Page 1: Table Of Contents
1/7/2021 PDF Export MS-FIT100-0 Field Inspection Tool User Guide Table of contents Introduction Accessories Physical Features General Use and Information FIT User Guidelines FIT Connection to Bus Modes of Operation Monitor Mode Scan Bus Mode 1-ON-1 Mode Battery Usage Getting Prepared to use the FIT...
Page 2: Introduction
1/7/2021 PDF Export Appendix A MS/TP Communication Basics and the FIT Voltage Levels Communication Voltage Levels Idle Bus Voltage Levels Proper EOL Termination FIT Connection, EOL, and Shield Grounding Scenarios 1-ON-1 Communication Voltage Levels Network Communication Voltage Levels Voltage Table Tips for Correcting Bus Installation Problems Quick Start Guide FIT Display Table...
Page 3: Physical Features
1/7/2021 PDF Export The following accessories for the FIT can be ordered separately: Table 1. Products and Accessories Code Number Description MS-FITCASE-0 FIT carrying case; includes one soft-sided carrying case FX-BTCVTCBL-700 FIT cable replacement; includes one 5 ft. (1.5m) retractable cable Physical Features The FIT is a portable handheld device.
Page 4: Fit Connection To Bus
The FIT is provided with a RJ-12 connector cable that is connected to the FC/SA 6 pin RJ-12 jack found on most Johnson Controls® controllers. The FIT also has a Four-Pin removable terminal block that is used to wire the FIT to the FC/SA bus. When the FIT is connected to the FC bus, it can only see the devices directly connected on the FC bus, but not the SA bus.
Page 5: On-1 Mode
Firmware revision, EOL termination switch, and other attributes. The 1-ON-1 mode is used to verify the operation of any single controller that does not communicate on the bus. It is used to help determine if a Johnson Controls manufactured controller is defective.
Page 6 1/7/2021 PDF Export cable and terminations are correct but ensures the anticipated number of controllers match the quantity found. Validate controller addresses and correct any duplicates. Before using the FIT, the user needs to make sure the bus installation to be tested (FC or SA) is complete and ready to be validated.
Page 7: Fit Menu
1/7/2021 PDF Export 4. For each SA Bus installation, all device addresses are reporting. Figure 1. FIT Menu Screens The FIT is designed to work with MS/TP hard wired controllers only and ignores wireless connected controllers. FIT Menu Figure 1. FIT Menu FIT Power On Menu Figure 1.
Page 8: Fit Issues Menu
(normally labeled 128) in the ON position. This switch is not to be used on a hard- wired Johnson Controls MS/TP Bus. It is reserved for Wireless bus installations. If you see this condition, validate that all FEC/VMA MS/TP hard-wired controllers have the 128 switch in the OFF position.
Page 9 1/7/2021 PDF Export If the FIT is turned OFF, issue count and history are not maintained. For a list of common issues and corrective actions, see Figure 6. No MSTP displays when the FIT is connected to a Bus with a very poor Health Index. Figure 1.
Page 10 1/7/2021 PDF Export Display Description Potential Corrective Action BadFrame Bad MS/TP frame. Invalid MS/TP header CRC or data system time CRC. Bad frames are typically caused by wiring issues, duplicate addresses, Check Idle Bus Voltage. wrong baud rates and/or noise. Confirm the correct FIT baud rate is being used.
Page 11 1/7/2021 PDF Export Display Description Potential Corrective Action system time If token passing is not Note: occurring and is initiated with the FIT connected to a bus (ScanBus Menu is selected), Online Issues may result until all addresses participate in the token passing loop.
Page 12 1/7/2021 PDF Export transmitted on the bus, so Display Description Potential Corrective Action it re-transmitted the token. Can be caused by wiring problems such as loose wires. If one controller has to send a token more than once it could be a wiring issue with the controller receiving the token.
Page 13: On-1 Menu
The FIT 1-ON-1 test communicates to the controller and provide feedback to the user pertaining to the operation of the controller. Figure 1. 1-ON-1 Test Menu The 1-ON-1 test provides the following information from a Johnson Controls manufactured controller: https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15...
Page 14: Monitor Menu
1/7/2021 PDF Export Model Type Firmware Revision Application Name Controller Description FC/SA Bus Address Status of EOL termination switch (ON/OFF) Voltage level of RS-485 communication from controller Notes: The Up Arrow key is used at any time to return to the previous screen. The EOL is automatically turned on.
