- Page 1 China Daheng Group, Inc. Beijing Image Vision Technology Branch Mercury USB2.0 Cameras User Manual Version: V1.0.1 Date: 2017-12-19...
- Page 2 All rights reserved. No parts of this manual may be used or reproduced, in any forms or by any means, without prior written permission of China Daheng Group, Inc. Beijing Image Vision Technology Branch. The right is also reserved to modify or change any parts of this book in the future without prior notification. All other trademarks are the properties of their respective owners.
- Page 3 Preface We really appreciate your choosing the product of DAHENG IMAGING. Mercury USB2.0 series camera is the mature area scan digital camera, featuring mega pixels resolution, super precision, high definition, extremely low noise and perfect color conversion. The camera, which is equipped with a standard USB2.0 interface, is convenient for use and connection.
-
Page 4: Table Of Contents
Contents 1. Introduction ........................1 1.1. Models ........................1 1.2. General Specifications .................... 1 1.2.1. MER-030-120Ux (-L) ......................1 1.2.2. MER-040-60UX (-L) ......................3 1.2.3. MER-125-30Ux (-L) ......................5 1.2.4. MER-130-30UM (-L) ......................7 1.2.5. MER-132-30Ux (-L) ......................8 1.2.6. MER-310-12UC (-L) ......................10 1.2.7. - Page 5 4.7. Filters/Anti-reflection Glass..................27 4.8. Hardware Trigger ....................27 4.8.1. Input Port ........................... 27 4.8.2. Output Port ........................28 4.8.3. Connection Method of Cables ................... 29 4.8.4. Trigger Filtering ........................29 5. FAQ ..........................30 6. Revision History ......................31 ©...
-
Page 6: Introduction
1.2. General Specifications 1.2.1. MER-030-120Ux (-L) Table 1- 1 MER-030-120UC (-L) General Specifications Specifications MER-030-120UC MER-030-120UC-L Resolution 656 × 492 Sensor Type Sony ICX618, CCD Optical Size 1/4 inch 5.6μm ×... - Page 7 1.Introduction Image size, gain, Exposure time, Image size, gain, Exposure time, Programmable Control trigger polarity, flash polarity, etc. etc. Conformity CE, RoHs, FCC, GenICam *The value is related to the ROI/Video mode/capture speed level/horizontal blanking and etc. Table 1- 2 MER-030-120UM (-L) General Specifications Specifications MER-030-120UM MER-030-120UM-L...
-
Page 8: Mer-040-60Ux (-L)
1.Introduction 1.2.2. MER-040-60UX (-L) Table 1- 3 MER-040-60UC (-L) General Specifications Specifications MER-040-60UC MER-040-60UC-L Resolution 752 × 480 Sensor Type Global Shutter CMOS Optical Size 1/3 inch 6.0μm × 6.0μm Pixel Size Frame Rate 60fps@ 752 × 480 ADC Bit Depth 10bit Pixel Bit Depth 8bit, 10bit... - Page 9 1.Introduction Table 1- 4 MER-040-60UM (-L) General Specifications Specifications MER-040-60UM MER-040-60UM-L Resolution 752 × 480 Sensor Type Global Shutter CMOS Optical Size 1/3 inch 6.0μm × 6.0μm Pixel Size Frame Rate 60fps@ 752 × 480 ADC Bit Depth 10bit Pixel Bit Depth 8bit, 10bit 1μs~1s * Shutter Time...
-
Page 10: Mer-125-30Ux (-L)
1.Introduction 1.2.3. MER-125-30Ux (-L) Table 1- 5 MER-125-30UC (-L) General Specifications Specifications MER-125-30UC MER-125-30UC-L Resolution 1292 × 964 Sensor Type Sony ICX445, CCD Optical Size 1/3 inch 3.75μm × 3.75μm Pixel Size Frame Rate 30fps@1292 x 964 ADC Bit Depth 12bit Pixel Bit Depth 8bit, 12bit... - Page 11 1.Introduction Table 1- 6 MER-125-30UM (-L) General Specifications Specifications MER-125-30UM MER-125-30UM-L Resolution 1292 × 964 Sensor Type Sony ICX445, CCD Optical Size 1/3 inch 3.75μm × 3.75μm Pixel Size Frame Rate 30fps@1292 x 964 ADC Bit Depth 12bit Pixel Bit Depth 8bit, 12bit Shutter Time 10μs~1s *...
