User's manual
LIFAN 2-cylinder Petrol Engine
92453
Illustration similar, may vary depending on model
Please read and follow the operating instructions and safety information prior to initial operation.
Technical changes reserved!
Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further
developments.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WilTec LIFAN 92453
Summary of Contents for WilTec LIFAN 92453
- Page 1 User’s manual LIFAN 2-cylinder Petrol Engine 92453 Illustration similar, may vary depending on model Please read and follow the operating instructions and safety information prior to initial operation. Technical changes reserved! Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further developments.
- Page 2 The information contained in this document may alter at any time without prior notice. No part of this document may be copied or otherwise duplicated without prior written consent. All rights reserved. WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating man- ual, nor in the diagrams and illustrations shown.
- Page 3 № Name № Name Air filter Attachment element Choke Oil screw Starter handle Oil level gauge Drain screw Throttle lever Oil filter Exhaust Spark plug © by WilTec Wildanger Technik GmbH Item 92453 Page 3 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 4 Batteries contain sulphuric acid (electrolyte). Any contact with your skin or eyes can cause se- • rious injuries. Wear suitable protection clothing. Contact the furnisher of the battery used to read up on suitable measures. © by WilTec Wildanger Technik GmbH Item 92453 Page 4 http://www.WilTec.de http://www.aoyue.eu...
- Page 5 Name № Name Oil level gauge Min. oil level Max. oil level № Name № Name Fuel tank Red marking for max. fuel level Tank opening © by WilTec Wildanger Technik GmbH Item 92453 Page 5 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 6 The air filter is to be checked and, if necessary, to be cleaned or replaced regularly. START Inclination of output shaft Allowable inclination ≤20° Inclination of engine Allowable inclination ≤20° © by WilTec Wildanger Technik GmbH Item 92453 Page 6 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 7 The motor should not be charged within the first 1–3 min after starting. № Name № Name Choke Carburettor drain screw Choke not activated On/off switch № Name № Name Ignition to off position Ignition switch © by WilTec Wildanger Technik GmbH Item 92453 Page 7 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 8 The exterior of the engine should be cleaned of dirt entirely. The air filter and spark plug should be re-checked and replaced, if necessary, or cleaned/re-adjusted. © by WilTec Wildanger Technik GmbH Item 92453 Page 8 http://www.WilTec.de...
- Page 9 Ignition sensor Clean. Idling Check, adjust. Play of valves Check, adjust. Oil filter Replace. Petrol filter Clean. Fuel supply Check. After 2 years (replace if necessary) line © by WilTec Wildanger Technik GmbH Item 92453 Page 9 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 10 18.4 hp / 13.5 kW / 3600 ⁄ Max. torque 43.5 Nm / 2500 ⁄ Ignition system Transistor/magneto ignition (TCI) Fuel consumption ( ⁄ ≤370 Engine oil capacity (ℓ) Weight (㎏) © by WilTec Wildanger Technik GmbH Item 92453 Page 10 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 11 Electrical drawing © by WilTec Wildanger Technik GmbH Item 92453 Page 11 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 12 Installation of e-starter (optional) © by WilTec Wildanger Technik GmbH Item 92453 Page 12 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 13 TO BE CONNECTED TO EARTH (–)! © by WilTec Wildanger Technik GmbH Item 92453 Page 13 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 14 EARTH / NEGATIVE POSITIVE POLE OF BATTERY © by WilTec Wildanger Technik GmbH Item 92453 Page 14 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 15 © by WilTec Wildanger Technik GmbH Item 92453 Page 15 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
- Page 16 CABLE TO MAGNETO SWITCH Important Note: Reproduction and any commercial use (of parts) of this operating manual, requires a written permission of WilTec Wildanger Technik GmbH. © by WilTec Wildanger Technik GmbH Item 92453 Page 16 http://www.WilTec.de http://www.aoyue.eu 2022-1 http://www.teichtip.de...
