Page 1: Deck Profile Sheet Confirmation
POOL LIFT OWNER’S MANUAL & MAINTENANCE PROCEDURES S.R. SMITH, LLC CORPORATE HEADQUARTERS P.O. Box 400 • 1017 S.W. Berg Parkway Canby, Oregon 97013 USA Phone (503) 266 2231 • Fax (503) 266 4334 700-3000 6.21.2016... - Page 2 Aquatic access lifts are application specific. A completed Deck Profile Sheet helps to ensure the lift purchased for the application will work in accordance to ADA guidelines. S.R. Smith reviews all submitted Deck Profile Sheets as a service to our customers, free of charge. Before installing the pool lift, the installer must review and confirm the information provided on the Deck Profile Sheet.
-
Page 3: Table Of Contents
TABLE OF CONTENTS aXs EU/K DECK PROFILE SHEET CONFIRMATION ................ 1 INTRODUCTION ....................... 4 WARNINGS AND SAFETY SUMMARY ................5 PRODUCT OVERVIEW ....................5 aXs - PRODUCT COMPONENTS ................... 6 UNPACKING & ASSEMBLY INSTRUCTIONS ..............11 ... -
Page 4: Introduction
Intended Lift User: All of S.R. Smith’s lifts have been designed to assist anyone who has problems entering or exiting a swimming pool or spa - the only restriction is that the User does not exceed the weight limit of the product (300 lb/136 kg to 400 lb/181 kg depending upon model). -
Page 5: Warnings And Safety Summary
WARNINGS AND SAFETY SUMMARY DANGER – FAILURE TO FOLLOW THESE WARNINGS, INSTRUCTIONS AND THE OWNER’S MANUAL MAY RESULT IN SEROUS INJURY OR DEATH ADA GUIDELINE SUMMARY* (USA Only) 1009.2.1 Pool Lift Location Pool lift shall be located where the water level does not exceed 48”. If entire pool water level exceeds 48”, place pool lift where convenient. -
Page 6: Axs - Product Components
The aXs is powered by a 24 volt rechargeable battery. The lifting motion is provided by a screw driven electronic actuator and an electronic gear motor provides the turning motion. S.R. Smith has designed the safest possible lift system, following all instructions in the owner’s manual, and all product labels is necessary to achieve safe, reliable and proper performance of the lift and avoid injury. - Page 7 Base Assembly - Mounts to the pool deck contains the turning elements of the lift. Base Insert Stem - Slides into the anchor sleeve that is installed on the pool deck. Mast - The main vertical component of the lift. Actuator Arm - Primary lifting arm of the lift connects the mast to the seat arm and is raised by the attached actuator.
- Page 8 the service light is illuminated the lift must not be used until required maintenance is performed. Emergency Stop Button – In the event of an emergency, or if you need to stop lift movement immediately, pressing the Emergency Stop Button (red button on the control) will stop all lift movement. At the same time an audible alert will sound for 10 sec.
- Page 9 Loaded battery voltage in millivolts batt_volt_load,21487 Estimated battery capacity in % batt_capacity,99 Number of times charging was attempted charge_starts,8 Number of times charging was finished successfully charge_completes,1 Connecting Battery Pack 0,power_on,1 Inserting Activation Key 0,key_enable, Emergency Button pressed 2,alert_pressed, Emergency Button released 3,alert_released, Lift movement - up 8,lift_up,2...
- Page 10 The battery pack has an LED indicator near the plug-in-port. It will glow Red when first plugged into the transformer. If the LED remains Red this indicates the battery pack needs charging. When fully charged the LED will glow Green. If the battery is fully charged and is plugged into the transformer the LED will glow Red for approximately 10 sec.
-
Page 11: Unpacking & Assembly Instructions
It is important that any damage be noted on the Bill of Lading prior to signing for the delivery. Contact either S.R. Smith or your dealer immediately to notify us of any damage or missing parts. -
Page 12: Using The Axs Lift
15. Attach seat assembly with bolt and thumbnut in appropriate hole. For storage, seat can be attached facing inward for less space. 16. Attach foot rest to seat with bolts and thumbnuts. USING THE aXs LIFT Obey all User Instructions listed in the Owner’s Manual whenever using lift. Obey all Caution, Warning, Operating Instruction(s) and Labels located on the lift whenever using. -
Page 13: Transferring
aXs Transferring Diagram TRANSFERRING Once the unit is positioned for use, use the following procedure to transfer to the seat and into the water. Only persons healthy enough for water activities should use the aXs. Users should consult with their physician to determine if water activities are appropriate for the User: ... - Page 14 IN CASE OF HAND CONTROL FAILURE Lifting failure - In the event of a lifting failure, there are control buttons built into the control box. Press the appropriate up or down/left or right button located on the front panel of the control box. If the aXs will be used by a disabled person living on their own, a communication device should be installed in the area of use to call for assistance in the event of an emergency.
-
Page 15: Standard Accessories/Optional Accessories
Turning failure - If the lift will not turn electronically, remove the housing cover and locate the toggle clamp (red handle). Pull upward on the handle and rotate until the handle is horizontal. With the handle in the horizontal position, pull on the handle to rotate the assembly in the clockwise direction. This will disengage the gears and allow the lift to be turned manually. -
Page 16: Maintenance And Cleansing
Optional accessories may be purchased for your aXs lift through your Authorized Reseller. The following accessories are available: Console/Battery Cover – P/N 910-1000: Protects battery and control unit from exposure to moisture Total Cover - P/N AX9005: Made of weather resistant nylon material to keep unit protected from elements when not in use. -
Page 17: Trouble Shooting
Activate the up and down buttons on the hand control. If lift rotates, the problem is likely the hand control. If lift does not rotate, the problem is likely the 24v motor. 7. Contact your Authorized Reseller or S.R. Smith for replacement information. Does lift raise or lower? 1. -
Page 18: Long-Term Storage
2. Write down or take a photo of the serial # sticker from the product. S.R. Smith provides a serial # for every pool lift we produce. The sticker with the serial number can be found at the bottom of the mast near the base. -
Page 19: Dimensions/Capacity
1. Dimensions/Capacity Mast Height 32”/81 cm Height-Arm Raised 56.5”/143.5 cm Seat Width 23”/58.5cm Overall Length-extended 68.75”/174.6 cm Storage Length-w/o chair 47”/19 cm Unit Weight-inc. chair 81 lb/36.7 kg Unit Weight-w/o chair 68 lb/30.8 kg Power 24v DC Battery Life 30 cycles (approx.) Lifting Capacity 300 lb/136 kg Anchor Reaction Load... -
Page 20: Parts List
PARTS LIST Item # Part # Description AX5001 LA34 Actuator 1001499 4 Button Control 1001555 4 Button Control w/Activation Key (not shown) 1001495 Battery Pack 1001530 Battery Charger (not shown) 100-4000A Hand Control AX1430 Hand Control Hanger 120-1100 24v Motor 120-1800 Motor Cord w/ O ring (not shown) 100-3100... -
Page 21: Appendix - A
Appendix - A 700-3000 6.21.2016... -
Page 22: Appendix - B
Appendix - B 700-3000 6.21.2016...
