Specifications

Range 44 lbs, 20kg,196 Newtons
o
Accuracy (23 C) ±(0.5%rdg + 2 digits)
Resolution 0.01lbs, 0.01kg, 0.05 Newtons
Overload Capacity 30kg
Circuit Custom LSI microprocessor circuit
Zero adjust Button for Peak Hold and normal display zero
Display 5 digits, 16 mm (0.63") LCD display
Update Rate Fast mode 0.2 secs; Slow mode 0.6 secs.
Over-range Indicator Displays "--------"
Zero Control Maximum capacity
Approx. 2mm max.
Full Scale Deflection:5000g
Approx. 0.4mm max.
Full Scale Deflection:20kg
Transducer type Load cell
Peak Hold Freezes Max reading on display
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F).
Operating RH Max. 80% RH.
Power Supply 6x 1.5V AA (UM-3) size battery or DC 9V adapter (not included)
Weight 480g / 1.1 lbs.
Size 215 x 90 x 45 mm (8.5 x 3.5 x 1.8")
Mounting Holes Located on rear of gauge
Accessories Tension adapter (hook), compression adapters (flat, cone, and chisel),
5" extension rod, 6 x 1.5V AA batteries, case
Copyright © 2014 FLIR Systems, Inc.
All rights reserved including the right of reproduction in whole or in part in any form
www.calcert.com
15
10 20
5 25
0 30
475044
176oz, 5000g, 49 Newtons
± (0.4%rdg + 1 digit)
0.05oz, 1g, 0.01 Newtons
10kg
6 475040-475044-EU-EN v2.7 5/14
475040