Page 15: Scan Bus Menu
1/7/2021 PDF Export To scroll through the rest of the communication voltages for each controller address, keep depressing the return key once for each device address. If you hold down the Return Key, the display automatically scrolls through the voltage readings. Scan Bus Menu The Scan Bus mode is used to initiate, monitor, and interrogate controllers on the FC/SA bus.
Page 16: Voltage Menu
Using the Expert Mode communication is slower when a large amount of information is being transmitted and received. For Johnson Controls manufactured equipment, Model and Vendor data are displayed. For a complete list of all attributes, and modes see the FIT Display Table . See Network Communication Voltage Levels for more information on bus voltage levels.
Page 17: Bit Voltage Menu
1/7/2021 PDF Export readings during communication pauses. For acceptable Idle Bus Voltage ranges, see Voltage Levels and the Voltage Table It is possible and normal for there to be minor voltage fluctuations while Note: reading Idle Bus Voltages. Figure 1. Idle Bus Menu Idle Bus Voltage Levels for more information.
Page 18: System Menu
1/7/2021 PDF Export determine if there is any voltage caused by noise sources or improper wiring occurring on the bus. It is important to understand that once MS/TP communication is active, voltage readings with a Volt-Ohm-Meter (VOM) or via the FIT’s Voltage Menu item Meter are largely irrelevant.
Page 19: Report Menu
1/7/2021 PDF Export Baudrate—Select FIT baud rate to Auto Baud, 9600, 19200, 38400, 76800. Auto Baud is default mode. FitAddr—This menu allows the user to change the FIT address on the MS/TP bus. The default address is 1. If the FIT determines there is already a device addressed at 1, it will automatically default to the next available free address.
Page 20: General Bus Information
Num) Device Information The Device information section of the report is one record per address discovered. Some information in this section can only be completed if: a ScanBus was performed The device is a Johnson Controls manufactured product. https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 20/60...
Page 21: Issue Information
The device address for each device recorded. By default these are sorted ascending by address number. Model Device object Model Name property for device at address. (Typically only Johnson Controls manufactured devices.) Type Device object Vendor property for device at address. (Typically only Johnson Controls manufactured devices.)
Page 22 1/7/2021 PDF Export The Report menu has six submenu items: Save: Save the current data in the tool to a Report. Name: Enter the name of the report.in alphanumeric characters. For FC Bus reports, it is recommended to use the Engine name followed by trunk number, if applicable. NAE1 1 would mean trunk 1 on NAE 1.
Page 23: Ms/Tp Communication Basics And The Fit
NAE starts a token at 38,400, whereas, in the absence of an NAE or another device with a fixed baud rate, Johnson Controls devices wait for a valid signal on the trunk before attempting to communicate. A bus in this state is called https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15...
Page 24: Voltage Levels
Monitor Menu section of this guide. It is also important to understand MS/TP Bus installations can have Johnson Controls or Third-Party Vendor manufactured devices on them. Information availability, device responses, default baud rates, and voltage readings will vary from product to product and manufacturer to manufacturer.
Page 25: Idle Bus Voltage Levels
1/7/2021 PDF Export The FIT can measure the voltage levels on the RS-485 MS/TP communications on the FC/SA bus. The RS-485 communications produce a differential voltage between the + and – communication wires. The differential voltage is the addition of the + wire voltage with respect to the COM wire and the –...
Page 26 1/7/2021 PDF Export With proper EOL termination, the idle bus voltage should read approximately 2.7–2.3 VDC or 0.4V DC differential. The + communication line is biased at 2.7 VDC with respect to the COM line and the—communication line is biased at 2.3 VDC with respect to the COM line.
Page 27: Proper Eol Termination
EOL On command allows the FIT to act as an active termination that can be placed anywhere on the bus to help troubleshoot bus communication issues. Keep in mind the FCB EOL termination attribute is limited to Johnson Controls manufactured products that have a built-in EOL switch. The location of other EOL https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15...
Page 28: Fit Connection, Eol, And Shield Grounding Scenarios
1/7/2021 PDF Export devices and jumpers is not detected. Not all legacy Johnson Controls; controllers support the EOL termination attribute. Figure 18, Figure 19, and Figure 20 show different scenarios, how the FIT should be configured, and what EOL switches are monitored.
