Summary of Contents for Anova TC102
- Page 1 Instructions and user manual TC102 Milasur, SL. Rúa Eduardo Pondal, nº 23 - Pol. Ind. Sigüeiro 15688 - Oroso - A Coruña 981 696465 www.millasur.com...
- Page 2 ANOVA wishes to congratulate you for choosing one of our products and guarantees the assistance and cooperation that has always distinguished our brand over time. This machine is designed to last for many years and to be of great use if used in accordance with the instructions contained in the user manual.
-
Page 3: Table Of Contents
CONTENT 1. SAFETY INDICATIONS 2. IDENTIFICATION OF PARTIES 3. ASSEMBLY 4. CONTROLS AND ACCESSORIES 5. INSTRUCTIONS FOR USE 6. MAINTENANCE 7. TECHNICAL DATA 8. WARRANTY 9. ENVIRONMENT 10. EXPLODING 11. EC DECLARATION This manual has been written to help you become familiar with the machine and use it safely and efficiently. -
Page 4: Safety Indications
1. SAFETY INDICATIONS Some paragraphs in the manual that contain important safety and operating information are highlighted in the following ways: WARNING or IMPORTANTThese provide details or more information on what has already been said, in order to prevent damage to the machine. CAVEATFailure to comply will carry the risk of injury to oneself or others. - Page 5 - the fact that you cannot use the brake to regain control of a machine that is sliding down a slope. The main reasons for loss of control are: insufficient wheel grip; • speeding; • • inadequate braking; • the type of machine is not suitable for its task; ignorance of the effect of terrain conditions, especially slopes;...
- Page 6 7) Disable the cutting system before crossing surfaces other than grass. 8) Never use the machine with the guards/covers damaged, or without the guard in place. 9) Do not change engine control settings or exceed engine speed (rpm). Running the engine at excessive speed can increase the risk of personal injury.
-
Page 7: Identification Of Parties
4 Danger! Ejected Objects: Keep bystanders away. 5 Danger! Risk of machine tipping over: Do not use this machine on slopes steeper than 10°. 6 Danger! Cuts and Injuries – Make sure children are kept away from the machine at all times when the engine is running. -
Page 8: Assembly
IDENTIFICATION OF MAIN COMPONENTS 1. Grass catcher 10. Cutting height adjustment lever 2. Grass discharge tube 11. Collection bag turning lever 3. Driving seat 12. Engine throttle 4. Front steering wheel 13. Rear wheel 5. Light switch 14. Cutting deck 6. - Page 9 NOTE On Hydrostatic Drive Models: For easy movement or removal of the machine from the platform, place the drive disengagement lever in the “B” position to unlock traction and allow the machine to move freely. 3.2 MOUNTING THE STEERING WHEEL Place the machine on a flat surface and align the front wheels.
- Page 10 3.5 ASSEMBLE THE COLLECTING BAG SUPPORT Using the nuts and bolts inside the attached envelope, fit the two brackets onto the rear frame. NOTE: Pay attention to the difference between the pin on the left bracket and the pin on the right.
- Page 11 3.6.4 Attach the side retaining tube to the grass catcher, use screws to fit it into the upper bracket and lower bracket. 3.6.5 Mounting the outlet guard (grass catcher) Never use the machine without having installed the outlet protections! Attach the grass catcher to the brackets and center it up with the back plate so that the two reference marks line up.
-
Page 12: Controls And Accessories
4. CONTROLS AND ACCESSORIES 4.1 STEERING WHEELTurns the front wheels and allows you to steer the machine while working. 4.2 THROTTLE Regulates the motor the number of rpm and the forward speed. The positions are indicated on a plate showing the following symbols: "CHOKE"... - Page 13 4.5 IGNITION KEY (☛Fig2) It has three positions: "OFF" everything is off; "ON" activates all parts; “START” engages the starter motor. If you release the key at “START”, it will automatically return to “ON”. 4.6 SOUND WARNINGS - The audible warning indicates that the grass catcher is full. 4.7 CUTTING HEIGHT ADJUSTMENT LEVER There are six positions for this lever (shown as "1"...
