Getting Started - Barco SP4K-B Installation Manual

Getting started

2.1 Installation requirements ...............................................................................................................24
2.2 Unpacking the projector ................................................................................................................26
2.3 Unpacking the external cooler .......................................................................................................30
2.4 Initial inspection............................................................................................................................32
2.5 Conventions.................................................................................................................................33
2.6 Air flow ........................................................................................................................................34
2.7 Web Communicator ......................................................................................................................36
2.8 Web Commander .........................................................................................................................37
2.9 Exhaust adapters (optional)...........................................................................................................38
About this chapter
Read this chapter before installing your SP4K-B projector. It contains important information concerning
installation requirements for the SP4K-B projector, such as minimum and maximum allowed ambient
temperature, humidity conditions, required safety area around the installed projector, required power net, etc.
Furthermore, careful consideration of things such as image size, ambient light level, projector placement and
type of screen to use are critical to the optimum use of the projection system.
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms
of guarantee. Observing the specification mentioned in this chapter is critical for projector
performance. Neglecting this can result in loss of warranty.
The drawings in the installation manual are created for a SP4K-40B projector but are equal for the
other projector types. If there are exceptions the drawing for that specific projector is used.
2
R5912128 /03 SP4K-B 23
