- Page 1 All manuals and user guides at all-guides.com Vid 1 Vid 2 Vid 3 Vid 4 Mute A0127 IR Keypad for Multi-Room Audio Systems...
- Page 2 All manuals and user guides at all-guides.com A0127 Keypad Chan A0127 ... Keypad controller for use with the A4601. The A Features: Both Available in both white (A0127W) and ivory/almond (A0127IA) colors. varie Teaching capability allows controls to be stored in learning remote controls.
- Page 3 All manuals and user guides at all-guides.com Changing buttons face plates on the A0127 keypad... The A0127IA comes with both Almond and Ivory face plates and buttons. Both the A0127W and A0127IA come with replacement buttons labeled for a variety of sources.
- Page 4 All manuals and user guides at all-guides.com See page 6 for connection details A4603 Rear P Channel Vision A4601 Tested To Comply With FCC Standards Control Control Control FOR HOME OR OFFICE USE R-Audio-L Video R-Audio-L Video R-Audio-L Vide OUTPUTS...
- Page 5 IR emitter outputs allow IR-3002 flashers to be connected for remote control of source components. Ÿ Each zone is controlled through the A0127 keypad which connects to the RJ45 jacks on the rear panel. Ÿ A learning remote (such as the AB-500) can be programmed to control your source components and the A0127 (see page 7 for details).
- Page 6 Keypads connect to the A4601 through the RJ45 jacks on the back panel of the A4601. Connections to the A0127 may be accomplished either by using the RJ45 jack or the screw terminals provided on the back side of the keypad.
- Page 7 All manuals and user guides at all-guides.com Stripping and Connecting CAT5 Wire pad. CAT5 cable should be stripped with a proper stripping tool, such as Channel Vision’s J-110 tool. 1. Place the CAT5 between the blade and the first notch of the J-110 tool. Blade CAT5 2.
- Page 8 Setting the A0127 as the master keypad... By changing a jumper setting on the A0127 you can make it a master keypad. This simply means that the master A0127 will be able to power on or power off the entire system from a single zone.
- Page 9 All manuals and user guides at all-guides.com Channel Vision Technology will repair or replace any defect in material or workmanship which occurs during normal use of this product with new or rebuilt parts, free of charge in the USA, for one year from the date of original purchase.
