- Page 1 BDCOM S2528-C Hardware Installation Manual...
-
Page 2: Table Of Contents
2.3.3 Cabinet Configuration......................6 2.3.4 Power Requirements......................7 2.4 Installation Tools and Device......................7 Chapter 3 Installing the BDCOM S2528-C Switch..................8 3.1 Installation Flow of BDCOM S2528-C................... 8 3.2 Installing the Machine Box of the Switch..................8 3.2.1 Installing the Machine Box on the Desk................8 3.2.2 Installing the Machine Box on the Cabinet................ - Page 3 Table of Contents 4.1 Opening the Machine Box......................14 4.2 Closing the Machine Box.......................15 Chapter 5 Hardware Fault Analysis......................16 5.1 Fault Separation..........................16 5.1.1 Faults Relative with Power and Cooling System............16 5.1.2 Faults Relative with Port, Cable and Connection............16 5.2 Indicator Description........................16 - II -...
-
Page 4: Chapter 1 Bdcom S2528-C Introduction
The section describes the characteristics and parameters of BDCOM S2528-C and gives an overview of BDCOM S2528-C. 1.1 Appearance Description for Standard Configuration The built-in ports of BDCOM S2528-C are: 24 gigabit TX ports and 4 GSFP. See table 1-1. Table 1- 1 Attributes of the built-in port... -
Page 5: Bdcom S2528-C Systematic Characteristic Parameters
Gigabit optical port GSFP 4 GSFP interfaces 25S-28S Figure 1- 2 Back template of the BDCOM S2528-C switch Table 1- 3 Parts at the back template of the BDCOM S2528-C switch Abbrev. Name Description Grounding column The grounding must be fine. - Page 6 BDCOM S2528-C Hardware Installation Manual Power characteristics input voltage: AC100～240V, input frequency: 50～60Hz Power consumption 21W (Max) - 3 -...
-
Page 7: Chapter 2 Installation Preparation
Similar to other electronic products, the semiconductor chip easily gets damaged if you power on or off abruptly and frequently. To restart up the switch of BDCOM S2528-C, you have to open the power on-off after the power is cut down for three to five seconds. -
Page 8: Safety Principles For Live Working
BDCOM S2528-C Hardware Installation Manual Read the installation guide carefully before you operate the system. Only professionals are allowed to install or replace the switch. Pull out the AC power socket and close the direct-current power before ... -
Page 9: Electrostatic Discharge Damage Prevention
BDCOM S2528-C Hardware Installation Manual D. Seek for medical help, or judge the loss and seek for available help. 2.2.4 Electrostatic Discharge Damage Prevention Electrostatic discharge may damage devices and circuits. Improper treatment may cause the switch to malfunction completely or discontinuously. -
Page 10: Power Requirements
2.4 Installation Tools and Device The tools and devices to install the BDCOM S2528-C switch are not provided by the BDCOM S2528-C switch. You yourself need to prepare them. The following are... -
Page 11: Chapter 3 Installing The Bdcom S2528-C Switch
Installing the machine box on the desk Installing the machine box on the cabinet 3.2.1 Installing the Machine Box on the Desk The BDCOM S2528-C switch can be directly put on the smooth and safe desk. Note: - 8 -... -
Page 12: Installing The Machine Box On The Cabinet
The rate of the console port is 9600bps. It has a standard RJ45 plug. After you connect the console port to the serial port of PC through a console cable, you can configure and monitor the switch of BDCOM S2528-C by running the terminal emulation software, such as super Windows terminal. The cable is provided according to the host. - Page 13 Otherwise, the single-pass problem will arise on the super terminal. The cable is used to connect the console port of the BDCOM S2528-C switch and the outside console terminal device. One end of the cable is a 8-pin RJ45 plug and the other end is a 9-hole plug (DB9).
-
Page 14: Connecting Gsfp Ports
BDCOM S2528-C Hardware Installation Manual 3.3.2 Connecting GSFP ports BDCOM S2528-C provides 4 gigabit GSFP ports, and their corresponding indicators are 25S~28S . The ports can connect other GSFP modules through the fiber to other Ethernet terminal devices. Figure 3-5 Connecting the 1000M Base-TX port and other Ethernet terminals 3.3.3 Connecting Ethernet TX Ports... - Page 15 BDCOM S2528-C Hardware Installation Manual Because 24 10/100/1000 Base-T ports of BDCOM S2528-C support the MDI/MDIX auto-identification of the cable, BDCOM S2528-C can adopt five classes of direct-through/cross network cables when it connects other Ethernet terminals. Figure 3-7 Connecting the 1000 Base-TX port and other Ethernet terminals...
-
Page 16: Checking After Installation
BDCOM S2528-C Hardware Installation Manual 3.4 Checking after Installation Before electrically starting up the switch, perform the following checkups after the switch is installed: If the switch is installed on the cabinet, check whether the installation point between the cabinet and the switch is strong. If the switch is installed on the desk, check whether there is enough space for the switch to discharge its heat and whether the desk is stable. -
Page 17: Chapter 4 Maintaining Switch
BDCOM S2528-C Hardware Installation Manual Chapter 4 Maintaining Switch Caution: Before opening the machine box, make sure that you have released the static you carried and then turn off the power on-off of the switch. Before operating any step in Appendix B, read the section “Safety Advice”. -
Page 18: Closing The Machine Box
BDCOM S2528-C Hardware Installation Manual When the cover is opened, put it aside. The mainboard of the system appears. Note: After taking off the cover, put it horizontally and avoid it to be crushed or collided. Otherwise, the machine box is hard to install. -
Page 19: Chapter 5 Hardware Fault Analysis
9600 bps, eight data bits, no sum check bit, one stop bit and no traffic control. 5.2 Indicator Description The following table shows the indicators of the BDCOM S2528-C switch and their description: - 16 -... - Page 20 BDCOM S2528-C Hardware Installation Manual Abbrev. Name Description When the indicator is always on, the system is being started System indicator When the indicator flickers, the system works well. When the switch is powered on, Power indicator the indicator is on.
