Table 9: FIT Display Table
Menu Fit Display Short Meaning
Monitor Packets
Monitor Chars
One-on- 1-on-1
One
One-on- Connect
One
One-on- Model
One
One-on- Firmware
One
One-on- Name
One
One-on- Descr
One
One-on- BusAddr
One
One-on- EOL
One
One-on- Dev OID
One
One-on- BitVolts
One
Voltage Voltage
Voltage IdleBus
Voltage IdleBus
Voltage BitVolts
MS-FIT100-0 Field Inspection Tool User Guide
Expert
Mode
Number of X
Packets
Number of X
Characters
Connect to 1
Controller
Start 1-on-1
Communication
Model Name
Firmware
Version
Configuration
File Name
Device
Description at
Address
Address of
current device
EOL Switch
Position at
Address
Device Object Id
Bit Volts
Reading
Measure Bus
Voltages
Submenu item
Idle Bus Voltage
Reading
Submenu item
Description
A running total of the number of packets
transmitted while the FIT has been
connected.
Indicates the number of data bytes received
by the FIT. This number includes all messages
from all devices.
Main Menu item One-On-One. Used to read
attributes on 1 controller disconnected from
the bus.
Used by the FIT to communication with a
controller disconnected from a Bus.
Device object Model_Name property for
device connected to FIT (if disconnected from
the bus).
The version of the Firmware loaded in the
controller connected to FIT (if disconnected
from the bus).
The Name of the configuration file loaded
in the controller connected to FIT (if
disconnected from the bus).
Device object Description property for device
connected to FIT (if disconnected from the
bus).
Address reported for device connected to FIT
(if disconnected from the bus).
Position of the End-Of-Line Switch reported
by connected controller (if disconnected from
the bus).
The BACnet device ID for the connected
controller.
Communication Voltage reported by device
connected to FIT (if disconnected from the
bus).
Main Menu Item Voltage. Read Voltages Idle
Voltage, BitVolts and Meter Voltage Levels.
This is a submenu item. Press Enter to see
the Idle Bus Voltage.
Idle state (no communication) Voltage.
Measured when no communication is
occurring.
This is a submenu item. Press Enter to see
the Bit Voltage.
