DVTEC DvCarRig Quick Start Manual

Included Parts

1 x Car Tripod.
1 x Main Column with 3/8" thread.
4 x Flat Hook Safety Straps.
3 x Vacuum Cup Feet for car use.
3 x Rubber Feet for ground use.
1 x Multi adjusting key.

Description

•
The DvCarRig is a camera tripod modified and adapted for on-car use.
•
The tripod center column has a standard 3/8" thread for attaching an extension arm, a ball head or any
other flat base fluid camera head. (e.g. Manfrotto/Bogen 501)
•
It has three extendable two section telescopic legs each with 4 position locking.
•
The Car Tripod can be used with the Vacuum Cups for on-car use or with the standard rubber feet for
ground use as a low angle baby tripod.
•
The Tripod is equipped with 4 locking buckles for attaching and tightening the flat hook safety straps.

General

•
Always wash the car before use to provide a clean and smooth surface for the Vacuum Cups.
•
Look for "soft" body areas and avoid leaning the tripod legs on them.
•
The Vacuum cups will not work on car body dents or scratched paint,
•
Do Not use the DvCarRig with the Vacuum Cups only!! Always attach and tighten the safety straps before
use.
•
Do Not mount the camera on the DvCarRig until all safety straps are safely and firmly attached and tightened.
•
Use extreme Caution when driving with the car mount. Especially with a side mount that sticks out from the
car.
•
Use a rig mounted car only according to the traffic rules in your country or area.
DvCarRig
Your shots would be as smooth as the road.

Optional Parts

:
Ball Head

Extension Arm.
