E1A0683003 Pattern cam shaft E-Ring (ETW-6) 0 0 3 0 1 0 0 6 3 * EAA0053000 Pattern cam EAA0153003...
- Page 11 Page E Part No. Description EAA0213006 BH lever plate E1A2373000 Shield 0 0 2 4 2 5 1 18 Switch ass’y 0 0 1 2 5 1 4 09 Foot controller (4C-316B202ZH) U.S.A. 0 0 4 2 5 0 0 8 6 Set screw (M5x12) 0 0 4 2 4 0 0 5 6 Set screw (M4 x 6 B)
- Page 13 Page F Part No. Description NB0693000 Bobbin shaft oil cloth E1A2033000 Bobbin shaft NB0673000 Bobbin shaft washer (2) E-Ring (ETW-4) 0 0 3 0 1 0 0 4 6 * NB1275000 Shuttle hook complete NB0643000 Magnet NB1265000 Shuttle hook holder NB0683000 Bobbin shaft washer (3) E1A0563000...
- Page 15 Page G Part No. Description 006900008 Hemmer foot (K) 006918008 Zig zag foot © 006914008 Button sew on foot 006907008 Overcastting foot (E) 006904008 Blind hem foot (F) 006905008 Zipper foot (I) 006171008 Buttonhole foot (D) 006008001 Quilting bar 006051009 Anti-rusty 006052009 Drier...
