Firmware Upgrade and Calibration
1. A slight deviation is found in the tilt angle of the smartphone
in level position after power-on.
2. A slight deviation is found in the roll angle of the smartphone
in level position after power-on.
3. Frequent small angle correction is found when the
smartphone is in a level position when the gimbal stays still.
1. A slight deviation is found in the level position after the auto-
calibration of the gimbal.
2. The gimbal has not been used for a long time.
3. The gimbal has undergone a significant temperature
difference.
1. Install SMOOTH-Q4 onto the tripod and connect to the ZY Cami App.
2. Go to the settings of the app and select "auto-calibration". The SMOOTH-Q4
will enter the calibration automatically. You can check the progress at the
prompt of the app.
Before the calibration, please make sure the gimbal is straightly put on a flat
surface. Please don't touch the gimbal when in calibration.

Calibration

Calibration Reason

Auto-Calibration

How to
calibrate
Gimbal auto-
calibration
Six-side
calibration
