DvMultiRig
Thank you for choosing the MultiRig camera support.
The MultiRig is a modular
convertible camera support that can
be configured in many ways to
adapt to many uses and shooting
styles.
Acc. Plate
Unfolding the MultiRig
Place the rig on a flat surface with the foam grips up. Lift the grips up then swing and spread the side arms
to clear the way for the front arm, No swing the front arm to the right and lift the grip to a vertical position.
Turn the rig and position it on the grips.
Locate the locking mechanism at each grip/arm joint and practice moving it. To release, move the grip to
the center of it's slack, release the lock by pressing the brass lever with your thumb, move the grip.
Joints Adjustment
The arms and grips are designed for effortless uncomplicated minor modifications during shoots.
Do not over tighten them, Try the rig in real shooting conditions first.
Base bracket
The arms are connected to the base by adjustable friction joints. If necessary, use the supplied Allen
wrench to adjust the friction.
www.dvmultirig.com
Patent Pending
Support Pod
w / Flexi Tip
Back Bar
DVTEC
Inner Tube
Shoulder
Bar
Shoulder Brace
Right Arm
Acc.+ Cam
plate
adaptors
Hot shoe
3/8
adaptor
Allen
wrench
natovich@inter.net.il
3/8" support pod
threads
Lock
Base
bracket
Front Arm
Right Grip
www.dvtec.tv
Left Arm
Left Grip