-
Page 12: Mer-130-30Um (-L)
1.Introduction 1.2.4. MER-130-30UM (-L) Table 1- 7 MER-130-30UM (-L) General Specifications Specifications MER-130-30UM MER-130-30UM-L Resolution 1280 × 1024 Sensor Type Rolling Shutter CMOS Optical Size 1/1.8 inch 5.2μm × 5.2μm Pixel Size Frame Rate 30fps@1280 × 1024 ADC Bit Depth 10bit Pixel Bit Depth 8bit, 10bit... -
Page 13: Mer-132-30Ux (-L)
1.Introduction 1.2.5. MER-132-30Ux (-L) Table 1- 8 MER-132-30UC (-L) General Specifications Specifications MER-132-30UC MER-132-30UC-L Resolution 1292 × 964 Sensor Type Optical Size 1/3 inch 3.75μm × 3.75μm Pixel Size Frame Rate 30fps@1292 x 964 ADC Bit Depth 12bit Pixel Bit Depth 8bit, 12bit 50μs~1s * Shutter Time... - Page 14 1.Introduction Table 1- 9MER-132-30UM (-L) General Specifications Specifications MER-132-30UM MER-132-30UM-L Resolution 1292 × 964 Sensor Type Optical Size 1/3 inch 3.75μm × 3.75μm Pixel Size Frame Rate 30fps@1292 x 964 ADC Bit Depth 12bit Pixel Bit Depth 8bit, 12bit 50μs~1s * Shutter Time Digital Gain ×1, ×0.5, ×0.25,×0.125, ×0.0625...
-
Page 15: Mer-310-12Uc (-L)
1.Introduction 1.2.6. MER-310-12UC (-L) Table 1- 10 MER-310-12UC (-L) General Specifications Specifications MER-310-12UC MER-310-12UC-L Resolution 2048 × 1536 Sensor Type Rolling Shutter CMOS Optical Size 1/2 inch 3.2μm × 3.2μm Pixel Size Frame Rate 12fps@ 2048× 1536 ADC Bit Depth 10bit Pixel Bit Depth 8bit, 10bit... -
Page 16: Mer-500-7Ux (-L)
1.Introduction 1.2.7. MER-500-7Ux (-L) Table 1- 11 MER-500-7UC (-L) General Specifications Specifications MER-500-7UC MER-500-7UC-L Resolution 2592 × 1944 Sensor Type Rolling Shutter CMOS Optical Size 1/2.5 inch 2.2μm × 2.2μm Pixel Size Frame Rate 7fps@ 2592 x 1944 ADC Bit Depth 12bit Pixel Bit Depth 8bit, 12bit... - Page 17 1.Introduction Table 1- 12 MER-500-7UM (-L) General Specifications Specifications MER-500-7UM MER-500-7UM-L Resolution 2592 × 1944 Sensor Type Rolling Shutter CMOS Optical Size 1/2.5 inch 2.2μm × 2.2μm Pixel Size Frame Rate 7fps@ 2592 x 1944 ADC Bit Depth 12bit Pixel Bit Depth 8bit, 12bit Shutter Time 50μs~1s *...
-
Page 18: Spectral Response
1.Introduction 1.3. Spectral Response 1.3.1. MER-030-120Ux (-L) Figure1- 1 MER-030-120UC (-L) Sensor Spectral Response Figure1- 2 MER-030-120UM (-L) Sensor Spectral Response © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 19: Mer-040-60Ux (-L)
1.Introduction 1.3.2. MER-040-60Ux (-L) Figure1- 3 MER-040-60UC (-L) Sensor Spectral Response Figure1- 4 MER-040-60UM (-L) Sensor Spectral Response © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 20: Mer-125-30Ux (-L)
1.Introduction 1.3.3. MER-125-30Ux (-L) Figure1- 5 MER-125-30UC (-L) Sensor Spectral Response Figure1- 6 MER-125-30UM (-L) Sensor Spectral Response © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 21: Mer-130-30Um (-L)
1.Introduction 1.3.4. MER-130-30UM (-L) Figure1- 7 MER-130-30UM (-L) Sensor Spectral Response 1.3.5. MER-132-30Ux (-L) Figure1- 8 MER-132-30UC (-L) Sensor Spectral Response © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 22: Mer-310-12Uc (-L)
1.Introduction Figure1- 9 MER-132-30UM (-L) Sensor Spectral Response 1.3.6. MER-310-12UC (-L) Figure1- 10 MER-310-12UC (-L) Sensor Spectral Response © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 23: Mer-500-7Ux (-L)
1.Introduction 1.3.7. MER-500-7Ux (-L) Figure1- 11 MER-500-7UC (-L) Sensor Spectral Response Figure1- 12 MER-500-7UM (-L) Sensor Spectral Response © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 24: Mechanical Interface
2.Mechanical Interface 2. Mechanical Interface 2.1. Mechanical Dimensions Three Views: (Unit: mm) Figure2- 1 MER-USB Series Mechanical Dimensions Figure2- 2 MER-USB-L Series Mechanical Dimensions © China Daheng Group, Inc. Beijing Image Vision Technology Branch... -
Page 25: Filters/ Anti-Reflective Glass
2.Mechanical Interface 2.2. Filters/ Anti-reflective Glass Each Mercury color camera is equipped with an additional infrared cut-Off filter, and each monochrome camera is equipped with a piece of transparent anti-reflection glass. The following figures are their specifications and spectral response. Figure2- 3 MERCURY Infrared Cut-Off Filter Spectral Response Figure2- 4 MERCURY Transparent Glass Spectral Response ©... -
Page 26: Optical Interface
