A) File information and reset button: Indicates the information on the chosen series, the reset button clears the cutting
data and returns to the initial key file screen without data.
B) Side and axis selectors: To select the active side, if the key has several sides. An axis selector also appears if the
side has multiple axes.
1) Engraving button: Activates engraving and allows a template to be chosen that has been defined for this
key model (defined in the Engraving/Marking section of this manual). The engraving is carried out together with the
cutting process.
C) Cutting information and options: this is all the information available on the app as regards cutting the key.
1) Line with values read by the machine: these are the depth values and the symbol that the machine has
deduced for the read key.
2) Line with deviations: the difference between the read value and that defined on the following line.
3) Lines with assigned values: indicates the cutting symbols that the manufacturer allows that are closest to
the read (or directly entered) values and its depth values. The symbols can be edited at any time.
4) Cut selector between read values or manufacturers' values: The usual thing to do is cut a key with the
manufacturer's values, in special cases, particularly in the case of old defective locks, it may be useful to be able to
cut a new key from a reading of the original, which is what this selector allows.
* fields 1, 2 and 4 only appear if the key has been read, otherwise they do not appear.
D) Warning indicators: these symbols appear at the side of the deviation values if there is a value with a high deviation
or the deviations conflict (large positive and negative deviations on the same key).
E) Information on the relationship between the symbol and the active axis value: displays all the information on the
symbols defined by the manufacturer and their depth values.
F) Drawing of how the cut will turn out and the relevant dimensions of the key: Displays an approximate preview of
how the key will look and its dimensions.
G) Tooling details: displays a screen with information on the tools to use and how to clamp the key in the machine.
H) Cutter selector: if a file has several cutter options, the cutter selector will appear with a choice between the normal
cutter, or the interpolation cutter if the normal cutter is not available.
I) Copy number indicator.
J) Cutting start button: starts the cutting process as defined in this key file.
K) Button for modifying cutting axes: it loads the screen where you can configure whether you want to read or cut
"excess" or "less" for each axis.
SELECT ENGRAVING TEMPLATE
You can assign a template to each side of the key, although this is not necessary. The templates assigned to each side
do not necessarily have to be the same or equal.
