2750-93111 (903)
OWNER / OPERATOR MANUAL
BACKPACK BLOWER
EB6200
Thank you for purchasing a RedMax
WARNING
product.
Before using our blower, please read
The engine exhaust from this product
this manual carefully to understand the
contains chemicals known to the State
of California to cause cancer, birth
proper use of your unit.
defects or other reproductive harm.
Read this manual periodically.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EB6200 and is the answer not in the manual?

Questions and answers

Related Manuals for RedMax EB6200

Summary of Contents for RedMax EB6200

  • Page 1 2750-93111 (903) OWNER / OPERATOR MANUAL BACKPACK BLOWER EB6200 Thank you for purchasing a RedMax WARNING product. Before using our blower, please read The engine exhaust from this product this manual carefully to understand the contains chemicals known to the State of California to cause cancer, birth proper use of your unit.

  • Page 2: Safety First

    Instructions contained in warnings within this manual and warning seals marked with a symbol on the blower concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail.

  • Page 3: Table Of Contents

    SAFETY PRECAUTIONS · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2 OPERATOR USE OF BLOWER WORKING CONDITION AVOID NOISE PROBLEM AVOID CHANCES OF DAMAGE PARTS LOCATION &...

  • Page 4: Safety Precautions

    • Please check and follow the local regulations. OPERATOR • Refrain from operating the blower if you are tired, ill, or upset, or if you are under the influence of alcohol, drugs or medication. • Clothing attire should consist of long- sleeved shirt, long pants and proper protective equipment.

  • Page 5: Working Condition

    • Avoid using any accessory or attachment other than those bearing the RedMax mark for use with the blower. • When suspending a job or inspecting the blower, be sure to stop engine.

  • Page 6: Avoid Noise Problem

    • Keep operation area clear of all persons, particularly small children and pets. Injury may result from flying debris. • Avoid using the blower where stable footing and balance are not assured. • Never to touch the spark plug or plug cord while the engine is in operation.

  • Page 7: Parts Location & Specifications

    Parts Location & Specifications MODEL EB6200 Dimensions ( L x W x H ) Dry Weight Fuel Tank Capacity Engine Type Piston Displacement Air Filter Carburetor ( Diaphragm ) Ignition System Spark Plug Muffler Operating Engine Speed Fuel Consumption Air Volume (w/std Pipes)

  • Page 8: Fuel

    2-cycle engine use. Recommended mixing ratio is 32 : 1 or 50 : 1 with RedMax JASO/ISO Oil. • Do not mix fuels which have been left unused for a period of one month or more.

  • Page 9: Operation

    2.When the engine is cool, close the choke. 3.Set the throttle lever in 1/3 open position. 4.To start, hold the top of the blower firmly with your left hand. Pull the starter knob slowly until you feel it engage and then give it a vigorous strong pull.

  • Page 10: Maintenance

    AIR CLEANER • Never operate the blower without an air filter or with a deformed or broken filter element. • C h e c k the air cleaner every 25 hours of use or more frequently if used under dusty conditions.

  • Page 11: Muffler

    AIR INLET SCREEN IMPORTANT • Before operating the blower, check that the air inlet screen is attached in place, is free from any damage and is not clogged with dusts or obstacles. • Blowing air is taken in from the air inlet screen.

  • Page 12: Shoulder Strap

    Never install the strap with the flapped side inside, or the unit may fall from the operator, which could result in injury to the operator and/or damage to the unit. NOTE • Never use a blower which is not properly repaired or remodeled.

  • Page 13: Parts List

    [It is possible that some specific parts may be subject to change of their delivery term and list price within the limit of ten (7) years after the machine is discontinued. It is also possible that some parts may be available even after the limit of seven (7) years.] EB6200...
  • Page 14 Parts List : EB6200 Fig.1 CARBURETOR COMPONENTS Carburetor Ass’y P/NO. 2750-81000...
  • Page 15 EB6200 Fig.1 CARBURETOR COMPONENTS Key# Part Number Description 1850-81450 Body ass’y 3306-81380 Screen 3356-81310 Valve 1850-81270 Spring 1850-81220 Screw 3310-81250 3310-81230 Lever 1850-81490 Body 1850-81520 Cover 1751-81510 Pump 5500-81160 Washer 1881-81140 Swivel 1751-81130 Ring 1065-81410 Gasket 1065-81420 Diaphragm 1850-81470 Gasket...
  • Page 16 Parts List : EB6200 Fig.2 ENGINE GROUP...
  • Page 17 EB6200 Fig.2 ENGINE GROUP Key# Part Number Description 2750-12110 Cylinder 2750-12210 Gasket, base 2750-12130 Bolt 1484-13160 Insulator 2750-13130 Gasket 1460-13132 Gasket 0263-90535 Screw 2750-12510 Cover 2750-12520 Bolt 2756-15100 Muffler ass’y 1421-15120 Arrester 2750-15210 Gasket 2750-15160 Bolt 2750-15170 Bolt 2750-21100 Crankcase comp...
  • Page 18 Parts List : EB6200 Fig.3 BLOWER GROUP...
  • Page 19 EB6200 Fig.3 BLOWER GROUP Key# Part Number Description 2750-31110 Volute case 2750-31210 Volute cover 2750-31150 Screw 3490-11150 Elbow 07000-02095 O-Ring 2750-31420 Screw 3310-53331 2750-31310 Cover lnlet 2750-31150 Screw 1140-72231 Clamp 3407-16120 Screw 2750-31290 Tube 2750-31510 3407-12210 Bolt 2750-31612 Engine cover...

  • Page 20: California Emission Control Warranty Statement

    CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS THE CALIFORNIA AIR RESOURCES BOARD AND KOMATSU ZENOAH Co. ARE PLEASED TO EXPLAIN THE EMISSION CONTROL SYSTEM WARRANTY ON YOUR 1995 AND LATER LAWN AND GARDEN EQUIPMENT ENGINE. IN CALIFORNIA, NEW UTILITY AND LAWN AND GARDEN EQUIPMENT ENGINES MUST BE DESIGNED, BUILT AND EQUIPPED TO MEET THE STATE'S STRINGENT ANTI-SMOG STANDARDS.
  • Page 21 ALL OTHER PARTS EXCEPT ABOVE PARTS, FOR TWO (2) YEARS OF HOME USE [ ONE (1) YEAR FOR ANY OTHER USE ] FROM THE DATE OF ORIGINAL ANY DELIVERY OF THE MODEL EB6200 UNIT, THE COMPANY, THROUGH ANY RedMax DEALER, WILL REPAIR OR REPLACE, FREE OF CHARGE, FOR THE ORIGINAL PUSHCHASER, ANY PART OR PARTS FOUND TO BE DEFECTIVE IN MATERIAL AND/OR WORKMANSHIP.
  • Page 22 KOMATSU ZENOAH AMERICA INC. 1505 Pavilion Place Suite A Norcross, Georgia 30093...
