- Page 1 3000 Examination couches User manual Version: 2.0...
-
Page 3: Table Of Contents
1. Important information ............................2. Foreword ................................. 3. Used symbols ................................ 4. Safety instructions .............................. 5. Intended use ................................6. medifa 3000 examination couches ....................... 7. Rating plate................................8. Commissioning ..............................9. Care instructions ..............................10. Technical data ............................... 11. Disposal ................................... -
Page 4: Important Information
All rights according to the copyright law are expressly reserved by medifa. medifa shall only be responsible for the safety- related properties of this device within the framework of the legal regulations if maintenance, servicing and changes to this device are carried out by medifa itself or a representative in accordance with instructions. -
Page 5: Foreword
Development, design and production at medifa have been certified according to DIN EN ISO 9001 and DIN EN ISO 13485. The products comply with the requirements of the German Medical Products Act (MPG) and bear the CE label. -
Page 6: Used Symbols
Used symbols 3. Used symbols Various information and safety symbols are used in these operating instructions to highlight particularly relevant information. Safety instructions HAZARD HAZARD indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNUNG verweist auf eine potenzielle Gefahrensituation die, wenn sie nicht vermieden wird, zum Tode oder zu schwe- ren Verletzungen führen kann. -
Page 7: Safety Instructions
Safety instructions 4. Safety instructions WARNING Risk of injury! The examination couch is designed for a maximum load of 225 kg. This safe working load must not be exceeded. WARNING Risk of injury! Only accessories listed in the accessories list may be used. WARNING risk of tipping! The examination couch must not be operated over an uneven floor! -
Page 8: Intended Use
5. Intended use The examination couch is intended exclusively for human medical purposes. The examination couch in combination with the standard medifa accessories is intended for the following uses: • The examination couch serves exclusively for short-term positioning of the patient during the examination and/or treatment. -
Page 9: Medifa 3000 Examination Couches
3000 examination couches 6. medifa 3000 examination couches Fig. 1: Model 111419/ 111519 Fig. 2: Model 111519/171519F Description Upholstery Safety spacer Paper roll holder stick Adjustable latch on the headrest Holder for paper roll holding stick Rocker switch for parking brake Castor User manual for examination couches version 2.0... -
Page 10: Rating Plate
Rating plate 7. Rating plate medifa GmbH & Co. KG Industriestraße 5 , 57413 Finnentrop, Germany medifa 3000 11xxxx xxxxx Tare weight: xx kg Manufactured: MM/YYYY Max. load: 225 kg Fig. 3: Rating plate Elements / symbols Description Manufacturer details and contact information... -
Page 11: Commissioning
Commissioning 8. Commissioning Headrest adjustment To adjust the angle of the headrest [1], it only needs to be lifted. To lower the head section, it must first be raised to the stop. This disengages the adjustment grid [2] and the head section can be lowered without difficulty. - Page 12 Commissioning Attaching a paper roll To attach a paper roll, take the supplied paper roll holder stick [1] and push it through the paper roll. Afterwards the roll can easily be hooked in between the pair of legs at the head end or foot end with the stick in the middle.To do this, drill holes are provided on both sides in the examination couch feet available.
-
Page 13: Care Instructions
Care instructions 9. Care instructions CAUTION Danger of personal injury. • Only hand over cleaned and disinfected devices / equipment to a service technician for maintenance and repair work. • Replace padding that no longer meets the hygiene and infection prevention requirements. WARNING Risk of damage to property due to incorrect care. -
Page 14: Technical Data
For proper disposal of old devices, please contact medifa‘s Technical customer service department, your local dealer or the appropriate national authority. - Page 15 User manual for examination couches version 2.0...
- Page 16 GmbH & Co. KG Industriestraße 5 57413 Finnentrop Germany fon +49 2721 7177-0 fax +49 2721 7177-255 info@medifa.com www.medifa.com...
