CC400PT / CC400P

OWNER'S MANUAL

Read and follow all Safety Rules and Instructions Before operating this equipment

CE-Declaration

The machinery complied with European Machinery Directive 2006/42/EC and European

standard EN 836.

Table of Contents

Need help?

Do you have a question about the CC400PT and is the answer not in the manual?

Questions and answers

Summary of Contents for Anova CC400PT

Page 1 CC400PT / CC400P OWNER’S MANUAL Read and follow all Safety Rules and Instructions Before operating this equipment CE-Declaration The machinery complied with European Machinery Directive 2006/42/EC and European standard EN 836.
Page 2: Table Of Contents
Thank you for choosing an ANOVA lawnmower. To ensure that you get the best results from your Gasoline Lawnmower please read all of these safety and operating instructions carefully before using this product. TABLE OF CONTENTS PRODUCT SPECIFICATION Product Specifications…………………….1 Safety Rules……………………………….2...
Page 3 Training a) read the instructions carefully:Be familiar with the controis and the proper use of the equipment; b) never allow children or people unfamiliar with these instructions to use the lawnmower. Local regulations can restrict the age of the operator, c) never mow while people, especially children,or pets are nearby;...
Page 4: Product Specifications
and lift only the part which is away from the operator, p) do not start the engine when standing in front of the discharge chute; q) do not put hands or feet neat or under rotating parts. Keep clear of the discharge opening at all tines;...
Page 5: Safety Rules
IMPORTANT: This cutting machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.. WARNING: In order to prevent accidental starting when setting up, transporting, adjusting or making epairs, always disconnect spark plug wire.
Page 6: Assembly/Pre-Operation
 Be alert and turn machine off if children enter the area.  For wheeled rotary machines, mow across the face of slopes, never up and down.  Never allow children or people unfamiliar with these instructions to use the lawnmower. Local regulations can restrict the age of the operator.
Page 7: Operation
REMOVE LAWN MOWER FROM CARTON Roll lawn mower out of carton and check carton thoroughly for additional loose parts. INSTALL ATTACHMENTS Your lawn mower was shipped ready to be used as rear bag mower. SET UP YOUR MOWER INPORTANT: Unfold handle carefully so as not to pinch or damage control cables.
Page 8 ADJUST CUTTING HEIGHT Raise wheels for low cut and lower wheels for deep cut, adjust cutting height to suit your requirements. Medium position is best for most lawns. BEFORE STARTING ENGINE ADD OIL Before each subsequent use the oil level must be check and if necessary topped up with 500ml SAE30 engine oil.
Page 9 CAUTION: Alcohol blended fuels (called gasohol or using ethanol or methan can attract moisture which eads to separation and formation of acids during storage.Acidic gas can damage the fuel system of an engine while in storage.To avoid engine problems, the fuel system should be emptied before storage of 30 days or longer.
Page 10: Maintenance
 Keep top of engine around starter clear and clean of grass clippings and chaff. This will help engine air flow and extend engine life. MAINTENANCE IMPORTANT-Regular, careful maintenance is essential for keeping the safety level and original performance of the machine unchanged in time. 1)Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition.
Page 11 CHANGING BLADES To replace the blade, undo the screw. Empty the oil tank before removing the blade Blade ref. CC400P-18 Reinstall as illustrated . Tighten the screw properly. Tightening torque 45 Nm. When replacing the blade, the blade screw should also be replaced. .
Page 12 Air Filter Unclip the air filter cover and remove the sponge filter element. To avoid objects falling into the air intake, replace the air filter cover. FOAM ELEMENT AIR CLEANER COVER FOAM ELEMENT DRAINING THE FUEL TANK AND CARBURETOR 1.Place an approved gasoline container below the carburetor, and use a funnel to avoid spilling fuel. 2.Remove the drain bolt, then move the fuel valve lever to the ON position.
Page 13: Maintenance Schedule
MAINTENANCE SCHEDULE REGULAR SERVICE Before First Every 3 Every 6 Every Every Page PERIOD Each Month Months Months Year Years ITEM 5 Hrs 25 Hrs 50 Hrs or 250 Perform at every indicated month or operating hour interval, whichever comes first.
Page 14: Storage
ENGINE LACKS POWER Possible Cause Correction 1.check air cleaner Air cleaner elements clogged. Clean or replace air cleaner elements(p.9). 2. Check fuel Bad fuel;engine stored without Drain fuel tank treating or draining gasoline, of carburetor(p.5). Refuel with fresh refueled with bad gasoline. gasoline.
