Page 1 MULTI PJ CAMERA Multifunctional Camera System Camera User’s Guide Thank you for purchasing this CASIO product. • Before trying to use this camera, be sure to carefully read Safety Precautions in the “ ” MULTI PJ CAMERA/Multifunctional Camera System YC-430 User’s Guide.
Page 2: Table Of Contents
CONTENTS INTRODUCTION About This Manual......9 Features ........9 Read this first! .
Page 3 SHOOTING A SNAPSHOT Holding the Camera Correctly ....49 Shooting a Snapshot......50 ■...
Page 4 ADVANCED SETTINGS Changing the Focus Mode ....96 ■ Using Auto Focus ■ Using Macro Focus ■ Using Fixed Focus (Pan Focus) ■...
Page 5 EDITING IMAGES Resizing a Snapshot ..... . . 140 Cropping a Snapshot ..... . 141 Keystone Correction .
Page 6 OTHER SETTINGS Configuring Camera Sound Settings ..171 Turning the Startup Screen On or Off ..173 Specifying the File Name Serial Number Generation Rule .
Page 7 APPENDIX General Guide ......221 Monitor Screen Contents ....223 Menu Reference .
Page 8 Getting the Most Out of Your Camera Snapshots Shooting with Optimum Setups ➞ USING BEST SHOT ......80 Portrait, Scenery, Night Scene, Night Scene Portrait, Children, etc Adding Special Effects ➞...
Page 9: Introduction
INTRODUCTION About This Manual This manual covers the stand-alone operation of the digital camera that is part of the CASIO MULTI PJ CAMERA/ Multifunctional Camera System. Features ■ BEST SHOT for beautiful shots simply by selecting a sample image built into the...
Page 10 ■ A powerful collection of useful recording features • Hand movement and subject movement reduction using high shutter speed (page 85) • High-sensitivity recording avoids dark images, even when the flash is not being used (page 87) • Quick Shutter for very high-speed focus (page 102) ■...
Page 11: Read This First
Note that CASIO COMPUTER CO., LTD. shall not be held liable for any misuse of this product that infringes on the copyrights of others or that violates copyright laws.
Page 12 CASIO COMPUTER CO., LTD. is forbidden under copyright laws. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or loss suffered by you or any third party due to the use or malfunction of this product.
Page 13: Precautions During Use
Precautions during Use ■ Take test shots before shooting the final shot. • Before shooting your final image, shoot a test shot to ensure that the camera is recording correctly. ■ Avoid Use While In Motion • Never use the camera to record or play back images while operating an automobile or other vehicle, or while walking.
Page 14: Display Panel
2. If you are using the AC adaptor to power the camera, unplug it from the wall outlet. If you are using battery power, remove the battery from the camera, taking care to protect yourself against burn injury. 3. Contact your dealer or nearest CASIO authorized service center. INTRODUCTION...
Page 15 2. If you are using the AC adaptor to power the camera, unplug it from the wall outlet. If you are using battery power, remove the battery from the camera. 3. Contact your dealer or nearest CASIO authorized service center. ■...
Page 16 • Never try to take the camera apart or modify it in any way. Doing so creates the risk of electric shock, burn injury, and other personal injury. Be sure to leave all internal inspection, maintenance, and repair up to your dealer or nearest CASIO authorized service center. ■...
Page 17 Doing so can damage the battery, and cause deterioration of its performance and loss of service life. • This battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life.
Page 18 – Never try to modify the AC adaptor or subject it to bending. – Do not twist or pull on the power cord. – Should the power cord or plug ever become damaged, contact your dealer or nearest CASIO authorized service center. INTRODUCTION...
Page 19 • Never touch the AC adaptor while your hands are wet. Doing so creates the risk of electric shock. • Misuse of the AC adaptor creates the risk of fire and electric shock. Make sure you observe the following precautions when using the AC adaptor.
Page 20: Battery Life
■ Data Error Precautions • Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory. – Removing the battery or memory card from the camera, or...
Page 21: Operating Environment
■ Operating Environment • The operating temperature range of the camera is 0°C to 40°C (32°F to 104°F). • Do not place the camera in any of the following locations. – In an area exposed to direct sunlight, or large amounts of moisture or dust –...
Page 22: Caring For Your Camera
■ Caring for your camera • Fingerprints, dirt, and other foreign matter on the lens surface can interfere with proper operation of the camera. Avoid touching the lens surface. To clean the lens surface, use a blower to blow off dust or foreign matter and then wipe with a soft, dry cloth.
Page 23: Getting Ready
GETTING READY Charging the Battery Your camera is powered by a rechargeable lithium ion battery (NP-40). IMPORTANT! • Use of any type of battery other than NP-40 is not supported. To load the battery Open the battery cover. While pressing the battery cover, slide it in the direction indicated by the arrow.
Page 24: To Charge The Battery
Close the battery cover. Swing the battery cover closed, and then slide it securely into place as you press it against the camera. The battery is not fully charged when you use the camera for the first time after purchasing it. Use the following procedure to charge it.
Page 25 With the camera positioned so the monitor screen is facing towards you as shown in the illustration, place it onto the USB cradle. The [CHARGE] lamp lights red and charging starts. • It takes about three hours to achieve a full charge. Actual charging time depends on current battery capacity, remaining power, and charging conditions.
Page 26 If an error still continues to occur after you perform the above steps, it could mean that the battery is faulty. Contact your nearest CASIO authorized service center. IMPORTANT! • Use only the bundled USB cradle to charge the special rechargeable lithium ion battery (NP-40).
Page 27 ■ Checking Remaining Battery Power As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below. Remaining High Power Battery Indicator Indicator Light Orange Color blue “ ” indicates that battery power is low. Charge the battery as soon as possible.
Page 28: Replacing The Battery
Replacing the Battery Open the battery cover. With the camera oriented with its monitor screen facing upwards as shown in the illustration, slide the stopper in the direction indicated by the arrow and hold it there. • This will cause the battery to come out part way. While still holding the stopper, pull the battery out the rest of the way.
Page 29: Turning Power On And Off
■ Storage Precautions • Though a rechargeable lithium ion battery provides high capacity in a compact configuration, long-term storage while charged can cause it to deteriorate. – If you do not plan to use a battery for some time, fully use up its charge before storing it.
Page 30 IMPORTANT! • Pressing [ON/OFF] or [ ] (REC) to turn on power also causes the lens to extend. Take care there is nothing pressing against or hitting the lens. Holding the lens with your hand so it cannot extend creates the risk of malfunction.
Page 31 Turning On Power for the First Time The first time you load a battery into the camera, a screen appears for configuring screen text language, date, and time settings. Use the procedure under “Configuring Display Language, Date, and Time Settings” in the “MULTI PJ CAMERA/Multifunctional Camera System YC-430 User’s Guide”...
Page 32: Using A Memory Card
Use [ ] and [ ] to select the sleep or Auto Power Off trigger time and then press [SET]. Selecting “Off” for the sleep setting disables the sleep feature. NOTE • Auto Power Off and sleep are disabled under the following conditions.
Page 33 Supported Memory Cards Your camera supports use of SD memory cards or MMCs (MultiMediaCard). Memory Used for Storage Images recorded while a memory card is loaded are saved to the memory card. When no memory card is loaded, images are saved in built-in memory.
Page 34: Loading A Memory Card Into The Camera
• Electrostatic charge, electrical noise, and other phenomena can cause data to become corrupted or even lost. Make sure that you always back up important data on other media (CD-R, CD-RW, MO disk, hard disk, etc.). Loading a Memory Card into the Camera IMPORTANT! •...
Page 35: Replacing The Memory Card
Load a memory card into the camera. Positioning the memory card so its front is facing upwards (towards the monitor screen side of the camera), slide it into the card slot all the way in until you hear it click securely into place.
Page 36: Formatting A Memory Card
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the battery, and contact your retailer or nearest CASIO authorized service center. • Never remove a card from the camera while the operation lamp is flashing green.
Page 37 Load the memory card you want to format into the camera. Turn on the camera and press [MENU]. On the “Set Up” tab, select “Format” and then press [ ]. Use [ ] and [ ] to select “Format” and then press [SET] to start formatting.
Page 38: Using On-Screen Menus
Using On-screen Menus The following are menu operations you will need to use to configure camera settings. Take a few moments to become familiar with them. • See “Menu Reference” on page 226 for information about menu contents. Example Menu Screen Tabs •...
Page 39: Configuring Monitor Screen Settings
Use [ ] and [ ] to select the item you want to configure and then press [ ]. Example: Select “Focus” and then press [ ]. Use [ ] and [ ] to select the setting you want. Apply the setting. •...
Page 40: Selecting A Screen Layout (Layout)
The following is the procedure for menu operations in the REC mode. In the REC mode, press [DISP]. This will display the display menu screen. Use [ ] and [ ] to select the setting you want. Use [ ] and [ ] to select the setting you want. •...
Page 41 Panel (Operation Panel) Image Size/Quality (page 54) Flash Mode (page 63) Focus Mode (page 96) Self-timer (page 68) Anti Shake (page 85) ISO sensitivity (page 110) White balance (page 107) EV shift (page 105) Date/Time (page 174) *1 Image quality cannot be changed using Panel (Operation Panel).
Page 42 IMPORTANT! • Panel (Operation Panel) is not displayed while Voice Recording or Zoom Continuous Shutter is being used. Normal ■ PLAY Mode Screen Layout The PLAY mode screen layout settings let you select how display images are shown on the monitor screen. Layout Type Description With this setting, 100% of the display image...
Page 43: Turning Display Information On And Off (Info.)
Layout Type Description With this setting, the display image is the maximum possible size that allows the entire image to be displayed horizontally. With some aspect ratios, the top and bottom of the image will be cut off. Wide Turning Display Information On and Off (Info.) With “Info.”...
Page 44 REC Mode (Layout: Panel (Operation Panel)) REC Mode (Layout: Normal) Show +Histogram Show +Histogram Hide Hide GETTING READY...
Page 45: Adjusting Monitor Screen Brightness (Brightness)
PLAY mode Show Hide Adjusting Monitor Screen Brightness (Brightness) +Histogram You can use the “Brightness” setting to adjust the brightness of the monitor screen. This setting is the same in the REC mode and PLAY mode. Brightness Setting Auto Description With this setting, the camera detects available light levels and automatically adjusts the brightness of the monitor screen accordingly.
Page 46: Adjusting Monitor Screen Image Quality (Type)
Brightness Description Setting Normal monitor screen brightness for indoor use, etc. Low monitor screen brightness for nighttime use, –1 indoor use under dark conditions, etc. Adjusting Monitor Screen Image Quality (Type) You can use the “Type” setting to adjust the quality of the monitor screen image.
Page 47: If You Lose Your Way
Quality Setting Description This setting provides a brighter screen image when shooting under dark conditions, and comes in handy when recording at night Night with a tripod. Note, however, that this setting can cause movement of objects on the monitor screen image to become rough. Consumes slightly less power than the other Power Saving settings, and extends battery life.
Page 48: Using The Camera On A Trip
PLAY mode To return to the normal playback Current Screen screen Menu screen [MENU] or [ Display Menu screen [DISP] or [ REC mode screen Press [ Press [ ]. You could also select Delete screen “Cancel” and then press [SET]. Using the Camera on a Trip Extra Batteries Taking along extra fully charged batteries (NP-40) is...
Page 49: Shooting A Snapshot
SHOOTING A SNAPSHOT Holding the Camera Correctly Holding the camera with one hand can result in accidental hand movement. Hold the camera securely with both hands when shooting snapshots. • To protect against accidentally dropping the camera, attach the wrist strap and make sure it is around your fingers or wrist while you are operating the camera.
Page 50: Shooting A Snapshot
NOTE • Good-looking images are impossible if you move the camera when you press the shutter button or while the Auto Focus operation is being performed. Holding the camera correctly, carefully press the shutter button and take care that you do not move the camera as the shutter releases.
Page 51 Focus the image. While the focus frame is aligned with the subject, half-press the shutter button. Auto Focus will focus the image automatically, and the focus frame and operation lamp will turn green. The shutter speed, aperture, and ISO sensitivity also will be set automatically.
Page 52: Using Quick Shutter
If the image does not focus... If the focus frame stays red and the operation lamp is flashing, it means that the image is not in focus (because the subject is too close, etc.). Point the camera at the subject and try to focus again.
Page 53: Monitor Screen Indicators
■ Monitor Screen Indicators The monitor screen uses various indicators and icons to keep you informed of the camera’s status. Remaining Shots Metering Image Size and Quality Digital zoom indicator Flash Mode Continuous Shutter Mode Focus Mode Self-timer Mode Anti Shake Indicator ISO Sensitivity White Balance Setting ISO Sensitivity...
Page 54: Changing The Image Size
Changing the Image Size A digital camera image is a collection of small dots (pixels). The size of an image indicates how many pixels it contains, and is expressed as horizontal pixels × vertical pixels. The initial factory default image size setting is 10M (3648 × 2736 pixels).
Page 55: Specifying Image Quality
• Selecting 3:2 (3648 × 2432 pixels) records images with an aspect ratio of 3:2, which matches the standard aspect ratio (3:2) of print paper. • VGA (640 × 480 pixels) is the optimum size when attaching images to e-mail. •...
Page 56: Turning Off The Af Assist Lamp
NOTE • The “Fine” setting helps to bring out details when shooting a finely detailed image of nature that includes dense tree branches or leaves, or an image of a complex pattern. Turning Off the AF Assist Lamp The AF assist lamp emits light that helps the camera focus when you half-press the shutter button under dark lighting conditions.
Page 57: Snapshot Shooting Precautions
In the REC mode, press [MENU]. On the “REC” tab, select “AF Assist Light” and then press [ ]. Use [ ] and [ ] to select “Off” and then press [SET]. When you want to turn on the AF assist lamp, select “On” here.
Page 58: Auto Focus Restrictions
■ Monitor Screen when Shooting Snapshots • The image that appears on the monitor screen is for image composition. The actual image will be recorded at the quality set for the image quality setting. • Subject brightness conditions can cause monitor screen response to slow and can cause digital noise in the monitor screen image.
Page 59: Shooting With Zoom
Shooting with Zoom Your camera provides you with 3X optical zoom (which changes the lens focal distance), which can be used in combination with digital zoom (which digitally process the center portion of the image to enlarge it) for total zoom capabilities of 12 - 45X. IMPORTANT! •...
Page 60 NOTE • Performing a zoom operation changes the lens aperture. • Use of a tripod is recommended to protect against hand movement when using the telephoto setting (zoom in). • Optical zoom is disabled while shooting a movie. Digital zoom only is available while shooting a movie. Make sure you select the optical zoom setting you want to use before you press the shutter button to start shooting your movie.
Page 61 Undeteriorated Image Quality Deteriorated Image Quality Range 3X to 17.1X Optical/Digital Switch Point Image Deterioration Point Image starts to deteriorate from here. (Point factor depends on image size.) • The image deterioration point depends on the image size (page 54). The smaller the image size, the higher the zoom factor you can use before reaching the image deterioration point.
Page 62: Using Instant Zoom
Using Instant Zoom Instant Zoom lets you jump to digital zoom telephoto with the press of a button. ■ Specifying the Instant Zoom Setting In the REC mode, press [MENU]. On the “REC” tab, select “Instant Zoom” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 63: Using Flash
IMPORTANT! • Performing an Instant Zoom operation after zooming an image with digital zoom will cancel the previous digital zoom operation. • Instant Zoom is not supported while “Timestamp” (page 115) is turned on. Using Flash Perform the following steps to select the flash mode you want to use.
Page 64 Approximate Flash Range (ISO Sensitivity: Auto) Wide Angle : 0.1 m to 3.6 m (0.3' to 11.8') Telephoto : 0.4 m to 1.9 m (1.3' to 6.2') • The flash range changes in accordance with optical zoom. In the REC mode, press [ ] ( [ ] ( Use [ ] and [ ] to select the flash setting you want and then press [SET].
Page 65 IMPORTANT! • When using flash, take Flash care that the flash window is not blocked by your fingers or the camera strap. • When the ISO sensitivity setting is “Auto” (page 110), sensitivity is high and there is increased digital noise when flash is used.
Page 66 ■ Checking the Flash Mode The current flash mode is indicated on the monitor screen and by the operation lamp when you half-press the shutter button. Operation Lamp Flashing Orange :Flash is charging. Lit or Flashing Green*:Flash charging is complete. Monitor Screen “...
Page 67: Using Flash Assist
