Operator's Manual
For support and additional information
about using your Compact C40 go to
support.seesnake.com/compact-c40
or scan this QR code.
Wi t h
Tech n o lo g y

Advertisement

Table of Contents
loading

Related Manuals for RIDGID SeeSnake COMPACT C40

Summary of Contents for RIDGID SeeSnake COMPACT C40

  • Page 1 Operator’s Manual Wi t h Tech n o lo g y WARNING! Read this Operator’s Man- ual carefully before using this tool. Failure to under- For support and additional information stand and follow the con- about using your Compact C40 go to tents of this manual may result in electrical shock, support.seesnake.com/compact-c40...

  • Page 2: Table Of Contents

    Table of Contents Introduction Regulatory Statements ..................... 3 Safety Symbols ......................3 General Safety Rules Work Area Safety ...................... 4 Electrical Safety ......................4 Personal Safety ......................4 Equipment Use and Care ..................5 Pre-Operation Inspection ..................5 Compact C40 Overview Description........................

  • Page 3: Regulatory Statements

    NOTICE NOTICE indicates informa- UK Importer tion that relates to the pro- Ridge Tool UK (RIDGID) tection of property. 44 Baker Street This symbol means read the oper- London W1U 7AL, UK ator’s manual carefully before using the equipment.

  • Page 4: General Safety Rules

    General Safety Rules • Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the power tool. Keep cord away from WARNING heat, oil, sharp edges, and moving parts. Damaged or entangled cords increase the risk of electrical shock. •...

  • Page 5: Equipment Use And Care

    • If using drain cleaning equipment and • Use the equipment and accessories drain inspection equipment at the in accordance with these instructions, same time, wear RID GID drain clean- taking into account the working con- ing gloves. Never grasp the rotating ditions and the work to be performed.

  • Page 6: Pre-Operation Inspection

    Pre-Operation Inspection 7. Examine the job to be done and de- termine the correct equipment for the task. WARNING 8. Observe the work area and erect bar- riers as necessary to keep bystanders away. See additional product specific safety in- formation and warnings starting on page To reduce the risk of serious injury from electrical shock or other causes, and...

  • Page 7: Compact C40 Overview

    Compact C40 Overview Description TruSense Technology Description ™ The RIDGID SeeSnake Compact C40 ® ® TruSense technology establishes a two- camera reel offers fast, easy setup and can way communication link between the cam- take on the most diverse and demanding era head and a connected CSx series Wi-Fi inspection conditions.

  • Page 8: Standard Equipment

    Type TruSense Counter Data Two-Way Communication Standard Equipment Push Cable • SeeSnake Compact C40 • Docking System Length 40 m [131 ft] • Operator’s Manual Diameter 6.7 mm [0.27 in] • Pipe Guide Kit Fiberglass core 3 mm [0.12 in]...

  • Page 9: System Components

    Specific Safety System Components Information WARNING Frame Docking System This section contains important safety information that is specific to the Com- SeeSnake pact C40. Read these precautions care- System fully before using the equipment to re- Cable duce the risk of electrical shock, fire, and/or serious injury.

  • Page 10: Operating Instructions

    Routing the Camera • Always use appropriate personal pro- tective equipment when handling and If the camera is inside the drum, you must using equipment in drains. Wear ap- route the camera through the push cable propriate protective equipment such as guides.

  • Page 11: Pipe Guides

    CS6x Versa Docking Connecting to the Monitor System Connect the system cable to the monitor by aligning the connector guide pin with the socket and pushing the connector straight WARNING Do not carry the Compact C40 by the Only twist the outer lock- NOTICE monitor’s mounting frame or kickstand.

  • Page 12: Removing The Monitor

    System Cable Removal 3. Firmly push the monitor down into the docking system until you feel the mon- 1. Disconnect the system cable from itor lock into place. the reporting monitor and remove the monitor from the docking system. Removing the Monitor 2.

  • Page 13: Maintenance And Support

    Maintenance and Support System Cable Installation To install the system cable, follow these Cleaning steps: Clean your system with rags and a soft 1. Align the arrow on the slip-ring dial nylon brush. If desired, a mild detergent or with the unlock symbol on the frame disinfectant can be used.

  • Page 14: Service And Repair

    Improper service or repair can cause the camera reel to be unsafe to operate. Service and repair of the camera reel must be performed at a RIDGID Independent Au- thorized Service Center. To find your near- est service center or for any service or re- pair questions: •...
  • Page 15 Compact C40 – English – 15...
  • Page 16 RIDGID and the RIDGID logo are trademarks of Ridge Tool Company, registered in the USA and other countries. All other registered and unregistered trademarks and logos men- tioned herein are the property of their respective owners.
