Grass Collection Systems
System Number: Description:
5600005
3 Bag System - 61" Mower Deck
5600006
3 Bag System - 61" Mower Deck
5600008
3 Bag System - 61" Mower Deck
5600009
3 Bag System - 61" Mower Deck
5600057
3 Bag System - 61" Mower Deck
5600060
3 Bag System - 61" Mower Deck
5600083
3 Bag System - 61" Mower Deck
OPERATOR'S
MANUAL
with Setup Instructions
FAST-Vac
61" Mower Decks
Fits Models: Serial Number Range:
IS3100ZL
IS3000Z
IS3000ZX
IS1000Z
IS4500Z
IS2000Z
S200X
IS3100Z
IS3100ZBS
IMPORTANT NOTE:
These FAST-Vac Systems fit
2005 and newer Model Year
product equipped with the rubber
discharge chute.
S/N: 3631 & Above
S/N: 2899 & Above
5103133
Rev E
