- Page 1 HPA-DAC8 Dante Accessory Card ® 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 1 –...
-
Page 2: Key Features
® audio transportation over standard IP networks. The HPA Series 8-channel amplifiers come standard with eight balanced line inputs and an accessory slot to fit the HPA-DAC8. Dante input 1, and the analog balanced input levels are isolated from each other and ®... -
Page 3: Audio Applications
HPA-DAC8 Owner’s Manual Audio Applications When installed, the HPA-DAC8 converts the HPA Series amplifier into a digital audio network amplifier and makes the HPA Series amplifier the “go to” solution for a variety of applications including: • Restaurants • Government Facilities •... - Page 4 HPA-DAC8 Owner’s Manual HPA-DAC8 Card Installation Note: Accessory card installation must be done by a qualified technician. 1. Remove the HPA amplifier from the AC mains source. Note: In standby mode there are DC voltages present. The HPA amp must be removed from the AC mains source in order to prevent damage to the card or amplifier.
- Page 5 HPA-DAC8 Card Installation 1. It is important to set the input levels within the system to avoid clipping the amplifier input or the output HPA-DAC8 card. Note: The best way to prevent clipping the HPA-DAC8 (Dante receiver) is to place a limiter set for 0dB in the signal path prior to ®...
- Page 6 HPA-DAC8 Owner’s Manual Selecting the Router OR Network Switch – Important! It is extremely important when selecting a router or switch for the Dante network; not ® all routers or switches are the same. The size of the Dante network will influence which ®...
- Page 7 Dante transmitter product with good signal to noise ® ratio specification, such as 100dB or better. For instance, AtlasIED BlueBridge ® has a signal to noise ratio of 110dB. The noise is very low before it is amplified, assuring low noise out of the HPA amplifier.
- Page 8 HPA-DAC8 Owner’s Manual System Type 8 Input Dante Receiver Card for the HPA Series Amplifiers ® Connection Single RJ-45 Cable Quality CAT-5 Gain Settings None Indicators Ethernet Network Activity LED Green / Yellow Amplifier Interface 2 x 16 Pin HPA Amplifier Connections...
-
Page 9: Dimensional Drawings
HPA-DAC8 Owner’s Manual Dimensional Drawings 3.91" (99mm) 4.71" 1.83" (47mm) (120mm) 3.91" (99mm) 4.71" 4.71" (120mm) (120mm) 0.97" (25mm) 4.71" (120mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 9 –... - Page 10 HPA-DAC8 Owner’s Manual Notes: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 10 –...
-
Page 11: Limited Warranty
This warranty shall extend from the date of purchase for a period of three years on all AtlasIED products, including SOUNDOLIER brand, and ATLAS SOUND brand products except as follows: one year on electronics and control systems;... - Page 12 Service Should your HPA-DAC8 require service, please contact the AtlasIED warranty department through the online warranty claim process. Online Warranty Claim Processes Warranty submissions are accepted at: https://www.atlasied.com/warranty_statement where the type of return Warranty or Stock return can be selected.
