User's Guide
Models 475040 and 475044
Digital Force Gauge
1.
Universal sensing head
2.
LCD Display
3.
Fast response indicator
4.
FAST / SLOW response selection
5.
LCD reverse display button
6.
Zero/Tare button
7.
Units select switch
8.
Mounting Holes (on rear)
9.
Battery compartment cover (on rear)
10. Flat Head adapter
11. Cone adapter
12. Chisel adapter
13. Hook adapter
14. 5" (120mm) extension rod
15. OFF/ON/PEAK HOLD button
Introduction
Congratulations on your purchase of Extech's Digital Force Gauge. This professional meter,
with proper care, will provide years of safe reliable service. Measure Tension or Compression
(Push or Pull) to 5kg (475040) or 20kg (475044), reversible display indicates readings in
grams, ounces, or newtons. This meter offers Peak Hold and a Zero function.
