User manual e-MatriX linear & e-MatriX mood
General
 Please note!
Used in an environment where background
noise is very low, it may be possible to hear a
sound which is related to the operation of the
flame and heat effect. This is normal and
should not be a cause for concern.
Manual control (behind access door)
Button functions, see fig. 1.0:
A = main switch
1 = ON/OFF
2 = pairing
3 = only for maintenance (service engineer)
4 = reduce flame effect
5 = increase flame effect
6 = reduce fire crackling sound
7 = increase fire crackling sound
 Please note!
Main switch 'A' controls the electricity supply
to the fire. To operate the fire the switch must
be in the "ON" (I) position.
First time water fill

Ensure that all valves are open and turn
on the water supply.

Ensure that the mains switch is in the ON
(I) position.
Switching ON the fire
Press the button to turn on the
Although the main lights operate immediately it
will take a further 15 seconds before the flame ef-
fect starts.
Switching OFF the fire (standby mode)
Press the button to put the fire into standby
mode.
Remote control
Button functions, see fig. 1.1:
1 = OFF
2 = ON
3 = Reduce flame
4 = Increase flame
5 = Heating On/Off
6 = Mood setting On/Off
The remote control is already connected with the
receiver, so the fire is ready for use.
Placing batteries in the remote control

Unscrew the battery cover on the back
(fig. 1.3);

Place 2 AA 1.5 Volt Alkaline long life bat-
teries;
6 < < < <
Pairing Bluetooth remote control with receiver
See fig 1.0, knobs Control box;
Switching on the fire
Press the
Although the main lights operate immediately it
will take a further 15 seconds before the flame ef-
fect starts.
Switching off the fire (standby mode)
Press the
mode.
Getting the desired flame effect
The fire always starts with minimum flame setting.
Press the
flame effect.
Switching on/off the heat
flame effect.
Press the
 Please note!
Enable/disable Mood setting
Press the
setting.
 Please note!
Wall holder for the remote control
For a proper working of the thermostat function, it
is necessary to hang the remote control in the
holder (see fig. 1.4) in a suitable place. The remote
control is also the room temperature sensor. Place
the holder at a height of approximately 1,5m and
away from the radiation area of the fireplace.
Avoid placement in corners, near windows, doors
and heat sources such as central heating radiators.

Fix the battery cover again.

Turn the main switch in the "ON" (I) posi-
tion;

Press the button;

Simultaneously press button
on the remote control (see fig. 1.2) until
the LED starts flashing blue continuously
and then release the buttons. When a
connection is established, the LED will
flash green.
button to turn on the
button to put the fire into standby
and button to get the desired
button to turn the heater on/off.
The heater will be turned on or off at the value
as set in the App.
(Menu > Settings > Flame image > Heating
level remote control)
button to enable/disable the Mood
This enables/disables the last Mood setting set
in the ITC App (see chapter 8).
and
flame effect.