Page 29 Leave the Proper Shield Grounding Point at the NAE. In scenario two, shown in Figure 18, the following is occurring: The FIT is plugged into Johnson Controls Field Control Bus RJ. The FIT identifies two EOLs. The FIT EOL should be ON.
Page 30: On-1 Communication Voltage Levels
1/7/2021 PDF Export The FIT is plugged into Johnson Controls Field Control Bus RJ. The FIT has not identified any EOLs. The FIT EOL should be OFF. Leave the Proper Shield Grounding Point at the NAE. Make sure third-party vendor devices at the end of the bus have EOL.
Page 31: Network Communication Voltage Levels
1/7/2021 PDF Export in the range of 4–10 VDC differential voltage and 2 to 5 VDC for the +, – line voltages. The important thing to note is that the + and – line readings typically are equal or within approximately 0.2VDC of each other. The + line voltage will usually read equal to or slightly higher than the –...
Page 32 1/7/2021 PDF Export Table 1. Voltage Table Communication Voltage State Meaning Acceptable Range Bias Voltage Either Idle or The + to COM See notes below for Active Reading, - to COM acceptable ranges based Communication or + to -. Typically on active or idle used such as + is communication states.
Page 33: Tips For Correcting Bus Installation Problems
1/7/2021 PDF Export Communication Voltage State Meaning Acceptable Range Bit Voltage Active + or – with respect +2.0 to +4.0 VDC (+ to to COM when Com), -2.0 to -4.0 VDC (- to communication is Com). When comparing the occurring. absolute value of these two readings, there should be no more than...
Page 34: Quick Start Guide
See 1-ON-1 Menu for more information. Remove vendor equipment from the bus. Johnson Controls does not manage vendor equipment communication or default states. Isolating a bus to devices with known defaults ensures effective communication. Getting Prepared to use the FIT section for ways to use the tool on unpowered buses to validate continuous bus wiring and end-to-end continuity.
Page 35: Fit Display Table
1/7/2021 PDF Export Click here to view the most up-to-date version of the Field Inspection Tool Users Guide (LIT-12012443). FIT Display Table Table 1. FIT Display Table Expert Menu Display Short Meaning Mode Description Health Health of a Bus An overall indication of Bus Health.
Page 36 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description ScanBus Device Object The BACnet device ID for the scanned controller. This is set by the application file in the controller and are not necessarily unique. ScanBus Vendor Device Vendor Device object Vendor property for at Address device at address...
Page 37 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Issues EOL>2 >2 EOL Switches More than two devices with EOL are On switch ON. This is all EOL switches Note: on ALL bus segments for connected bus. Monitor Monitor Monitor Traffic ...
Page 38 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Monitor DevId Device ID at Device ID when an I-Am is seen in Address a capture (trigger with Who-Is) or -1 if not seen. Monitor RxTkn Tokens Received Displays the number of Token by Address Frames the device receives.
Page 39 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Monitor Postpd Reply Counts the number of data frames Postponed by received at the device that Address requires an immediate reply where this device requests additional time to prepare the reply. This may happen normally if the reply involves a large amount of data.
Page 40 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Monitor DNER Data Not Displays the number of data Expecting Reply frames sent by the device that do not require an immediate reply. This value includes proprietary frames that have been sent and received a reply.
Page 41 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Monitor Self Sent to Self Number of Tokens sent to self. Monitor Stats Bus Statistics This menu item provides overall Menu Item bus statistical information. Monitor LoopTime Loop Time Indicates how much time passes between the periods when the device allows initiation of messages on the network.
Page 42 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Monitor CharErrs Character Errors X Counts the number of errors detected in the individual data bytes received by the device. A framing error occurs when the device receives a stop bit in the wrong state.
Page 43 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description One-on- Connect Start 1-on-1 Used by the FIT to communication Communication with a controller disconnected from a Bus. One-on- Model Model Name Device object Model_Name property for device connected to FIT (if disconnected from the bus).
Page 44 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description Voltage BitVolts Bit Volts Communication Voltage reported Reading by random sample. Voltage Meter Submenu item This is a submenu item. Press Enter to see the Meter Voltage. Voltage System Change FIT's ...
