RIDGID SeeSnake CS65X Operator's Manual
Hide thumbs Also See for SeeSnake CS65X:

Advertisement

Quick Links

WARNING!
Read this Operator's Man-
ual carefully before using
this tool. Failure to under-
stand and follow the con-
tents of this manual may
result in electrical shock,
fire, and/or serious per-
sonal injury.
1.800.544.2843
Operator's Manual
www.calcert.com
15
10
20
5
25
0
30
Companion Apps
Available
Original Instructions – English – 1
sales@calcert.com

Advertisement

Table of Contents
loading

Summary of Contents for RIDGID SeeSnake CS65X

  • Page 1 Operator’s Manual Companion Apps WARNING! Available Read this Operator’s Man- ual carefully before using this tool. Failure to under- stand and follow the con- tents of this manual may result in electrical shock, fire, and/or serious per- sonal injury. Original Instructions – English – 1 1.800.544.2843 www.calcert.com sales@calcert.com...
  • Page 2: Table Of Contents

    Table of Contents Introduction Regulatory Statements �����������������������������������������������������������������������������������������������������������������������������������������������������3 Safety Symbols �����������������������������������������������������������������������������������������������������������������������������������������������������������������3 General Safety Rules Work Area Safety ��������������������������������������������������������������������������������������������������������������������������������������������������������������4 Electrical Safety ����������������������������������������������������������������������������������������������������������������������������������������������������������������4 Personal Safety �����������������������������������������������������������������������������������������������������������������������������������������������������������������4 Equipment Use and Care �������������������������������������������������������������������������������������������������������������������������������������������������5 Battery Use and Care �������������������������������������������������������������������������������������������������������������������������������������������������������5 Pre-Operation Inspection ��������������������������������������������������������������������������������������������������������������������������������������������������6 See Snake CS65x Overview Description ������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Specifications ��������������������������������������������������������������������������������������������������������������������������������������������������������������������8 Components ���������������������������������������������������������������������������������������������������������������������������������������������������������������������9...
  • Page 3: Regulatory Statements

    Introduction Safety Symbols In this manual and on the product, safety symbols and The warnings, cautions, and instructions dis- signal words are used to communicate important safe- cussed in this manual cannot cover all possible ty information� This section is provided to improve under- conditions and situations which may occur.
  • Page 4: General Safety Rules

    • If using drain cleaning equipment and drain in- • Avoid traffic. Pay attention to moving vehicles when spection equipment at the same time, wear RIDGID using on or near roadways� Wear high-visibility cloth- drain cleaning gloves. Never grasp the rotating drain ing or reflector vests�...
  • Page 5: Equipment Use And Care

    Equipment Use and Care Battery Use and Care • Do not force equipment. Use the correct equipment • Use equipment only with specifically designed for your application� The correct equipment does the battery packs. Use of any other battery packs may job better and more safely�...
  • Page 6: Pre-Operation Inspection

    Pre-Operation Inspection WARNING To reduce the risk of serious injury from electrical shock or other causes, and to prevent damage to your equipment, inspect all equipment and correct any problems before each use. To inspect all equipment, follow these steps: 1�...
  • Page 7: See Snake Cs65X Overview

    See Snake CS65x Overview Description The CS65x is easy to use in the most demanding work The RIDGID See Snake CS65x Wi-Fi-enabled reporting ® ® environments� The keyboard is encased in a splash-proof monitor is the all-in-one solution for capturing media and...
  • Page 8: Specifications

    Specifications Specifications Weight without Battery 4�2 kg [9�3 lb] Transfer Method 2�0 USB Dimensions 1 x 0�5 A (Port 1) USB Ports 1 x 1�5 A (Port 2) Depth 406 mm [16�0 in] 128 GB Internal Storage Solid State Drive (SSD) Width 319 mm [12�5 in] Connectivity...
  • Page 9: Components

    Components USB Ports The CS65x supports up to two USB drives so you can create two copies of a job at the same time: one for your USB Port Cover records and one for your customer� Keep the USB port cover closed to protect the USB drives and USB ports during inspections and transport�...
  • Page 10: Operating Instructions

    • Do not expose the unit to mechanical shocks. Ex- posure to mechanical shocks can damage equipment This section contains important safety information and increases the risk of serious injury� that is specific to the RIDGID See Snake CS65x. ®...
  • Page 11: Inspection Overview

    Inspection Overview Connecting to a Camera Reel The CS65x can connect to any See Snake camera reel WARNING with the See Snake system cable� 1� Pull back the outer locking sleeve on the system cable connector� 2� Align the connector ridge and plastic guide pin with the socket and push the connector straight in�...
  • Page 12: Keypad And Keyboard

    Keypad and Keyboard Microphone Caps Lock LED Future Feature LED Keypad Keyboard Keys and Functions Keypad Keyboard Key Name Function Power Power on and off� Select highlighted items and apply changes� When recording standard Select / Pause video or Autolog video, press to pause and resume recording� Open the menu to modify settings, including connectivity, reel, camera, Menu region, and more�...
  • Page 13 Keys and Functions Keypad Keyboard Key Name Function LED Brightness Control the brightness of the LEDs in the camera� Microphone Mute Enable and disable the microphone� Sonde Enable and disable the sonde� Long press (>3 seconds) to set the system measurement to zero at the beginning of an inspection�...
  • Page 14: User Interface

    User Interface 12:05:54 PM / 11-30-2016 3.8m User Interface Time and Date Options: Show time only, date only, both, or neither� Overlay Wi-Fi not connected� Wi-Fi connected� Bluetooth enabled but not connected� Connectivity Bluetooth connected� GPS icon flashes when acquiring satellite signal� Icon is solid when locked� Sonde Sonde enabled and transmitting�...
  • Page 15 User Interface Photo captured� PhotoTalk media created� ™ Video recording� Media Capture Icons Video recording paused� Autolog video recording� Autolog video recording, motion detected� Autolog video recording paused� Open Job A job is open� Internal SSD Storage� The star indicates that this is the primary storage� SSD Status Media is being written to the SSD�...
  • Page 16: Maintenance And Support

    Only use accessories designed and recommended for use with the CS65x. Accessories designed for use with other tools may become hazardous when used with the CS65x. The following RIDGID products have been designed for use with the CS65x: Software Updates • See Snake M...
  • Page 17: Service And Repair

    )� As ™ a licensee, RIDGID pays the cost of recy- cling RIDGID rechargeable batteries� In the U�S� and Canada, RIDGID and other battery suppli- ers use the Call2Recycle program network of over 30,000 ® collection locations to collect and recycle rechargeable batteries�...
  • Page 18: Troubleshooting

    Troubleshooting Problem Probable Fault Solution Verify that the battery is a compatible model� Not all batteries that fit into the battery shoe are compatible� System does not Power source power on Recharge the battery� Switch to AC power� Check primary storage drive settings� Unable to capture No primary storage drive media...
  • Page 19 Due to product develop-ment, the photos and other presentations specified in this manual may differ from the actual product. RIDGID and the RIDGID logo are trademarks of Ridge Tool Company, registered in the USA and other countries. All other registered and unregistered trademarks and logos mentioned herein are the property of their respective owners. Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommendation.

This manual is also suitable for:
