- Page 1 1000 RX and TX Quick Start Guide...
- Page 2 PHYSICAL PROPERTIES Bolt 1000 LT - RX RP-SMA connectors Power status LED Video status LED Bolt 1000 LT - TX Link status LED Fault LED 3G-SDI or HDMI output 3G-SDI input Power input Power switch Mini-USB Reset button Menu joystick...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Power and Connect ......2 Device Operation ........2 Bolt Connector/Pin-Out ...... 4 Custom 3rd Party Cables ..... 5 Mounting ..........6 On-Screen Display (OSD) Operation .. 7 Bolt Manager ........8... -
Page 4: Power And Connect
POWER AND CONNECT Connect the output from your video source to the SDI input on the Bolt transmitter. Connect the SDI or HDMI output from the Bolt receiver to the video input on your monitor. NOTE: If mounted upright on a stand above the monitor, use a right-angle SDI adapter to relieve any strain caused by the weight of the cable, and to avoid damaging the SDI output’s internal connectors. -
Page 5: Bolt Connector/Pin-Out
BOLT CONNECTOR/PIN-OUT Bolt uses a 2−pin power connector Description * Pin 1 is closest to the red dot on the connector CUSTOM/THIRD PARTY CABLES • Test the power cable polarity with ONLY the power cable connected to Bolt. Do not connect video cables. •... -
Page 6: Mounting
MOUNTING Bolt has a 1/4”-20 threaded hole on the bottom for mounting the included light stand adapter or any other mounting accessory. Bolt LT receivers • Mount the Bolt transmitter vertically, keeping the can be mounted vertically on a light antennas clear of any obstructions. -
Page 7: On-Screen Display (Osd) Operation
ON-SCREEN DISPLAY (OSD) OPERATION Receiver Status Screens - Connect your receiver to a monitor and activate the OSD (On-screen display) by depressing the Menu joystick button (L), then cycle through screens by pressing the button up or down. Hide the status screen by pressing left. •... -
Page 8: Bolt Manager
Maximum Range. For complex, high contrast situations where artifacts are visible, select Maximum Quality. Teradek regularly releases new firmware versions to improve performance, add new features, or to fix vulnerabilities. Visit teradek.com to update your device with the latest firmware. - Page 9 © 2019 Teradek, LLC. All rights reserved. v 1.4...