■ Using Flash Assist The subject in an image will look too dark if flash intensity is not enough to reach a subject that is too far away. When this happens, you can use flash assist to supplement the brightness of the subject so it appears as if flash illumination was sufficient.
Page 68: Using The Self-Timer
■ Flash Precautions • The desired effect may not be obtained when the subject is too far away or too close. • Flash charging time depends on operating conditions (battery condition, ambient temperature, etc.) With a fully charged battery, it takes anywhere from a few seconds to 8 seconds. •...
Page 69 In the REC mode, press [MENU]. On the “REC” tab, select “Self-timer” and then press [ ]. Use [ ] and [ ] to select the self-timer type and then press [SET]. This causes an indicator identifying the selected self- timer type to appear on the monitor screen.
Page 70: Using Continuous Shutter
NOTE • The indicator “1sec” appears on the monitor screen between Triple Self-timer shots. How long it takes for the camera to get ready to shoot again after it shoots an image depends on the image size and quality settings, whether or not a memory card is loaded in the camera, and the flash charge condition.
Page 71: Selecting The Continuous Shutter Mode
Selecting the Continuous Shutter Mode In the REC mode, press [MENU]. On the “REC” tab, select “Continuous” and then press [ ]. Use [ ] and [ ] to select the mode you want and then press [SET]. This enables the continuous shutter mode you selected and displays its icon on the monitor screen.
Page 72: Recording With Zoom Continuous Shutter
Recording with Zoom Continuous Shutter Use [ ], [ ], [ ], and [ ] to move the selection boundary around the image of the subject on the left side of the monitor screen until it is located at the part you want to enlarge, and then press [SET].
Page 73: Continuous Shutter Precautions
Continuous Shutter Precautions • Starting a continuous shutter operation causes the exposure and focus settings to be fixed at the levels for the first image. The same settings are applied to all subsequent images. • Continuous shutter cannot be used in combination with the following BEST SHOT scenes: Business Cards and Documents, Whiteboard, etc., Old Photo, ID Photo, Pastel, Illustration, Cross, Movie.
Page 74: Adding Audio To A Snapshot
Adding Audio to a Snapshot You can add an audio recording to snapshots, if you want. Use this feature to add a verbal explanation or a description of the mood to a snapshot, or to capture the sounds of the people in the snapshot.
Page 75 Press the shutter button again to stop audio recording. Recording will stop automatically after about 30 seconds if you do not press the shutter button. • To turn off the audio snapshot feature, select “Off” in step 3 of the procedure under “Turning on Audio Snapshot”. Playing Back Snapshot Audio Audio snapshots in the PLAY mode are indicated by the “...
Page 76: Shooting A Movie
SHOOTING A MOVIE Movie Image Quality Before shooting a movie, you should specify a movie image quality setting. Movie image quality is a standard that determines the detail, smoothness, and clarity of a movie during playback. Shooting with the high-quality (HQ) setting will result in better image quality, but it also shortens the amount of time you can shoot.
Page 77: Shooting A Movie
Movie File Formats Movies are recorded in Motion JPEG standard AVI format. Movies you shoot with your camera can be played back on a computer using the following software. – Windows Media Player – Macintosh QuickTime In the REC mode, press [MENU]. On the “Quality”...
Page 78: Movie Recording Precautions
Press the shutter button again to stop shooting. Each movie can be up to 10 minutes long. Movie recording stops automatically after 10 minutes of recording. Movie recording also will stop automatically if memory becomes full before you stop movie recording by pressing the shutter button.
Page 79 • Shooting a very bright subject can cause a vertical band to appear in the monitor screen image. This does not indicate malfunction. The band will not be recorded in a snapshot, but will be recorded in the case of a movie. •...
Page 80: Using Best Shot
USING BEST SHOT With BEST SHOT, you simply select the sample scene that is like the one you are trying to shoot, and the camera sets up automatically. Even difficult backlit scenes (which result in the main subject being too dark if set up improperly) come out looking great! ■...
Page 81 Use [ ], [ ], [ ], and [ ] to move the boundary to select the scene you want to select. • Pressing [ ] or [ ] while the red boundary is at the edge of the screen will scroll to the next screen of BEST SHOT scenes.
Page 82 IMPORTANT! • Night Scene, Fireworks These scenes use slow shutter speeds. Since a slow shutter speed increases the chance of digital noise in the image, the camera automatically performs a digital noise reduction process on slow shutter images. Because of this, such images take longer to store after you press the shutter button.
Page 83 Displaying Detailed Information about a BEST SHOT Scene Though the name of each BEST SHOT scene is displayed as you move the selection boundary around the 15-scene selection screen, there may be times when you need more information about a scene’s setup.
Page 84 ■ Creating Your Own BEST SHOT Scenes You can use the procedure below to save the setups of snapshots that you shot as BEST SHOT scenes. After that, you can recall a setup whenever you want to use it. In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select “BEST SHOT”...
Page 85: Reducing The Effects Of Hand And Subject Movement
Deleting a BEST SHOT User Scene Perform the following steps when you want to delete a BEST SHOT user scene. In the REC mode, press [BS]. Slide the zoom controller towards [ ] to display its explanation screen. Use [ ] and [ ] to select the BEST SHOT user scene you want to delete.
Page 86 ■ Turning on Anti Shake Using the Menu In the REC mode, press [MENU]. On the “REC” tab, select “Anti Shake” and then press [ ]. Use [ ] and [ ] to select “Auto” and then press [SET]. • This turns on Anti Shake and displays “ monitor screen.
Page 87: Taking Bright Images Without Flash
Taking Bright Images without Flash The BEST SHOT “High Sensitivity” scene makes it possible for you to take natural looking images without using the flash, even when lighting is low Normal Snapshot (With flash) Snapshot with High Sensitivity In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select the “High Sensitivity”...
Page 88: Shooting Images Of Business Cards And Documents (Business Shot)
Shooting Images of Business Cards and Documents (Business Shot) Shooting a business card, document, whiteboard, or similarly shaped object from an angle can cause the subject to appear misshaped in the resulting image. The BEST SHOT Business Shot scenes correct the shape of rectangular objects so they appear natural.
Page 89 ■ Shooting an Image Using a Business Shot Scene After selecting either of the BEST SHOT Business Shot scenes, compose the image and press the shutter button to shoot. This displays a screen that shows all of the rectangular shapes in the image that qualify as candidates for keystone correction.
Page 90: Shooting Id Photographs
IMPORTANT! • Make sure the entire object you are trying to shoot (correct) is enclosed within the monitor screen. The camera will not be able to detect the shape of the object correctly unless it is enclosed entirely within the monitor screen. •...
Page 91 ■ Shooting an Image Using the ID Photo Scene On the monitor screen, compose the image by positioning the subject within the on-screen frame and then press the shutter button to shoot an initial temporary image. • The initial temporary image is not saved in memory. The final image is saved in memory when you perform step 3, below.
Page 92 When everything is the way you want, press [SET]. This saves the image in memory. IMPORTANT! • An ID photo is always saved as 5M (2560 × 1920 pixels), regardless of the camera’s current image size setting. ■ Printing an ID Photo Printing an ID photo image will print the same image in various sizes on a single sheet of paper.
Page 93: Restoring An Old Photograph
Restoring an Old Photograph With Old Photo, you can record the image of an old, faded photograph and then use the camera’s built-in advanced digital camera technology to restore it. ■ Before Recording with Old Photo • Make sure the entire photograph you are trying to record is enclosed within the monitor screen.
Page 94 ■ Recording an Image with Old Photo Press the shutter button to shoot the image. • This displays a photograph contour confirmation screen and then saves the original recorded image. An error message will appear (page 239), without displaying the photograph contour confirmation screen, if the camera is unable to find the contour of the photograph.
Page 95 Use [ ], [ ], [ ], and [ ] to move the cropping boundary to the location you want and then press [SET]. The camera will correct color automatically and save the corrected image. • If you do not want a border around the image, configure the cropping boundary so it is slightly inside of the boundary of the displayed image.
Page 96: Advanced Settings