Page 45 1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description System Format Report Menu – Select the method of Upload CSV Select method (Microsoft® Notepad) or TAB of Upload (csv (Microsoft® Excel®). If the user’s or tab) desire is save to a simple file, CSV is recommended to save into a spreadsheet directly use TAB.
Page 46: Appendix B: Fit Firmware Update Instructions
1/7/2021 PDF Export Expert Menu Display Short Meaning Mode Description System PowerOf Auto Power Off Adjust the number of minutes for the FIT to go into Sleep mode. Adjustable 0-99 minutes. Default is 15 minutes. 0 minutes keeps the FIT on indefinitely.
Page 47 1/7/2021 PDF Export 3. On the End User License Agreement window, accept the agreement and click Next. Figure 2. End User License Agreement Window 4. Deselect the USB Driver for E1/E20 emulators V1.0100 and the USB driver for Renesas MCU Tools V2.76.01 boxes. Figure 3.
Page 48 1/7/2021 PDF Export Change the location for the program at this time, if desired. Note: 5. Click Next.The Renesas Flash Programmer installation starts. When the installation is complete, click Finish. Figure 4. Installation Complete The Renesas Flash Programmer software is now installed. The FIT firmware is now ready to be programmed.
Page 49 1/7/2021 PDF Export 1. Turn off the FIT and remove the rubber protective boot. 2. Turn the FIT over and remove the battery cover. 3. Remove the four screws holding the cover to the base as shown in Figure 28. Figure 5.
Page 50 1/7/2021 PDF Export 6. From the File menu, select Create New Project. Figure 7. Renesas Flash Programmer—Create New Project 7. The Create New Project Window will appear. Figure 8. Create New Project Window https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 50/60...
Page 51 1/7/2021 PDF Export 8. Select the Microcontroller drop-down window and change the microcontroller type from RH850 to RX100. 9. In the Project Name window, type in the name of the project. In this example, the project is named FIT Update. 10.
Page 52 1/7/2021 PDF Export 12. Connect the USB 2.0 A Male to Micro USB 5 pin Male Cable to the FIT. See Figure 33. 13. Remove the programming jumper W6 located on the FIT to the left of the power switch and turn the FIT power switch to the On position. Figure 10.
Page 53 1/7/2021 PDF Export 14. Select the Connect button on the Create New Project window. Figure 11. Create New Project Window—Connect The FIT should now connect with the Flash Programmer software. The USB driver for the FIT is loaded from your computer. When the USB Driver has loaded, the Flash Programmer status window should look like Figure 35.
Page 54 1/7/2021 PDF Export 15. The Renesas Programming software is now installed. Power off the FIT. Close out the Renesas Flash Programmer software by selecting File > Exit. Figure 13. Renesas Flash Program—Exit https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 54/60...
Page 55: Programming The Fit
1/7/2021 PDF Export Programming the FIT About this task The Program File window needs to be updated with the path for the FIT firmware to be downloaded. Procedure 1. Locate and run the Renesas Flash Programmer software. Repeat this step as many times as necessary to download the firmware to the FIT.
Page 56 1/7/2021 PDF Export 3. Make sure the W6 Jumper is removed. 4. Turn the Power Switch on the front of the FIT to the ON position. Figure 2. Power Switch—ON 5. On the Operation tab select Start. Figure 3. Flash Operation Confirmation https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 56/60...
Page 57 1/7/2021 PDF Export 6. The flash programming should start as shown in Figure 40. Figure 4. Flash Operation—Running 7. When the Renesas Flash Programming is complete, the window will look like Figure 41. Figure 5. Flash Operation—Complete https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 57/60...
Page 58 1/7/2021 PDF Export 8. Turn the FIT Power Switch to the Off position. 9. Replace the W6 Jumper. 10. Turn the FIT Power Switch to the ON position. The FIT will power and display the proper firmware version on the display screen.
Page 59: Single Point Of Contact
12. Remove the USB 2.0 A Male to Micro USB 5 pin Male Cable from the FIT. 13. Replace the back cover and return the FIT to the rubber protective boot. Single point of contact APAC Europe NA/SA JOHNSON CONTROLS JOHNSON JOHNSON CONTROLS CONTROLS C/O CONTROLS PRODUCT...
Page 60 1/7/2021 PDF Export https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 60/60...
