User manual e-MatriX linear & e-MatriX mood
Faber ITC-V2 App
Download the Faber ITC-V2 app which is available
via, IOS and Android.
Linking the ITC V2 App to the ITC module
Open the app and follow the given instructions
(fig. 2.1).
Switching on/off the fire
Switch the fire on/off with the symbol
(fig. 2.2). Although the main lights operate immedi-
ately it will take a further 15 seconds before the
flame effect starts.
Switching on/off the heat
Press the small circle (fig. 2.3) and select the re-
quired setting (fig. 2.4):
Eco = no heating
Single flame = 1 kW heating
Double flame = 2 kW heating
Technical data
Heating maximum
Heating minimum
Flame only
Standby mode
Batteries remote
Water consumption
Inlet water pressure
Water connection
7 < < < <
Selecting a Mood setting
Click on the flame in the large circle (fig. 2.5) and
select a setting (fig. 2.6).
(Optional: top light & bottom light).
Enable/disable Mood setting
Press symbol
ting.
Activating the thermostat function
Navigate: Menu -> Settings -> Thermostat to acti-
vate the thermostat.
Switching on the thermostat function
Switch on the thermostat function using the sym-
bol (fig. 2.7).
Switching off the thermostat function
To manually set the flame height again, press the
symbol (fig. 2.8).
The thermostat function will then switch off auto-
matically.
e-MatriX linear e-MatriX mood
230 V 240 V 230 V
2270 W 2470 W 1955 W
1330 W 1450 W 1109 W
463 W 504 W 232 W
32 W 35 W
(2x) 1,5 AA V
0,3 L/h
0,5-8 Bar
½ or ¾ Inch
to enable/disable the Mood set-
240 V
2129 W
1208 W
253 W
21 W 23 W
(2x) 1,5 AA V
0,15 L/h
0,5-8 Bar
½ or ¾ Inch
