- Page 1 Link everything for cat’ s life. User Manual CATLINK AI Cat Litter Box - Scooper Pro Version Shanghai Catlink Intelligent Technology Co., Ltd...
-
Page 3: Table Of Contents
【Unpacking Operation】 【Packing List】 【Product Structure】 【Function Differences】 【Working Mode 】 【Protection Mechanism】 【Control Panel & Button Operation】 【Indicator Conditions】 【Wi-Fi Connection】 【Cat Litter Replacement】 【Product Cleaning and Attentions】 【Exception Dealing】 【Product Specifications & CATLINK Features】 【After-sale Service】 【Service Card】... -
Page 4: Unpacking Operation
【 Unpacking Operation】 Check whether the items are complete according to the 【Packing List】 (Page 3). Place the product properly according to the 【Product structure】 （Page 4） . Insert the power adapter into the power port at the back of the product. -----------------------------------------------------------------------------------------------------------please refer to picture 3.1 Check whether the waste bag is properly inserted, and properly push the waste box back to its original position.-----------------------------------------------------------------------------------------------please refer to picture 4.1... - Page 5 3） Make sure that the device is close to the Wi-Fi signal and far away from electrical appliances with strong interference.------------------------------------------------------------------------------please refer to picture 5.3 【Picture 5.1】 【Picture 5.2】 【Picture 5.3】 When the power is turned on, the device will automatically turn on and wait for the device to complete the self-check (the ball cabin will reset and stop after turning counterclockwise and clockwise each half a turn).
-
Page 6: Packing List
The litter box can be used normally when the above steps are completed. 【Packing List】 Activated carbon cotton filter The cotton filter has been placed in the waste box. Catlink recommends taking it out and shining it once a month and replacing it every two months. Power Roll... -
Page 7: Product Structure
【Product Structure】 Cover Ball Cabin Base Waste Box... -
Page 8: Function Differences
✓ Note: The ambient light function can be turned on through the CATLINK APP. When this function is turned on, the light will be automatically turned off during the day and the light will be turned on automatically at night. -
Page 9: Working Mode
【Working Mode】 Icon of App Mode Notifications Operation method &Control panel In this mode, if the device detects a cat's entering and leaving, it will Auto mode automatically clean the ball cabin once after the safe time has passed In this mode, you can start or pause the Manual Mode filter cat litter by manual Operation through APP... -
Page 10: Protection Mechanism
【Protection Mechanism】 Protective Priority Notifications function level Radar protection The radar protection will be activated when a moving object enters *Only supported the ball cabin, and the ball cabin will stop rotating; The ball cabin will by Pro version rotation again when the object is confirmed to leave. The ball cabin will stop rotating when an object larger than 1.5kg Protection enters the ball cabin and the gravity protection is activated;The ball... -
Page 11: Control Panel & Button Operation
【Control Panel】 Error Wi-Fi Panel lock indicator indicator indicator Auto mode Timer Mode Clean/Pause indicator indicator button Manual Mode Empty Mode Mode indicator indicator button 【Button Operation】 Mode button The mode will be switched in order from Auto, Manual, Timer, Empty in a cyclic manner each time you press the button. - Page 12 If you want to disable the panel locking, repeat the above-mentioned operations. If the Panel lock indicator is off, the panel locking is successfully disabled. Note: This key can also be turned on or off on CATLINK APP. Wi-Fi connection button Press and hold the Mode button and the Clean/Pause button.
-
Page 13: Indicator Conditions
【Indicator Conditions】 Lighting Indicator Notifications conditions The device is in the Auto mode. The device is available for cat to use and will sense the cat's Auto mode indicator Constantly on entering and leaving and operate automatically. The device is in the Manual mode. The device is available for a cat to use and needs to be Manual Mode indicator Constantly on... - Page 14 Lighting Indicator Notifications conditions Error indicator+ Fast flashing During anti-pinch protection Panel lock indicator Slow flashing During anti-blocking protection Lights off Not connected Wi-Fi indicator Constantly on Wi-Fi connection Flashing Connecting Lights off Not locked Panel lock indicator Constantly on Locked After the machine is powered on, certain lights on the control panel will always be on.