ADVANCED SETTINGS Changing the Focus Mode Your camera provides you with the five focus modes described below. The initial factory default focus mode is Auto Focus. Focus Mode Description Auto Automatic focus when the shutter button is half-pressed. Focus During movie recording, the Auto Focus Mode is disabled and the camera switches to the Pan Focus Mode automatically.
Page 97 Perform the following steps to change the focus mode. In the REC mode, press [MENU]. On the “REC” tab, select “Focus” and then press [ ]. Use [ ] and [ ] to select the focus mode setting you want and then press [SET].
Page 98: Using Auto Focus
Using Auto Focus Align the monitor screen’s focus frame with the subject you want to focus and then half- press the shutter button. This camera will perform the focus operation. You can tell if the image is in focus by checking the operation lamp and the focus frame color.
Page 99: Using Macro Focus
Using Macro Focus Half-press the shutter button to focus the image. The focus operation is the same as that for Auto Focus. When the image is focused, press the shutter button the rest of the way to shoot. IMPORTANT! • Use of the flash along with Macro Focus can cause the light of the flash to become blocked, which can produce unwanted lens shadows in your image.
Page 100 Auto Focus and Macro Focus Shooting Tips Changing the Auto Focus Area Use the following procedure to change the metering area used for Auto Focus (AF). In the REC mode, press [MENU]. On the “REC” tab, select “AF Area” and then press [ ].
Page 101 Using Focus Lock “Focus lock” is the name of a technique you can use when you want to shoot an image in which the subject to be focused on is not within the focus frame in the center of the screen. •...
Page 102: Using Fixed Focus (Pan Focus)
Quick Shutter When Quick Shutter is turned on, the camera immediately shoots the image without waiting for Auto Focus to be performed when you press the shutter release all the way down. This helps to avoid missing a special moment while you wait for the camera to Auto Focus.
Page 103: Using Infinity Focus
Using Infinity Focus As its name suggests, Infinity Focus fixes focus at infinity ( Use this mode when shooting scenery and other faraway subjects. Infinity Focus also comes in handy when shooting from a car or train window, or when shooting scenery or other subjects that are difficult to focus properly with Auto Focus.
Page 104 Use [ ] and [ ] to focus the image, as you view the results on the monitor screen. At this time the image that is within the boundary will enlarge and fill the monitor screen, which aids in focusing. For this: Press this button: Closer focus...
Page 105: Correcting Image Brightness (Ev Shift)
Correcting Image Brightness (EV Shift) You can manually adjust an image’s exposure value (EV value) before shooting it. This feature helps to achieve better results when shooting a backlit subject, a strongly lit subject indoors, or a subject that is against a dark background. Exposure Compensation Value: –2.0EV to +2.0EV Unit: 1/3EV In the REC mode, press [MENU].
Page 106 After the EV value is the way you want, press [SET] to apply it. The exposure compensation value you set remains in effect until you change it. IMPORTANT! • When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even after performing exposure compensation.
Page 107: Controlling White Balance
Controlling White Balance Shooting on a cloudy day can give your subject a blue cast, while shooting under white fluorescent lighting can give your subject a green cast. White balance corrects for different types of lighting so the colors in your images always look natural. In the REC mode, press [MENU].
Page 108 NOTE • You can also use the Panel (Operation Panel) (page 40) to change the white balance setting. • When “Auto” is selected for the white balance setting, the camera automatically determines the white point of the subject. Certain subject colors and light source conditions can cause problems when the camera tries to determine the white point, which makes proper white balance adjustment impossible.
Page 109 Under the lighting conditions you plan to use when shooting, point the camera at a blank white piece of paper so it fills the entire monitor screen and then press the shutter button. The camera will adjust white balance settings for the current conditions, and display “Complete”...
Page 110: Specifying Iso Sensitivity
Specifying ISO Sensitivity ISO sensitivity is a value that expresses sensitivity to light. A larger value indicates higher sensitivity, which is better for shooting when available lighting is dim. If you want to use faster shutter speeds, you should use a higher ISO sensitivity value. Under certain conditions, a fast shutter speed in combination with a high ISO sensitivity setting can cause digital noise, which makes an image appear rough.
Page 111: Specifying The Metering Mode
IMPORTANT! • Using flash with high ISO sensitivity can cause problems with subjects that close to the camera. • “Auto” ISO sensitivity always is used for movies, regardless of the current ISO sensitivity setting. • You can use the key customization feature to configure the [ ] and [ ] buttons so they control the ISO sensitivity setting (page 119).
Page 112 Center Weighted Center weighted metering concentrates on the center of the focus area to measure light. Use this metering method when you want to exert some control over exposure, without leaving settings totally up to the camera. Spot Spot metering takes readings at a very small area.
Page 113: Using The Camera's Filter Effects
Using the Camera’s Filter Effects The camera’s filter feature lets you add color tints to your images as you shoot them. The color effect look just like what you would get by installing a color filter on the lens of the camera. In the REC mode, press [MENU].
Page 114: Controlling Color Saturation
Controlling Color Saturation Use the following procedure to adjust the saturation of colors in your images. In the REC mode, press [MENU]. On the “Quality” tab, select “Saturation” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 115: Date Stamping Snapshots
Date Stamping Snapshots You can have the snapshot’s recording date only, or date and time stamped in the lower right corner of the image. In the REC mode, press [MENU]. On the “Set Up” tab, select “Timestamp” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 116: Using The On-Screen Histogram To Check Exposure
Using the On-screen Histogram to Check Exposure The on-screen histogram that provides a graphic representation of the current exposure of the image. You can also display the histogram in the PLAY mode for information about the exposure levels of images. Histogram Select either the REC mode or the PLAY mode.
Page 117 ■ How to Use the Histogram A histogram is a graph that represents the lightness of an image in terms of the number of pixels. The vertical axis indicates the number of pixels, while the horizontal axis indicates lightness. You can use the histogram to determine whether an image includes the shadowing (left side), mid tones (center), and highlighting (right) to bring out sufficient image detail.
Page 118 A centered histogram indicates that there is good distribution of light pixels and dark pixels. This type of histogram results when the overall image is at optimal lightness, as shown in the nearby image. IMPORTANT! • Note that the above histograms are shown for illustrative purposes only.
Page 119: Other Useful Recording Functions
Other Useful Recording Functions The following functions are also available in the REC mode to help make your digital image more efficient and enjoyable. • Assign functions to the [ ] and [ ] keys • Display an on-screen grid for easy image composition •...
Page 120: Displaying An On-Screen Grid
In the REC mode, press [MENU]. On the “REC” tab, select “L/R Key”, and then press [ ]. Use [ ] and [ ] to select the function you want to assign and then press [SET]. After you assign a function, you can control its setting using the [ ] and [ ] keys.
Page 121: Displaying The Image You Just Recorded (Image Review)
Displaying the Image You Just Recorded (Image Review) When you purchase your camera, it is initially configured with the Image Review feature turned on. Image Review displays the image you just recorded so you can check it. In the REC mode, press [MENU]. On the “REC”...
Page 122: Using Mode Memory To Configure Power On Default Settings
IMPORTANT! • The icons listed below do not appear on the display while icon help is turned off. – Focus mode icon (page 96) – White balance icon (page 107) Using Mode Memory to Configure Power On Default Settings You can configure the camera so it saves certain settings in “mode memory”...
Page 123 In the REC mode, press [MENU]. On the “REC” tab, select “Memory” and then press [ ]. Use [ ] and [ ] to select the item you want to configure and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 124: Resetting The Camera To Its Initial Factory Defaults
*1 “On” restores the selected BEST SHOT scene when the camera is turned back on. “Off” exits BEST SHOT when the camera is turned off. *2 Optical zoom position only. IMPORTANT! • Turning the camera off while mode memory for the BEST SHOT mode is on will restore the settings of the BEST SHOT scene what was selected when you last turned off the camera.
