4) Insert the threaded bar (G) into the structure (B).
E
N
5) Insert the cap (D) into the threaded bar (G). Insert the nut and tighten it.
G
D
G
6) Screw the cap cover (D) to the threaded bar (G). If the threaded bar is too short, hold
the foot (E) locked and unscrew the bar.
B
G
E
REPEAT STEPS FROM 3 TO 5 FOR THE ASSEMBLY OF THE SECOND LEG (C)