-
Page 15: Wi-Fi Connection
Note: Name of WiFi cannot contain Chinese, spaces, or special characters, so as not to affect the WiFi connection. Open the CATLINK to register and log in. Find and click "Add Device" -> "AI Litter Box" and follow the instruc- tions. - Page 16 Android users. If possible, please use other phones for network connection. After the network is successful- ly connection, log in to the CATLINK on your original phone and you can use it normally." "In the case of multiple confirmations that your operation is correct, but the network connection still fails, please contact after-sales assistance in time."...
- Page 17 Mode Manu Empty 【Picture 6.1】 【Picture 7.1】...
-
Page 18: Cat Litter Replacement
【Cat litter Replacement】 After the ball cabin is reset, take out the waste Short press the Mode button once until it box, seal and discard the waste cat litter, put switches to the empty mode on a new waste bag, and push the waste box back to its original position The ball cabin starts to rotate clockwise when a single short press of the Clean/Pause button... -
Page 19: Product Cleaning And Attentions
【Product Cleaning and Attentions】 Open the cover--------- Refer to the steps of 【Cat litter Take out the ball cabin (pay Replacement】 (Page 15) , and attention to remove the support- power off after the cat litter is ing rod of the rotating shaft on empty the back of the ball cabin) Take out the waste box and the cotton filter... - Page 20 Parts can be wiped with wet wipes ( contains After cleaning up, install a new cotton filter electronic parts and cannot be washed directly) back to the waste box, and follow the reverse steps to assemble the device properly...
-
Page 21: Exception Dealing
【Exception Dealing】 Operation Exceptions Operation steps method The device stops running due to Press the Clean/Pause button Cancel abnormal radar/weighing protection once by manual or full waste box Press the Clean/Pause button The device stops running due to the Cancel once anti-pinch function being triggered by manual... - Page 22 Operation Exceptions Operation steps method Empty the cat litter Power off and restart the device Put a 1.5kg object into the ball cabin after rotating the ball cabin, 1.5kg Inaccurate weighing data(Inaccura- Adjust the press and hold the Mode button, cies caused by the use environ- weighing release it after hearing two beeps,...
-
Page 23: Product Specifications & Catlink Features
【Health Ecosystem】 The device has function of multi-cat recognition, and the health report of each cat can be viewed in the Catlink App. Version: CATLINK AI Litter Box-Scooper(Luxury/ Standard/ Luxury Pro/ Standard Pro) CATLINK AI Feeder-ONE-Standard(Multiple Pets) CATLINK AI Water Fountain-PURE... - Page 24 Note: The Catlink AI Litter Box-Young does not have this function (It is not connected to the Internet) 【CATLINK equipment sharing】 The main account can share unlimited permissions to family members and friends, and they can control the device or view health reports through the APP.
- Page 25 In order to guarantee the rights and interests of overseas users and overseas exclusive agents, products that have not been purchased through official certification may not be connected overseas. Please be sure to purchase our products through formal form. Catlink AI Litter Box-Scooper Pro Health report on excretion...
- Page 26 CATLINK AI Feeder-ONE-Standard(Multiple Pets) Health report on diet...
- Page 27 Catlink AI Water Fountain-PURE Health report on drinking The CATLINK APP page will be updated from time to time. The actual report page may be different from the above picture. The above picture is for reference only.
-
Page 28: After-Sale Service
【After-sale Service】 According to China's national regulations, we will provide customers with a one-year free warranty service. After-sales service contact information in Mainland China 1.Customer service of your CATLINK 2.Tel Number of after-sale:(+0086)18117545826、 (+0086)18121136180 3.Mailbox of after-sale:customer@catlink.cn、 support@catlink.cn *For after-sales service in other regions, please contact your local dealer. -
Page 29: Service Card
【Service Card】 Dear CATLINK user, thanks for using CATLINK series products, please read the following warranty clauses carefully before using this product. 1. The warranty period of this product is: within one year from the date shown on the valid purchase certificate. - Page 30 【Service Card】 Name of user Tel of user Address of user Name of product Purchase date The way of buying Problem Description...
- Page 32 Link everything for cat’ s life. Shanghai Catlink Intelligent Technology Co., Ltd Company address: No.800 Naxian road, Pudong new district, Shanghai, China Company number: (+0086)021-50686520 Company mailbox: business@catlink.cn Company website: www.catlink.cn...