2.Mechanical Interface 2.3. Optical Interface Figure2- 5 Optical interface Mercury USB cameras are equipped with C-mount lens adapters. The distance between the installation datum of lens and sensor photosensitive surface is 17.526 mm (in the air). After the filter/ transparent glass is installed, the distance between the installation datum and the filter/ transparent glass is 10.8mm, As shown in Figure2- 5, the lens can intrude into the camera body a maximum of 10.8mm. -
Page 27: Environment Requirement
2.Mechanical Interface 2.5. Environment Requirement Housing temperature during operation:0° C ~ 45° C,Humidity during operation:10% ~ 80% (relative , non-condensing). To avoid collecting dust on the optical filter, always keep the plastic cap on cameras when no lens is mounted. Make sure that cameras are transported in the original factory packages. -
Page 28: Installation And Use
3. Installation and Use 3.1. Setup Guide The installation of Daheng Imaging Camera Software Suite is very simple, but you have to take attention to the following matters. The path of installation can only be ASCII characters; otherwise you will not start the applications successfully. -
Page 29: Image Acquisition Control
4.Image Acquisition Control 4. Image Acquisition Control 4.1. Exposure 4.1.1. Exposure Mode Mercury series camera has two exposure modes: CCD cameras: Global shutter; CMOS cameras: the MER-040-60Ux camera is global shutter, and the others are electronic rolling shutter; Global shutter means that all the lines in the sensor are exposed at the same time. The high frame rate of up to 60fps allows the Mer-040-60Ux camera to be more suitable for moving objects and not to produce shadows. -
Page 30: Auto Exposure
4.Image Acquisition Control 4.1.3. Auto Exposure The MER series camera is designed for the industrial applications, designed for automatic exposure control, which can be adapted to different light variations without human intervention. The user can choose the operating environment according to the surrounding environment, and sets the Maximum & Minimum values of the adjustment, and ExpectedGrayValue, which can be automatically adjusted. -
Page 31: Digital Gain
4.Image Acquisition Control Figure 4- 1 VGA Gain 4.4.2. Digital Gain The camera also provides a hardware digital gain when outputting 8bit images. Table4- 6 Digital Gain Mode Hardware digital Gain ADC Level 0: Original brightness × 1 MER-500-7Ux ADC Level 1: Original brightness ÷ 2 MER-030-120Ux ADC Level 2: Original brightness ÷... -
Page 32: Black Level
4.Image Acquisition Control 4.5. Black Level The MER series USB interface camera is all with black level adjustable function. When the user needs to adjust the black level manually, he should disable the automatic black level calibration function, otherwise the camera may adjust it automatically. For CMOS cameras, if the automatic black level calibration function is disabled, some problems will appear in some situations, especially when using the Mono cameras, some fine grid will appear in the image. -
Page 33: Output Port
4.Image Acquisition Control Figure 4- 2 Camera input circuit 4.8.2. Output Port The MER series camera has one channel output signal, which is connected into the camera by the Hirose of the camera. And the output signal is opto-isolated. The voltage range of the VCC must between 5VDC -24VDC. -
Page 34: Connection Method Of Cables
4.Image Acquisition Control 4.8.3. Connection Method of Cables The MERCURY USB interface cameras have two types of trigger signals, one is positive voltage drive signal and the other is negative voltage drive signal. Both the High and the Low which are described in the software interface function and the demo, are based on positive voltage drive. -
Page 35: Faq
5.FAQ 5. FAQ General Question Answer Lower the acquisition speed; Increase the horizontal blanking length; The cameras often stop capturing Check the cable, Host and working environment; while working, but returned to normal after executing the start Recommend to use the USB port which is on the capture command. -
Page 36: Revision History
6.Revision History 6. Revision History Version Remarks Date V1.0.0 Initial release; 2017-06-22 Change manufacturer name to Daheng Imaging; V1.0.1 2017-12-19 Change logo. © China Daheng Group, Inc. Beijing Image Vision Technology Branch...