Page 125 IMPORTANT! • The following are not initialized when you reset the camera (page 228). – Home Time setup – World Time setup – Adjust – Date Style – Language – Video Out ADVANCED SETTINGS...
Page 126: Viewing Snapshots And Movies126
VIEWING SNAPSHOTS AND MOVIES Viewing a Snapshot Use the following procedure to view snapshots on the camera’s monitor screen. Press [ ] to enter the PLAY mode. • This will display one of the snapshots in memory, along with some information about the settings used to shoot it. File Type Folder/File Names Image Size...
Page 127: Listening To The Audio Of An Audio Snapshot
Note that if you copy an image from another type of digital camera, only a rough image may be shown on the monitor screen.
Page 128: Viewing A Movie
Audio Playback Controls The following are the different operations you can perform while audio is playing. To do this: Do this: Fast forward or fast reverse Hold down [ ] or [ ]. playback Pause or restart playback Press [SET]. Adjust volume Press [ ] or [ ].
Page 129 Press [SET] to start playback. • The monitor screen will return to the selection screen in step 1 after the end of the movie is reached. To switch to the REC mode Press [ Movie Playback Controls To do this: Fast forward or fast reverse playback.
Page 130: Playing A Slideshow On The Camera
Playing a Slideshow on the Camera The slideshow feature lets you play the files stored in memory in sequence, automatically. You can configure the slideshow so it plays the files the way you want. In the PLAY mode, press [MENU]. On the “PLAY”...
Page 131 Effect (Select Use [ ] and [ ] to select the effect you a special want. • Pattern 1, 2, 3, 4: Applies preset effects in effect.) sequence. • Random: Applies preset effects (Pattern 1, 2, 3, 4) in random sequence. •...
Page 132 “Time” setting. • In image copied from a computer or an image recorded with a different type of digital camera may remain on the screen longer than the time specified by “Interval”. ■...
Page 133 Press the USB cradle’s [PHOTO] button to start the slideshow. The slideshow is performed in accordance with the settings you configured with the procedure on page 130. The camera will turn off automatically after the time you specified with the “Time” setting elapses. •...
Page 134: Viewing Camera Images On A Tv
Viewing Camera Images on a TV Use the procedure below to view snapshots and movies on a TV screen. • You need to use the USB cradle and the AV cable that comes with the camera to connect to a TV. Connect the USB cradle to a TV.
Page 135 To turn off the camera You can turn off the camera by doing either of the following. • Press the camera’s [ON/OFF] button. • Press the USB cradle’s [USB] button. IMPORTANT! • When connecting to a TV to display images, be sure to configure the camera’s [ ] (REC) and [ buttons for “Power On”...
Page 136 ■ Selecting the Screen Aspect Ratio and Video Output System You can use the procedure in this section to select either NTSC or PAL as the video output system. You can also specify an aspect ratio of 4:3 or 16:9. For this type of TV: Standard aspect ratio screen NTSC TV (Japan, U.S., and other countries)
Page 137: Zooming The Displayed Image
Zooming the Displayed Image Perform the following procedure to zoom the image currently on the monitor screen up to eight times its normal size. In the PLAY mode, and use [ ] and [ ] to display the snapshot you want to zoom. Slide the zoom controller towards Each press of this button...
Page 138: Using The 12-Image Screen
Using the 12-image Screen You can use the procedure below to display a screen that shows 12 images. Slide the zoom Selection Boundary controller towards This displays the 12-image screen with a selection boundary around the last image that was on the monitor screen.
Page 139 Use [ ], [ ], [ ], and [ ] to move the selection boundary to the date whose image you want to view and then press [SET]. This will display the first image recorded on that date. NOTE • The year and month on the calendar is displayed using the same format as you selected for the “Date Style”...
Page 140: Editing Images
EDITING IMAGES Resizing a Snapshot You can change the size of a snapshot and save the result as a separate snapshot. The original snapshot is also retained. You can resize a snapshot to any one of the following sizes. Image Size (Pixels) Print Size 2560 ×...
Page 141: Cropping A Snapshot
IMPORTANT! • Note that you cannot resize the following types of snapshots. – VGA (640 × 480 pixels) and smaller snapshots – Snapshots created using MOTION PRINT – Snapshots recorded with another camera • Resizing a snapshot shot with an aspect ratio of 16:9 or 3:2 will cause the left and right sides of the image to be cut off.
Page 142: Keystone Correction
Use the zoom controller to zoom, and [ ], [ ], [ ], and [ ] to move around the zoomed image to display the part you want to extract. Press [SET] to extract the displayed part and save it as a separate file. •...
Page 143 Use [ ] and [ ] to select the candidate you want to correct. Use [ ] and [ ] to select “Correct” and then press [SET]. • Select “Cancel” to exit the procedure without performing keystone correction. IMPORTANT! • If the original image is smaller than 2M (1600 × 1200 pixels) size, the new (corrected) version will be the same size as the original one.
Page 144: Using Color Restoration To Correct The Color Of An Old Photograph
Color of an Old Photograph Color restoration let you correct the old color of a photograph shot with a digital camera. This function is useful for correcting existing old photographs, posters, etc. • Performing color restoration on an image causes a new (restored) 2M (1600 ×...
Page 145 IMPORTANT! • If the original image is smaller than 2M (1600 × 1200 pixels) size, the new (restored) version will be the same size as the original one. • Note that you cannot correct the following types of images. – Movie images and the voice recording file icon –...
Page 146: Editing The Date And Time Of An Image
Editing the Date and Time of an Image Use the procedure in this section to change the date and time of a previously recorded image. This capability comes in handy when the current date and time are wrong due to the following reasons.
Page 147: Rotating The Displayed Image Of A Snapshot
IMPORTANT! • You cannot change the date of the following types of files. – Movies, Voice recordings – Images created with MOTION PRINT • The date and time stamped into an image using the Time Stamp feature cannot be edited (page 115). •...
Page 148: Editing A Movie On The Camera
When the displayed image is at the orientation you want, press [MENU]. IMPORTANT! • You cannot rotate the image of a protected snapshot. To rotate a protected snapshot, first remove its protection (page 162). • You may not be able to rotate the image of a snapshot recorded with another camera.
Page 149 IMPORTANT! • When you edit a movie, only the result is saved. The original movie is not retained. Once you perform an editing operation, you will not be able to undo it. • A movie that is shorter than five seconds cannot be edited. •...
Page 150 Use [ ] and [ ] to select “ Point Cut) or “ Cut” (From-Point Cut) and then press [SET]. • To cancel movie editing, select “Cancel” and then press [SET]. This will return to the paused movie playback screen. Use the following operations to select the frame (point) from...
Page 151 In response to the confirmation message that appears, use [ ] and [ ] to select “Yes” and then press [SET]. • To cancel movie editing, select “No” instead of “Yes” and then press [SET]. This will return to the paused movie playback screen.
Page 152 Use [ ] and [ ] to select “ (Point-To-Point Cut) and then press [SET]. • To cancel movie editing, select “Cancel” and then press [SET]. This will return to the paused movie playback screen. Use the following operations to select the frames (points) between which you want to cut the movie...
Page 153: Creating A Snapshot Of A Movie Frame (Motion Print)
When the frame where you want the second (To) cut point to be is displayed, press [ ]. In response to the confirmation message that appears, use [ ] and [ ] to select “Yes” and then press [SET]. • To cancel movie editing, select “No” instead of “Yes” and then press [SET].
Page 154 1-frame Snapshot This format creates a snapshot using the (VGA 640 × 480 selected movie frame only. pixels) In the PLAY mode, display the movie that contains the frame you want to use. Press [MENU]. On the “PLAY” tab, select “MOTION PRINT”, and then press [ ].
Page 155: Using Audio
USING AUDIO Adding Audio to a Snapshot The dubbing feature of your camera lets you add audio to a snapshot after you shoot it. A snapshot that includes audio (regardless of whether the audio was recorded on the spot or added later) is indicated by the “...
Page 156 ■ Re-recording Snapshot Audio IMPORTANT! • Note that you cannot restore the original audio once you delete or re-record the audio of a snapshot. In the PLAY mode, display the snapshot whose audio you want to re-record. Press [MENU]. On the “PLAY” tab, select “Dubbing” and then press [ ].
