Akai AIR05W Manual

Hide thumbs Also See for AIR05W:
Table of Contents

Advertisement

Quick Links

Download this manual
WiFi Internet radio
User manual
Gebruiksaanwijzing
Manuel de l'utilisateur
Manual de instrucciones
Gebrauchsanleitung
Οδηγίες χρήσεως
Brugsanvisning
AIR05W
GB
2
NL 23
FR 44
ES 65
DE 86
EL 107
DA 128

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIR05W and is the answer not in the manual?

Questions and answers

Related Manuals for Akai AIR05W

Summary of Contents for Akai AIR05W

  • Page 1 WiFi Internet radio AIR05W User manual Gebruiksaanwijzing NL 23 Manuel de l’utilisateur FR 44 Manual de instrucciones ES 65 Gebrauchsanleitung DE 86 Οδηγίες χρήσεως EL 107 Brugsanvisning DA 128...

  • Page 2: Table Of Contents

    Table of contents Safety ................3 Intended use ..............3 Labels in this manual ............3 General safety instructions ..........3 Preparations for use ........... 4 Unpacking ................4 Package contents ............4 Installation ..............4 Remote control..............5 Connecting to the mains ..........6 Connecting to the Internet..........6 Connecting to a PC (Windows XP) ........7 Connecting to a Mac ............9 Registering the appliance ..........9...

  • Page 3: Safety

    AIR05W Safety Intended use The Wi-Fi Internet Radio plays music from Internet radio stations, shared folders on a PC or Mac and FM radio. The clock function includes an alarm and sleep program. Read the manual carefully before first use.

  • Page 4: Preparations For Use

    Preparations for use Unpacking ● Unpack the appliance carefully. ● Check the package contents as described below. If any item is missing, please contact your reseller. ● Remove the labels from the front panel carefully if present. We recommend that you retain the original carton and packing materials in case it ever becomes necessary to return your product for service.

  • Page 5: Remote Control

    AIR05W CAUTION ● Do not put the appliance near a heat source. ● Do not expose the appliance to direct sunlight. This appliance is equipped with rubber feet to prevent it from moving. The feet are made from non-migrating material specially formulated to avoid leaving any marks or stains on furniture.

  • Page 6: Connecting To The Mains

    Connecting to the mains ● Connect the female connector on the mains cable to the DC IN 9 V connection. ● Connect the mains plug to a wall socket. Connecting to the Internet A wireless access point (e.g. wireless router) is used to connect to the Internet. The wireless network is identified with an SSID, the name of the network.

  • Page 7: Connecting To A Pc (Windows Xp)

    AIR05W ● Navigate to NETWORK CONFIG and press the SELECT button (27). ● Navigate to ENTER NETWORK NAME and press the SELECT button (27). ● Enter the network name. Read the paragraph "General functions". ● If necessary, enter the password. Read the paragraph "General functions".
  • Page 8 ● Click the tab SHARING. ● Enable the option SHARE THIS FOLDER. ● Click PERMISSIONS. ● Select EVERYONE and click REMOVE. ● Click ADD. ● Click ADVANCED... and FIND NOW. ● Select the user account. ● Set the permissions and click OK. Connecting to a PC using a shared folder using accounts with no password ●...

  • Page 9: Connecting To A Mac

    AIR05W AIR05W Connecting to a Mac The appliance can use media files stored on a Mac. To access files stored on a Mac, Windows File Sharing must be activated. Setting up Windows File Sharing ● On the Mac, open SYSTEM PREFERENCES.

  • Page 10: Functions

    Functions Wi-Fi Internet Radio 10 11 ON/OFF button NEXT button STOP / P1 button PLAY/PAUSE / P2 button ALARM button Display SELECT button 10 Remote control sensor BACK button 11 VOLUME dial PREV button 12 Headphone jack...
  • Page 11 AIR05W AIR05W Display 34 SHIFT mode indicator 35 INTERNET indicator 36 MEDIA PLAYER indicator 37 INTERNET RADIO indicator 38 REPEAT indicator 34 35 36 37 38 39 40 41 42 39 SHUFFLE indicator 40 Wi-Fi strength indicator 41 ALARM indicator...

  • Page 12: Operation

    Operation All functions of the appliance are accessible using the remote control. All instructions refer to operation with the remote control, unless indicated otherwise. ● The appliance is designed to be operated using the remote control. For regular use you may find it convenient to switch the appliance to standby mode after use.

  • Page 13: Internet Radio Functions

    AIR05W AIR05W FM radio functions ● Switch on the appliance. ● Select the tuner mode. ● For extended instructions, read the paragraph "Radio functions" further on in this manual. Media player functions ● Switch on the appliance. ● Select the media player mode.

  • Page 14: Radio Functions

    Radio functions During playback, the following functions are available: ● Press the digit buttons to select a preset station (1-10). ● Press the SHIFT button (26) and the digit buttons to select a preset station (11-20). ● To select preset station 1 or 2, press the P1 button (2) or the P2 button (8) on the appliance.
  • Page 15 AIR05W ● If necessary, enter the account and the password. ● If necessary, browse in the shared folder by selecting BY ALBUM or BY ARTIST. Playing audio from shared media ● On the appliance, press the SOURCE button (14). ● Select the media player mode.

  • Page 16: Clock Functions

    Clock functions With the clock function, the following parameters can be set: - current time and date - alarm time (incl. alarm mode, snooze time) Setting the current time and date ● Press the MENU button (18). ● Select CONFIGURE. ●...

  • Page 17: Deactivating The Alarm

    AIR05W ● During a power failure, or when unplugging the appliance, the time settings are lost. Deactivating the alarm ● Press the MENU button (18). ● Select ALARM CLOCK. ● Select SET ALARM. ● Select the alarm. ● To deactivate the alarm, press the UP button (29) or the DN button (28) to select NO.

  • Page 18: Cleaning And Maintenance

    General setup page ● To navigate through the menu, press the UP button (29) or the DN button (28) or rotate the VOLUME dial (11). The following menu items can be set: - NETWORK CONFIG: to configure the network. - VERSION: to show the version information of the appliance. - UPGRADE FIRMWARE: to check automatically if new firmware is available.

  • Page 19: Troubleshooting

    AIR05W Troubleshooting Trouble Action No sound or Check if the correct source is selected. incomplete audio Check volume or mute setting. Check if the random equipment are switched on and set correctly. Check cables for connection problems. No power Check if the power cord has been properly connected to the power outlet.
  • Page 20 Media player Trouble Action Cannot find the PC Enable Global File Sharing. Check whether the PC is located in the same network. Check whether the PC has the same workgroup as the server managing the network. Check whether the wireless network is working properly. Check whether a firewall is not blocking any outgoing ports.

  • Page 21: Technical Data

    AIR05W Technical data Parameter Value Voltage Input voltage 100 ~ 240 V / 50 ~ 60 Hz Power consumption 12 W Max. power output 2 x 2 W (RMS) Radio bands Dimensions (W x H x D) 242 x 140 x 120 mm...

  • Page 22: Disposal Of Used Electrical And Electronic Equipment

    For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.akai.eu...