- Page 14 4.9 GRASS CATCHER RELEASE LEVER This removable lever tilts and empties the grass catcher. This means less work for the operator. 4.10 DRIVE PEDAL This pedal activates the drive of the wheels and controls the forward and reverse speeds of the machine. - To activate forward, press towards «F»...
-
Page 15: Instructions For Use
5. INSTRUCTIONS FOR USE 5.1 SAFETY RECOMMENDATIONS DANGER The machine must only be used for the purpose for which it was designed (cutting and collecting grass). Do not tamper with or remove the safety devices installed on the machine. REMEMBER THAT THE USER IS ALWAYS RESPONSIBLE FOR DAMAGE AND INJURIES TO OTHERS. - Page 16 connect a compressed air line with a pressure gauge to the valve. The correct pressures are: FRONT 1.0 bar (15 x 6.0-6) REAR 0.8 bar (18 x 8.5-8) 5.3.3 Checking fuel and oil (☛3.7) 5.3.4 Checking the safety and efficiency of the machine. 1.
- Page 17 5.4.3 Braking The machine already slows down considerably simply by releasing the drive pedal. If you release the drive pedal, the machine will stop if it is on a flat area. If there is a gradient or you require more consistent braking, you can press the brake pedal.
- Page 18 Cutting very tall or wet grass, especially at excessively high speeds, can clog the collector channel. If this happens, proceed as follows: - stop moving forward, disengage the blades and stop the engine; - remove the grass catcher or guard; - remove the grass cuttings;...
- Page 19 engine or exhaust to prevent them from igniting the next time the machine is used! Store the machine in a dry and protected place, preferably covered with a cloth or cover. IMPORTANT The battery should be kept in a cool and dry place. Before a long storage period (more than 1 month), always charge the battery to the maximum and then recharge it before using it again.
- Page 20 ﹥15° 15°﹥10° Grass on a slope must be mowed moving up and down and never perpendicular to the slope. When changing direction, be very careful that the wheels facing up the slope do not hit any obstacles (such as stones, branches, roots, etc.) that could cause the machine to slide to the side, tip over, or cause the machine to slide sideways.
-
Page 21: Maintenance
6. MAINTENANCE 6.1 SAFETY RECOMMENDATIONS CAVEAT Before cleaning or maintenance work, remove the ignition key and read the instructions. Wear proper clothing and work gloves when your hands are at risk. CAVEAT Never use the machine with worn or damaged parts. Defective or worn parts should always be replaced and not repaired. - Page 22 IMPORTANT Follow all instructions in the engine manual. To drain the engine oil, unscrew the oil cap when you put the cap back on, make sure the seal is seated correctly. 6.2.3 Battery The battery must be carefully maintained to ensure a long service life. The battery of the machine must always be charged:- before using the machine for the first time after purchase;- before leaving the machine unused for a long period;- before starting the machine after a long period of disuse Carefully read and follow the battery recharging instructions in the booklet that came with the battery.
-
Page 23: Technical Data
Belt replacement must be done at an Authorized Service Center. DANGERReplace belts as soon as they show obvious signs of wear! ALWAYS USE ORIGINAL REPLACEMENT BELTS! 7. TECHNICAL DATA MODEL ANOVA TC102 Blade screw tightening screw 40Nm Electric system Battery... -
Page 24: Warranty
- Misuse, negligence, careless operation or lack of maintenance. - Defects caused by incorrect use, damage caused due to manipulations carried out by personnel not authorized by Anova or use of non-original spare parts. 13.4. IN CASE OF INCIDENCE - The guarantee must be correctly completed with all the information requested, and accompanied by the purchase invoice. -
Page 25: Exploding
10. EXPLODING... -
Page 30: Ec Declaration
In the event that the machine is modified and this modification is not approved by the manufacturer and communicated to the distributor, this declaration will lose its value and validity. Machine name: LAWN TRACTOR TC102 Model: Recognized and approved standard to which it conforms: Directive 2004/108/EC...