Page 157 IMPORTANT! • Take care that you do not Microphone block the camera’s microphone with your fingers while recording. • Good recording results are not possible when the camera is too far away from what you are trying to record. • You may not be able to record audio if remaining memory capacity is too low.
Page 158: Recording Audio Only (Voice Recording)
Recording Audio Only (Voice Recording) Voice Recording lets you record audio only, without a snapshot or movie. Using built-in memory only, you get up to about 24 minutes of Voice Recording. In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select “Voice Recording”...
Page 159 Press the shutter button again to stop audio recording and return to the screen in step 3. • Recording also will stop automatically if memory becomes full. • If you press [ON/OFF] (Power) or play [ the battery goes dead during recording will stop the recording operation and save anything you have recorded up to that point.
Page 160 ■ Playing Back Voice Recording Data Enter the PLAY mode, and then use [ ] and [ ] to display the Voice Recording file you want to play. “ ” is displayed in place of an image for a Voice Recording file.
Page 161: Managing Your Files
MANAGING YOUR FILES Files and Folders Your camera treats each snapshot, movie, and Voice Recording, as a separate file. You can delete, protect, and copy files as required. Files are grouped in folders that are created automatically by the camera. Files and folders have their own unique names, which are assigned automatically by the camera.
Page 162: Protecting A File Against Deletion
Protecting a File Against Deletion You can protect an important file to ensure that it cannot be deleted accidentally. IMPORTANT! • Note that even if a file is protected, it will be deleted if you perform the format operation (pages 36, 181). ■...
Page 163: Using The Favorite Folder
■ Protecting All Files in Memory In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Protect” and then press [ ]. Use [ ] and [ ] to select “All Files : On” and then press [SET]. This protects all files currently in memory. Press [MENU].
Page 164 ■ Copying a File to the FAVORITE Folder In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Favorites” and then press [ ]. Use [ ] and [ ] to select “Save” and then press [SET]. Use [ ] and [ ] to select the snapshot you want to copy to the FAVORITE folder.
Page 165 ■ Viewing Snapshots in the FAVORITE Folder In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Favorites” and then press [ ]. Use [ ] and [ ] to select “Show” and then press [SET]. Use [ ] and [ ] to scroll through the snapshots in the FAVORITE folder.
Page 166: Copying Files
Copying Files Files can be copied from the camera’s built-in memory to a memory card, or from a memory card to built-in memory. This makes it possible, for example, to perform the following steps and copy a file from your memory card to another person’s memory card.
Page 167 ■ Copying a Single File from a Memory Card to Built-in Memory With this procedure, files must be copied one-by-one. Load the memory card that contains the file you want to copy into the camera. Turn on the camera, enter the PLAY mode and then press [MENU].
Page 168: Deleting Files
DELETING FILES You can delete files you no longer need, or after you transfer them to your computer’s hard disk or print them. This frees up memory for new files. You can delete one specific file, or you can delete all files currently in memory.
Page 169: Deleting All Files
Deleting All Files In the PLAY mode, press [ ] ( Use [ ] and [ ] to select “All Files Delete” and then press [SET]. In response to the confirmation message that appears, use [ ] and [ ] to select “Yes”. •...
Page 170 Now you can repeat steps 5 and 6 to delete another FAVORITE folder snapshot, or you can exit this procedure by pressing [MENU] twice. ■ Deleting All FAVORITE Folder Snapshots In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Favorites” and then press [ ].
Page 171: Other Settings
OTHER SETTINGS Configuring Camera Sound Settings Your camera lets you configure the following sound settings. • Type of sound for shutter release and other operations • Volume level for shutter release and other operation sounds • Volume level for movie and Voice Recording playback ■...
Page 172 ■ Setting the Operation Tone Volume Level Press [MENU]. On the “Set Up” tab, select “Sounds” and then press [ ]. Use [ ] and [ ] to select “ Use [ ] and [ ] to specify the playback volume setting you want and then press [SET].
Page 173: Turning The Startup Screen On Or Off
Turning the Startup Screen On or Off You can configure the camera to display a startup screen of an image you recorded, whenever you turn it on. • The startup screen is not displayed when you turn on the camera by pressing [ ] (PLAY).
Page 174: Specifying The File Name Serial Number Generation Rule
Specifying the File Name Serial Number Generation Rule Use the following procedure to specify the rule that governs generation of the serial number used in file names (page 161). Press [MENU]. On the “Set Up” tab, select “File No.” and then press [ ].
Page 175 Use [ ] and [ ] to select “Home” and then press [ ]. Use [ ] and [ ] to select “City” and then press [ ]. Use [ ], [ ], [ ], and [ ] to select the area where your Home City is located and then press [SET].
Page 176: Using World Time
■ Changing the Date Format You can select from among three different formats for the date. Press [MENU]. On the “Set Up” tab, select “Date Style” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 177 Use [ ] and [ ] to select “City” and then press [ ]. • To configure the summer time setting, select “DST” and then select either “On” or “Off”. • Summer time is used in some areas to advance the current time setting by one hour during the summer months.
Page 178: Changing The Display Language
Changing the Display Language You can use the following procedure to select one of 10 languages for on-screen messages. Press [MENU]. On the “Set Up” tab, select “Language” and then press [ ]. Use [ ], [ ], [ ], and [ ] to select the setting you want and then press [SET].
Page 179: (Rec) And
Use [ ] and [ ] to select the setting you want and then press [SET]. When you want to connect to this type of device: Computer or a printer that supports USB DIRECT-PRINT (page 184) With this setting, the computer sees the camera as an external storage device.
Page 180 Use [ ] and [ ] to select the setting you want and then press [SET]. To configure both keys to do Select this setting: this when pressed: Turn on the camera Power On Turn on or turn off the camera Power On/Off Do not turn on the camera Disable...
Page 181: Formatting Built-In Memory
Formatting Built-in Memory Formatting built-in memory deletes any data stored in it. IMPORTANT! • Note that data deleted by a format operation cannot be recovered. Check to make sure you do not need any of the data in built-in memory before you format it. •...
Page 182: Printing
PRINTING Types of Printing There are three different methods you can use for printing images. Professional Print Service (page 183) Printing at Printing on a Printer (page 184) Home Printing with a Computer Take the memory card that contains the images you want to print to a professional print service.
Page 183: Using Professional Print Service
■ Printing Precautions • See the documentation that comes with your printer for information about print quality and paper settings. • Contact the manufacturer of your printer to find out if it supports PictBridge or USB DIRECT-PRINT, for new printer versions, etc.
Page 184: Using Your Printer To Print Images
Using Your Printer to Print Images If your printer is either of the types described below, you can use it to print without going through a computer. – Printer equipped with an SD memory card slot – Printer that support PictBridge or USB DIRECT-PRINT ■...
Page 185 Connect the USB cable that comes bundled with the camera to the USB cradle and your printer’s USB port. USB Cable (Bundled) USB Port A Plug • Also, connect the AC adaptor to the cradle and plug the adaptor into an electrical outlet. •...
Page 186 Use [ ] and [ ] to select “Paper Size” and then press [ ]. Use [ ] and [ ] to select a paper size and then press [SET]. • The following are the available paper sizes. 3.5" × 5", 5" × 7", 4" × 6", A4, 8.5" × 11", By Printer •...
Page 187: Using Dpof To Specify Images To Be Printed And The Number Of Copies
Use [ ] and [ ] to select “Print” and then press [SET]. Printing will start and the message “Busy... Please wait...” will appear on the monitor screen. The message will disappear after a short while, even though printing is still being performed.
Page 188 ■ Configuring DPOF Settings Individually for Each Image In the PLAY mode, press [MENU]. On the “PLAY” tab, select “DPOF” and then press [ ]. Use [ ] and [ ] to select “Select Images” and then press [ ]. Use [ ] and [ ] to scroll through the images until the one you want to print is on the monitor screen.
Page 189 ■ Configuring the Same DPOF Settings for All the Images In the PLAY mode, press [MENU]. On the “PLAY” tab, select “DPOF” and then press [ ]. Use [ ] and [ ] to select “All images” and then press [ ]. Use [ ] and [ ] to specify the number of copies.
