S.R.Smith 900-6000-1 Installation & Maintenance Manual

Pool lift stability strap

Advertisement

Quick Links

POOL LIFT STABILITY STRAP
INSTALLATION &
MAINTENANCE MANUAL
S.R. SMITH, LLC
1017 SW Berg Parkway
Canby, OR 97013 USA
Phone: 503.266.2231 Fax: (503) 266-4334
Toll Free: 800.824.4387
www.srsmith.com
700- 5600
Rev 6.16.2016
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 900-6000-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for S.R.Smith 900-6000-1

  • Page 1 POOL LIFT STABILITY STRAP INSTALLATION & MAINTENANCE MANUAL S.R. SMITH, LLC 1017 SW Berg Parkway Canby, OR 97013 USA Phone: 503.266.2231 Fax: (503) 266-4334 Toll Free: 800.824.4387 www.srsmith.com 700- 5600 Rev 6.16.2016...
  • Page 2 FULLY FASTENED AND USED DURING EACH TRANSFER. PRODUCT OVERVIEW The Stability Strap Assembly is designed to secure the User in a S.R.Smith Lift Seat. The unit is constructed of high strength 4-Panel Nylon webbing and is UV and water resistant. It may be installed with the integral 6”...
  • Page 3 APPLICATION For use with S.R.Smith lift products which are fitted with a 1-Piece Lift Seat. The straps mount to existing mounting holes on rear side of the seatback. STABILITY STRAP ASSEMBLY The Stability Strap Assembly is comprised of two 2” wide Nylon webbed straps, a 27” long strap and a 32”...
  • Page 4 4. Insert a #10-24 Screw through the #10 Flat Washer. 5. Insert the Screw through the ¼” hole in the Strap grommet and tighten with a #2 Phillips screwdriver. Figure 3. View of 32” strap orientation on the seatback Not e: t his side does n ot have a 9”...
  • Page 5 2” W (5.1 cm) x 32” L (81.3 cm) Weight: Stability Strap Assembly < 0.5 lbs. (< 1 kg) with Hardware. PARTS LIST Part Number Description Quantity 900-6000-1 Stability Strap Set 800-0305 Screw - #10-24 Pan Head X .5 L 800-0315 Washer - #10 Fender 700- 5600...
