WARNING:
IMPROPER INSTALLATION OR
SWINGING ON THE RING MAY
60
CAUSE SERIOUS INJURY OR
MIN
DEATH
Notice to assemblers:
All the basketball systems, including those used for display purposes must be assembled and filled with weight
according to instructions. Failure to follow instructions could result in serious injury. Please read all warnings and
cautions before assembly. It is recommended to supervise children as they play with this product. This product is to
be assembled by 2 adults only!
We appreciate your purchase of one of our many fine products. We are assured that you will be very satisfied with
your selection.
READ AND SAVAE THIS INSTRUCTION FOR FUTURE USE
ASSEMBLY & INSTRUCTION MANUAL
Advertisement
Table of Contents
Related Manuals for HOMCOM A61-024
Summary of Contents for HOMCOM A61-024
- Page 1 INaia004_UK A61-024 WARNING: IMPROPER INSTALLATION OR SWINGING ON THE RING MAY CAUSE SERIOUS INJURY OR DEATH Notice to assemblers: All the basketball systems, including those used for display purposes must be assembled and filled with weight according to instructions. Failure to follow instructions could result in serious injury. Please read all warnings and cautions before assembly.
- Page 2 WARNING Moving the system • The system should be moved by at least 2 adults capable of handling its weight. • Children should not be allowed to move the system • Stand in front of the system and pull the pole forward until the system is balanced on its wheels. Move the system to the desired location and carefully set the base down WARNING!! FAILURE TO COMPLY WITH THESE WARNINGS COULD RESULT IN INJURY.
- Page 3 1.Boardx1 2.Ringx1 3.Netx1 4.Board Bracket x1 5.Boltx2(M8×35mm) 6.Nutx4 7.Boltx2(M8x16mm) 8.Boltx6(M10x85mm) 9.Nutx2 10.Capx1 11.TopPolex1 12.Middle Polex1 13.Bottom Pole×1 14.Basex1 15.Whteel Shaftx1 16.Wheelx2 17.Boltx1 (M8x90mm) 18.Nutx1 19.Pole Bracex2 20.Boltx2(M8x20mm) 21.Nutx2 24.Boltx2(M8x110mm) 25.Spring washerx2 26.Spring x2...
- Page 4 Assembly Steps 1 .Open the carton, find out all the parts listed on page 3, two adults are required for assembly. 2.Fix ring(2)and board bracket( 4)on board( I )by bolts(5)(24)and nuts(6). After that,use bolts(7) to fix the top of board bracket( 4 )on the back of board( I )tightly.Insert top pole(l l)into board bracket(4),fix them by bolts(8)and nuts(9).