Page 190: Date Stamping
IMPORTANT! • Some printers may ignore time stamp settings or may not support DPOF at all. Check the user documentation that comes with your printer for details. Date Stamping You can use any one of the following three methods to include the recording date in the printout of an image.
Page 191: Supported Protocols
• Specify date stamping with Photohands (Windows only) – See the Photohands User’s Guide for details. The Photohands User’s Guide is provided as a PDF file on the CD-ROM that comes bundled with your camera. • Request date stamping when ordering prints from a professional print service –...
Page 192: Exif Print
■ Exif Print Printing on a printer that also supports Exif Print (Exif 2.2) uses information about shooting conditions recorded with the image to enhance printed image quality. Contact your printer manufacturer for information about models that support Exif Print, printer upgrades, etc. PRINTING...
Page 193: Using The Camera With Acomputer
USING THE CAMERA WITH A COMPUTER What you can do Connecting the camera to a computer with the bundled USB cable provides you with the capabilities described below. View and You can use your computer to view camera store images* images and for long-term storage of images.
Page 194: Using The Camera With A Windows Computer
Using the Camera with a Windows Computer Install the required software in accordance with what you want to IMPORTANT! • Use of the bundled USB cradle is not supported with a computer running Windows 98, 98SE, Me, or previous version operating systems. Objective Install this software: •...
Page 195: Computer System Requirements
■ Computer System Requirements Computer system requirements are different for each of the applications. Be sure to check the requirements for the particular application you are trying to use. Note that the values provided here are minimum requirements for running each application. Actual requirements are greater, depending on the number of images and the sizes of the images being handled.
Page 196: Viewing And Storing Images On A Computer
Viewing and Storing Images on a Computer You can view and store images (snapshot and movie files) on your computer by connecting to the camera via its USB cradle. General Procedure 1) Use the USB cradle to connect the camera and computer (page 196).
Page 197 Connect the USB cable that comes bundled with the camera to the USB cradle and the USB port of your computer. USB Cable (Bundled) USB Port A Plug • Orient the USB plug so it correctly matches the shape of the USB port when you connect them.
Page 198 Press the USB cradle’s [USB] button. [USB] Camera-Computer Connection Pressing the cradle’s [USB] button puts it into the USB mode, which is indicated by the USB lamp lighting green. In this mode, your computer recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a removable disk.
Page 199 ■ Connecting the Camera to Your Computer after the First Time Since you need to configure menu settings only the first time you connect the camera to your computer, later connections are much simpler. Press the camera’s [ON/OFF] button to turn it off and then place the camera on the USB cradle.
Page 200 Double-click the file that contains the image you want to view. This displays the image. • For information about file names, see “Memory Folder Structure” on page 219. NOTE • An image that was rotated on the camera will be displayed on your computer screen in its original (unrotated) orientation.
Page 201 On the shortcut menu that appears, click “Copy”. Windows XP users: Click “Start” and then “My Documents”. Windows 2000 users: Double-click “My Documents” to open it. • If you already have a “DCIM” folder in “My Documents”, the next step will overwrite it. If you want to keep the existing “DCIM”...
Page 202: Managing Images On Your Computer
■ Removing the Camera from the USB Cradle Windows XP Users Press the USB cradle [USB] button. After making sure that the cradle’s USB lamp is not lit, remove the camera from the cradle. Windows 2000 Users Click card services in the task tray on your computer screen, and disable the drive number assigned to the camera.
Page 203 Click the Photo Loader “Read me” file and read its contents. • “Read me” files contain important information about installation, including installation conditions and computer system requirements. Click “Install” for Photo Loader. Follow the instructions that appear on your computer screen to install Photo Loader. •...
Page 204: Retouching, Reorienting, Or Printing Snapshots
On your computer, click “Start”, “All Programs”, “Accessories”, “System Tools” and then “System Information”. On the “Tools” menu, select “DirectX Diagnostic Tool”. On the “System” tab, check to make sure that the “DirectX Version” is 9.0 or higher. Click “Exit” to exit the DirectX Diagnostic Tool.
Page 205: Playing Movies
■ Installing Photohands Start up your computer and place the bundled CD-ROM into its CD-ROM drive. • Use the CD-ROM that has “Photohands” on its label. • Normally, this should cause the menu screen to appear automatically. If your computer does not display the menu screen automatically, navigate to the CD-ROM on your computer and then double-click the “MENU.exe”...
Page 206: Viewing User Documentation (Pdf) Files
Viewing User Documentation (PDF) Files Start up your computer, and place the bundled CD-ROM into its CD-ROM drive. • Use the CD-ROM that has “User’s Guide Included” on its label. • Normally, this should cause the menu screen to appear automatically.
Page 207: Using The Camera With A Macintosh
Using the Camera with a Macintosh Install the required software in accordance with what version of the Macintosh OS you are running and what you want to do. IMPORTANT! • PJ Camera Software cannot be used with Macintosh computers. Objective Install this software: Version •...
Page 208: System Requirements
■ System Requirements System requirements are different for each of the applications. Be sure to check the requirements for the particular application you are trying to use. Note that the values provided here are minimum requirements for running each application. Actual requirements are greater, depending on the number of images and the sizes of the images being handled.
Page 209: Viewing And Storing Images On A Macintosh
Viewing and Storing Images on a Macintosh You can view and store images (snapshot and movie files) on your Macintosh by connecting to the camera via its USB cradle. IMPORTANT! • Connection is not supported to a Macintosh running Mac OS 8.6 or lower, or Mac OS X 10.0.
Page 210 Connect the USB cable that comes bundled with the camera to the USB cradle and the USB port of your Macintosh. USB Cable (Bundled) USB Port A Plug • Orient the USB plug so it correctly matches the shape of the USB port when you connect them.
Page 211 Press the USB cradle’s [USB] button. [USB] Camera-Macintosh Connection Pressing the cradle’s [USB] button puts it into the USB mode, which is indicated by the USB lamp lighting green. In this mode, your Macintosh recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a drive.
Page 212 ■ Connecting the Camera to Your Macintosh after the First Time Since you need to configure menu settings only the first time you connect the camera to your Macintosh, later connections are much simpler. Press the camera’s [ON/OFF] button to turn it off and then place the camera on the USB cradle.
Page 213 IMPORTANT! • Do not leave the same image displayed on your Macintosh screen for a long time. Doing so can cause image “burn in”. NOTE • An image that was rotated on the camera will be displayed on your Macintosh screen in its original (unrotated) orientation.
Page 214 IMPORTANT! • Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or memory card. Doing so can cause problems with the camera’s image management data, which will make it impossible to play back images on the camera and can drastically alter remaining memory capacity.
Page 215: Managing Images On Your Macintosh
Managing Images on Your Macintosh If you are running Mac OS X, you can manage snapshots using iPhoto, which comes bundled with your operating system. If you are running Mac OS 9, install the Photo Loader application from the CD-ROM that comes with the camera. ■...
Page 216: Playing Movies
On the CD-ROM, open the “Manual” folder. • Use the CD-ROM that has “User’s Guide included” on its label. Open the “Digital Camera” folder and then open the folder for the language whose user’s guide you want to view. Open the file named “camera_xx.pdf”.
Page 217: Registering As A User
• Use the CD-ROM that has “Photo Loader” on its label. Open the “Photo Loader” folder and then open the “English” folder. Open “PhotoLoader_english”. Registering as a User Internet registration only is supported. Visit the following CASIO website to register: http://world.casio.com/qv/register/ Reading Files Directly from a Memory Card The method you should use to read files from a memory card depends on the type of computer you have.
Page 218: Memory Card Data
