- Page 1 INSTALLATION INSTRUCTIONS LC372 SOUND REINFORCEMENT MODULE LC372SR SOUND REINFORCEMENT MODULE Installation Instructions REV: 10-12 DOC: 1307B...
-
Page 2: Important Safety Instructions
The integrated receiver of the LC372SR is a 30W amplifier with a 25V speaker line. It features two (2) RJ45 connectors for use with LC11CS or LC12DCS wall plate call switches and LC372M remote intercom microphone. These standard call switches provide four logic input functions as normal call, emergency call, lockdown acknowledge, and contractor defined (i.e. -
Page 3: Wireless Microphone
INSTALLATION INSTRUCTIONS LC372 SOUND REINFORCEMENT MODULE The LC372SR is powered via Ethernet cable from a LANcom power injector located near the device or in a remote tele- communications closet along with other data switch and distribution equipment. An internal fan and cabinet vents help keep the internal circuitry cool during operation. - Page 4 LC372SR SOUND REINFORCEMENT MODULE INSTALLATION INSTRUCTIONS CONNECTIONS LC372SR Sound Reinforcement Module LC372SR Figure 1 - LC372SR Front View IR RECEIVER INPUTS ETHERNET/ CALL SWITCHES HANDSET IED MIDSPAN REMOTE MIC INPUT INTERFACE SPKR LINE MUTEPOWER FORM C RELAY OUTPUTS AUX AUDIO INPUT...
- Page 5 6. Power and Network RJ45 Port This port is used to connect the LC372SR to the system network. It connects to the network through either an LC41PI or LC48MPI Power Injector that provides 48VDC power to the device. Note that power is provided only using the LC41PI or LC48MPI.
- Page 6 12. Relay Output Jack The LC372SR has four Form C relays that are terminated at this connector. Relays 1 and 2 provide a momentary contact closure used to synchronize the clock in the room to the system time. The exact time and duration for ETHERNET/ this closure is globally configured in the control software at the headend.
- Page 7 INSTALLATION INSTRUCTIONS LC372 SOUND REINFORCEMENT MODULE AL-MYNA Wireless Microphone The LC372SR includes two (2) AL-MYNA IR wireless microphones. Figure 5 - AL-MYNA 13. Microphone High quality internal microphone is used when the unit is in the handheld or lapel configuration.
- Page 8 26. Battery Cover Conceals two “AA” rechargeable batteries, IR channel switch and Lockout mode switch. AL-MYNA-NEST The LC372SR includes one (1) AL-MYNA-NEST charging station for the two (2) included AL-MYNA IR wireless micro- phones. Figure 6 - AL-MYNA-NEST 27. Microphone Charging Receptacles Holds the microphones in place while charging.
-
Page 9: Standard Installation
4 – Rubber Feet with Screws Standard Installation The LC372SR is supplied with four (4) removable rubber feet for standard installation on a shelf. Attach the rubber feet using the supplied screws as shown in Figure 7. Figure 7 - Rubber Feet Installation... - Page 10 Optional LC372WMK Wall-Mount Installation Kit The LC372WMK is available as an optional accessory used when installing the LC372SR on a wall or other flat surface. Attach the two mounting plates to the bottom of the unit as shown in Figure 9 using the screws supplied with the kit.
- Page 11 Optional LC372PMK Pole-Mount Installation Kit The LC372PMK is available as an optional accessory to mount the LC372SR on a pole of up to 2”. This is a convenient solution when mounting the device in a room that has a video projector suspended on a ceiling mount. This allows you to place the LC372SR on the mounting pole between the projector and the ceiling.
- Page 12 LC372SR SOUND REINFORCEMENT MODULE INSTALLATION INSTRUCTIONS Next, attach the mounting bracket as shown in Figure 12 using the supplied mounting screws. Insert the U-shaped pole brackets and attach the retaining nuts loosely as you will tighten them later. Figure 12 - LC372PMK Mounting Hardware Installation Slide the unit on the pole as shown in Figure 13 and tighten the U-shaped mounting clamps snugly to support the unit.
- Page 13 INSTALLATION INSTRUCTIONS LC372 SOUND REINFORCEMENT MODULE Connect Unit to Other System Components Connect the field devices to the LC372SR as required. Figure 14 illustrates a typical room installation. Note that all con- nections are not shown in the example illustration. LC12DCS...
- Page 14 The SCS Endpoint Configurator application provides access to all the necessary setup operations that must be performed on an LC372SR Sound Reinforcement Module before it can be used in a system. It also provides access to additional setup features, such as EQ, that are configured upon installation and not adjusted as part of normal system operation.
- Page 15 Figure 19 - Discovery Window The columns in the Discovery Window are described below. Type This displays the type of device that has been detected. LC372SR devices will be of type SRM. This is a read-only field and cannot be edited. MAC Address This is the hardware network address of the device.
- Page 16 INSTALLATION INSTRUCTIONS Most of the adjustments made to the LC372SR are made through the LANcom SCS software. EQ adjustments are not ac- cessible through the SCS software and must be made using the SCS Endpoint Configurator. First, highlight an LC372SR and then select the Edit sub-menu from the File menu as shown in Figure 20.
- Page 17 INSTALLATION INSTRUCTIONS LC372 SOUND REINFORCEMENT MODULE Center Freq. (HZ) Once you have selected a filter band, you can manually type in the frequency for the filter in this box. This allows you to quickly set the filter to a very precise value. When using one of the parametric bands, this frequency will control the center frequency of the filter.
-
Page 18: Specifications
LC372SR SOUND REINFORCEMENT MODULE INSTALLATION INSTRUCTIONS SPECIFICATIONS Mechanical Dimensions ..............8.50” W x 1.75” H x 13.625” D (215.9mm W x 44.5mm H x 346.1mm D) Mounting methods ........Desk/Table Top Surface Mount (Standard), Optional Pole Mount Kit, Rack Mount Kit or Wall Mount Kit Connectors Ethernet/Power ....................RJ-45... - Page 19 INSTALLATION INSTRUCTIONS LC372 SOUND REINFORCEMENT MODULE NOTES REV: 10-12 DOC: 1310B PAGE 18...
- Page 20 INSTALLATION INSTRUCTIONS LC372SR SOUND REINFORCEMENT MODULE Innovative Electronic Designs, LLC +1.502.267.7436 phone 9701 Taylorsville Road +1.502.267.9070 fax Louisville, KY 40299, USA www.iedaudio.com REV: 10-12 DOC: 1310B ©2012, Innovative Electronic Designs, LLC...
