Daheng Imaging VENUS USB3 Quick Manual

VENUS QuickGuide VENUS QuickGuide
Thank you for choosing DAHENG IMAGING products! This guide will help you get started as quickly as
possible with our products. For more information(e.g. detailed manuals, CAD/3D drawings, driver software,
etc.), please visit: www.daheng-imaging.com/en
This guide applies to the following products:
VENUS
■ ■ USB3.0 Series
1.1 Product description
The VENUS USB3 Vision series camera is DAHENG IMAGING's innovative board level industrial digital
camera. The cameras are available in a variety of resolutions and frame rates, and are available with CMOS
sensors from leading chip manufacturers, which is easy to install and use.
VEN-U3 series cameras have dual sensor board level cameras and single sensor board level cameras.
VEN-U3 series cameras transfer images via USB3.0 interface, featuring light and compact. Users can acquire
images and configure parameters with Galaxy Viewer.
Figure1-1 VEN-U3 series dual sensor board cameras
1.2 Electrical Interface
The appearances of VEN-U3 series cameras are shown the following. VEN-U3 series cameras transfer data
and power over USB3.0 interface, receive trigger signal and synchronizing signal via 4pin IO interface.
USB3.0
Figure1-3 The main board of VEN-U3 series dual
sensors board cameras
VEN-U3
I. Product Introduction
4pin IO
China Daheng Group, Inc. Beijing Image Vision
Technology Branch
Website: www.daheng-imaging.com/en
Sales Email: isales@daheng-imaging.com
Sales Tel: +86 10 8282 8878
Support Email: isupport@daheng-imaging.com
Figure1-2 VEN-U3 series single sensor board cameras
USB3.0
Figure1-4 VEN-U3 series single sensor board cameras
4pin IO
