LED Description
Stream
Client
AP (Access Point)
WiFi
Encoder
Video
Button Operation
Mode Button
Hold for 1−2 seconds: Switches stream destination (when multiple
clients are connected).
Hold for 6−8 seconds: Toggles between AP mode and Infrastructure
mode (if configured).
Reset Button
Hold for 5 seconds: factory reset.

GETTING STARTED

iOS users − download the
1
TeraClip app.
Plug power and video into
2
Clip. Attach antennas.
B
C
D
E
Off
Not streaming
No clients
N/A
Not configured
Not encoding
No video
A:
Wireless Antenna
B:
Power Input
C:
Micro HDMI Video Input
D:
Mode Button
E:
Auxiliary Connector
A
F:
Stream Status Indicator
G:
Client Status Indicator
H:
Access Point Status Indicator
I:
Reset Button
J:
WiFi Status Indicator
K:
Encoder Status Indicator
L:
Video Status Indicator
F G H
Red/Yellow
Client not responding Streaming
N/A
Infrastructure Mode
2.4GHz
Restarting/no host
Video not supported
Connect iPad to Clip's network.
3
(WiFi SSID − CLIP−xxxx)
Open the TeraClip app.
4
I
J K L
Blue
AP Mode
• Solid: Client(s)
Connected
Infrastructure mode
• Blinking: Connecting
• Solid: Connected
AP Mode
5GHz
Ready/Encoding
Video sync
1