DCF is a system that defines both image file formats and the structure of the folders that store data. This makes it possible for a digital camera, printer, or other DCF-compliant device to display or print image data from another DCF device.
Page 219: Memory Folder Structure
■ Memory Folder Structure (DCIM Folder) DCIM (Recording Folder) 100CASIO (Image File) CIMG0001.JPG (Movie File) CIMG0002.AVI (Audio File) CIMG0003.WAV (Audio Snapshot Image File) CIMG0004.JPG (Audio Snapshot Audio File) CIMG0004.WAV (Recording Folder) 101CASIO (Recording Folder) 102CASIO FAVORITE * (FAVORITE Folder) (Recording File) CIMG0001.JPG (Recording File) CIMG0002.JPG...
Page 220: Handling Precautions
• Startup Screen File File for storing the startup screen image. This file is created when you specify an image for use as the startup screen image. ■ Supported Image Files • Image files shot with this camera • DCF-compliant image files Even if an image is DCF-compliant, this camera still may not be able to display it.
Page 221: Appendix
APPENDIX General Guide The numbers in parentheses indicate the pages where each part is explained. ■ Camera Front Shutter (page 51) [ON/OFF] (Power) (page 29) Flash (page 63) AF Assist/Self-timer Lamp (pages 49, 56, 68, 231) Lens Microphone (pages 78, 157) Back bkbl [DISP] Button (page 39)
Page 222 Bottom Battery/Memory Card Slots (pages 23, 34) Cradle Contact (page 25) Tripod Hole Use this hole when attaching to a tripod. Speaker (page 127) ■ USB Cradle Front Back Camera Contact (page 25) USB Lamp (pages 198, 211, 234) [USB] Button (pages 187, 198, 211) [PHOTO] Button (pages 133, 134)
Page 223: Monitor Screen Contents
Monitor Screen Contents The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes.
Page 224 ■ Movie Recording Mode Normal Panel (Operation Panel) Focus Mode (page 96) White Balance Setting (page 107) Recording Mode Remaining Movie Memory Capacity (page 77) Movie Image Quality (page 76) Exposure Compensation (page 105) Battery Level Indicator (page 27) Histogram (page 116) APPENDIX...
Page 225 ■ Snapshot Playback Mode blbk File Type (page 126) Flash Mode (page 63) Protect Indicator (page 162) Recording Mode Folder Name/File Name Battery Level Indicator (page 161) (page 27) Snapshot Image Quality Histogram (page 116) (page 55) Exposure Compensation Snapshot Image Size (page 105) (page 54) ISO Sensitivity (page 110)
Page 226: Menu Reference
Icon Help Icon Help provides you instant access to information about the icons that appear on the monitor screen in the REC mode. You can turn off icon help if you want (page 121). • Icon Help text is displayed for the following functions. Flash Mode, Metering, White Balance, Self-timer, EV Shift •...
Page 227 Quick Shutter On* / Off Audio Snap On / Off* Grid On / Off* Review On* / Off Icon Help On* / Off Memory BEST SHOT: On / Off* Flash: On* / Off Focus: On / Off* White Balance: On / Off* ISO: On / Off* AF Area: On* / Off Metering: On / Off*...
Page 228 Saturation +2 / +1 / 0* / –1 / –2 Contrast +2 / +1 / 0* / –1 / –2 Flash Intensity +2 / +1 / 0* / –1 / –2 Flash Assist Auto* / Off Set Up Tab Menu Sounds Startup* / Half Shutter / Shutter / Operation / Operation /...
Page 229: Play Mode
■ PLAY Mode PLAY Tab Menu Slideshow Start* / Images / Time / Interval / Effect / Cancel Calendar – MOTION PRINT 9 frames* / 1 frame / Cancel Movie Editing Cut (Before) / Cut (Between) / Cut (After) / Cancel* Keystone –...
Page 230: Display Menu Reference
Display Menu Reference The tables in this section show the items that appears on the menus that appear on the monitor screen when you press [DISP]. Most of these items are for configuring monitor screen settings. The items included on the menus depend on whether the camera is in the REC mode or PLAY mode.
Page 231: Indicator Lamps
Indicator Lamps The camera has lamps: an Operation Lamp and an AF assist/ self-timer Lamp. These lamps light and flash to indicate the current operational status of the camera. Operation Lamp AF assist/self-timer Lamp * There are three lamp flash patterns. Pattern 1 flashes once per second, Pattern 2 flashes twice per second, and Pattern 3 flashes four times per second.
Page 232 Assist/ Operation Lamp Self-timer Lamp Green Amber Pattern Cannot charge flash. Memory card problem / Memory Pattern card is unformatted. / BEST SHOT setup cannot be registered. Memory card is locked / Cannot create folder. / Memory is full. / Write error Pattern Low battery alert Pattern...
Page 233 ■ PLAY mode Assist/ Operation Lamp Self-timer Lamp Green Amber Pattern Pattern Operation Lamp Meaning Green Operational (Power on, recording enabled) Pattern One of the following operations is in progress: Delete, DPOF, protect, copy, format, resize, trimming, adding audio to snapshot, keystone correction, color correction, MOTION PRINT, movie editing,...
Page 234: Usb Cradle Indicator Lamps
■ USB Cradle Indicator Lamps The USB cradle has two indicator lamps: a [CHARGE] lamp and a USB lamp. These lamps light and flash to indicate the current operational status of the cradle and camera. [CHARGE] lamp USB Lamp [CHARGE] Lamp USB Lamp Color Status...
Page 235: Troubleshooting Guide
Troubleshooting Guide Find the Problem and Fixing It Problem Power does not turn 1) The battery is not oriented correctly. 2) The battery is dead. Camera suddenly 1) Auto Power Off activated (page 31). powers down. 2) The battery is dead. Image is not 1) Camera is in the PLAY mode.
Page 236 Problem Possible Causes The subject is out of The image is not focused properly. focus in the recorded image. The flash does not (Flash Off) is selected as the flash mode. fire. 2) The battery is dead. 3) A BEST SHOT scene that selects the flash mode is selected.
Page 237 Problem Possible Causes Digital zoom 1) The digital zoom setting is turned off. (including Instant 2) Date stamping is turned on. Zoom) does not work. The zoom bar indicates zoom only up to a zoom factor of 3.0. There is a vertical Shooting a very brightly lit subject can cause a vertical line on the monitor band to appear in the monitor screen image.
Page 238 If the same message appears after you turn power back on, contact your retailer or a CASIO service center. APPENDIX...
Page 239: Display Messages
This message appears and the camera turns off whenever lens performs some unexpected operation. If the same message appears after you turn power back on, contact your retailer or a CASIO service center. Load paper! The printer ran out of paper while printing. Memory Full Memory is full.
Page 240 Take action to remove the obstacle, and try turning on power again. SYSTEM ERROR Your camera system is corrupted. Contact your retailer or an authorized CASIO service center. The card is The LOCK switch of the SD memory card locked.
Page 241: Specifications
Specifications ■ Camera Functions Image Files Format ....Snapshots: JPEG (Exif Version 2.2); DCF (Design Rule for Camera File System) 1.0 standard; DPOF compliant Movies: Motion JPEG AVI format Audio: WAV Recording Media .
Page 242 Approximate Approximate Image Size Image Built-in Memory Image File (Pixels) Quality (8.0MB) Size Capacity Fine 1.17 MB 6 images (1600 × Normal 780 KB 9 images 1200) Economy 390 KB 17 images Fine 360 KB 20 images (640 × 480) Normal 240 KB 30 images...
Page 243 * Number of image values are approximate and are provided for reference only. * Based on Matsushita Electric Industrial Co., Ltd. products. The number of images you can save depends on the type of memory card you are using. * When using a memory card with a different capacity, calculate the number of images as a percentage of 256 MB.
Page 244 Exposure Control ..Metering: Multi-pattern, center weighted, and spot by imaging element Exposure: Program AE Exposure Compensation: –2EV to +2EV (in 1/3EV steps) Shutter ....CCD shutter, mechanical shutter Snapshot (Auto): 1/2 to 1/2000 second (with ISO 50) Snapshot (Night Scene):...
Page 245: Power Supply
Monitor Screen..2.8-inch TFT color LCD 230,400 (960 × 240) pixels Viewfinder ... . .Monitor Screen Timekeeping Functions . . .Built-in quartz digital clock Date and Time: Recorded with image data Auto Calendar: To 2049...
Page 246 *2 Continuous Playback Time Standard temperature (23°C (73°F)), one-image scroll approximately every 10 seconds *3 Approximate continuous recording time • The above values are based a new battery, starting from a full charge. Repeated charging shortens battery life. • Frequency of flash, zoom, and Auto Focus usage, and the time the camera is on greatly affects recording time and number of shots values.
Page 247: Usb Cradle
■ USB Cradle Input/Output Terminals . . .Camera contact; USB port; external power supply terminal; AV terminal (AV OUT: NTSC/PAL standards) Power Consumption ..5.0 V DC, Approximately 3.2 W Dimensions ... .107 (W) × 17 (H) × 58 (D) mm (4.2"(W) ×...
Page 248 CASIO COMPUTER CO.,LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA0704-A...

This manual is also suitable for:

Multi pj camera

Casio YC-430 PJ User Manual

Introduction

Getting Ready

Shooting a Snapshot

Shooting a Movie

Using Best Shot

Advanced Settings

Viewing Snapshots and Movies

Editing Images

Using Audio

Managing Your Files

Deleting Files

Other Settings

Printing

Using the Camera with Acomputer

Appendix

Quick Links

Related Manuals for Casio YC-430 PJ

Summary of Contents for Casio YC-430 PJ
