  • Page 1 Ranger Camera-Back Transmitter and Receiver Quick Start Guide...
  • Page 2 PHYSICAL PROPERTIES Ranger TX A: Type N (V) connector Ranger RX B: Type N (H) connector C: 6-28V DC power input D: HDMI input E: SDI output F: SDI input G: USB port H: OLED display I: Menu joystick J: Network status LED...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Power and Connect ......3 DC Power Input Connector/Pin-Out ..4 Custom/3rd Party Power Cables ..4 Pairing ..........5 Mounting .......... 6 Mounting Array Antenna ....7 Array Antenna Receive Pattern .... 8 Transmitter Menu ......9 Receiver Menu .........11 Launchpad ........13 Launchpad App ........14...

  • Page 4: Power And Connect

    Connect the output from your video source to either the SDI or HDMI input (D or F) on the transmitter. Connect either the SDI or HDMI output (E or M) from the Ranger receiver to the video input on your monitor.

  • Page 5: Dc Power Input Connector/Pin-Out

    * Pin 1 is closest to the red dot on the connector CUSTOM/THIRD PARTY POWER CABLES • Test the power cable polarity with ONLY the power cable connected to Ranger. Do not connect video cables. • Check the power cable for shorts and proper grounding.

  • Page 6: Pairing

    PAIRING Ranger sets (TX and RX), are paired by default, requiring no additional configuration. Ranger devices purchased separately need to be paired using the device's front panel (OLED) menu, Launchpad, or the Launchpad App. NOTE: Before starting any pairing process, ensure that both the transmitter and receiver have the same firmware version and have Bluetooth enabled.

  • Page 7: Mounting

    Additionally, Ranger devices are equipped with a dual mount battery plate that allows you to attach your device to either the back of a camera, monitor, or Array Antenna.

  • Page 8: Mounting Array Antenna

    • Mount the Array Antenna vertically, keeping it clear of any obstructions. • Orient the transmitter and receiver so they are parallel to each other. • For best results, orient the Array Antenna so the front (with the Teradek logo) has a clear line−of−sight to the transmitter. • DO NOT OVERTIGHTEN...

  • Page 9: Array Antenna Receive Pattern

    ARRAY ANTENNA RECEIVE PATTERN The Array Antenna has a built-in directional antenna with a receive pattern that varies based on its distance from the transmitter. The horizontal receive angle measures 55° at 5,000 ft (1.5 km), 104° at 4,000 ft (1.25 km), and is effectively omni directional at up to 500 ft (150 m). The vertical receive angle measures 20°...

  • Page 10: Transmitter Menu

    Ranger App (pg. 10). • Wireless Settings - Configure the transmitter’s wireless settings. Enable Broadcast Mode - Broadcast Mode enables Ranger to extend its range when used with � the Array Antenna, and to transmit to an unlimited number of receivers (non-DFS channels only).
  • Page 11 • Pair - Pair your transmitter with another receiver. Once Pairing is activated on the transmitter, activate Pairing on the receiver. • Unpair - Unpair your transmitter and receiver. • Bluetooth Settings- Enable or disable Bluetooth communication. • Display Settings - Use the Display Settings to control the OLED display operation. By default, the OLED display will invert every 10 minutes.

  • Page 12: Receiver Menu

    • Switch TX - Select a different transmitter (paired transmitters only). • Wireless Settings - Configure the transmitter’s wireless settings. Enable Fixed Frequency - Fixed Frequency Mode allows your Ranger to designate a specific � non-DFS frequency range for use, providing a stronger connection in difficult environments.
  • Page 13 • Test Pattern - Select a video format to output a test pattern. Remove the test pattern by pressing left on the Menu joystick. • Audio Settings - Configure Ranger’s Audio settings. If Beep on REC is activated, you will hear a short tone whenever the camera begins or stops recording. The Mute Settings allow you to select between completely muting the audio, not muting the audio, or muting the audio while recording.

  • Page 14: Launchpad

    • Firmware versions - Displays the current firmware versions for all device components. LAUNCHPAD Launchpad allows you to configure, pair, and upgrade your Ranger device. Launchpad is available as software for Mac and Windows at www.teradek.com/pages/downloads. The following configuration options are available: •...

  • Page 15: Launchpad App

    Download Launchpad from the App Store. Navigate to the Bluetooth menu on both the transmitter and receiver, then select Enable (see pages 6-8). Open Launchpad from your iOS device, then tap the Ranger Devices button. Select the device you want to monitor.
  • Page 16 • Status - Displays the paired TX name, link status, current output resolution, frequency, camera recording status, and temperature. Teradek regularly releases new firmware versions to improve performance, add new features, or to fix vulnerabilities. Visit teradek.com to update your device with the latest firmware. NEED MORE HELP? SUPPORT: http://support.teradek.com →...
  • Page 17 © 2020 Teradek, LLC. All rights reserved.
