22.When using the heater, do not frequent switching windows and doors, it will affect the
heating effect.
23.Do not use the heater outdoors.
24.Keep the product specification, not discarded.
Electrical schematic diagram
Thermal Link
L
Indicator Light
N
Power Plug
Main technical parameters
Model
HD972E-A5Q
HD972E-A7Q
HD972E-A9Q
HD972E-A11LQ
HD972E-A11Q
HD972E-A13Q
HD972E-A15Q
Switch
NTC
Fall Switch
Non-adjustable thermostat
Figure5 Product Electrical Schematic Diagram
Number
Rated
of fins
voltage (V)
5
220-240
7
220-240
9
220-240
11
220-240
11
220-240
13
220-240
15
220-240
7
H1
ACL
H2
PCB
ACN
Heater 1
Rate（Hz）
power (W)
50/60
910-1100
50/60
1370-1630
50/60
1830-2180
50/60
2000-2400
50/60
2290-2720
50/60
2290-2720
50/60
2380-2830
Heater 2
Note
